Lattice Semiconductor Corporation ICE40HX1K-STICK-EVN iCEstick — iCE40HX1K USB FPGA Stick

Part No.:
ICE40HX1K-STICK-EVN iCEstick — iCE40HX1K USB FPGA Stick
Manufacturer:
Lattice Semiconductor Corporation
Category:
Embedded Complex Logic (FPGA, CPLD) Evaluation Boards
Package:
Datasheet:
SANJIA TECHNOLOGY LTD.ICE40HX1K-STICK-EVN iCEstick — iCE40HX1K USB FPGA Stick.pdf
Description:
BOARD EVAL FPGA ICESTICK
Quantity:
Payment:
Payment
Shipping:
Shipping

Inventory:3,686

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity*
Price
Name*
Company*
Email*
Comments

Product details

Lattice Semiconductor ICE40HX1K-STICK-EVN - iCEstick Evaluation Kit

The ICE40HX1K-STICK-EVN is Lattice's iCEstick - a USB-thumb-drive-shaped evaluation board for the iCE40 HX family. The 1,280-logic-cell iCE40HX1K-CT144 is powered and programmed entirely over USB (FTDI 2232H), with a Vishay TFDU4101 IrDA transceiver, 16 LVCMOS I/O on 0.1" pins, a Pmod connector and 32 Mbit of Micron SPI flash on board.

Key Features

  • iCE40HX1K-CT144: 1,280 logic cells, 64 kb EBR, 1 PLL
  • USB-thumb-drive form factor (~4 in) - USB-powered, no external supply
  • FTDI 2232H: programming + UART bridge over one USB cable
  • Vishay TFDU4101 IrDA transceiver (up to 115 kbps) for comms demos
  • 16 LVCMOS/LVTTL 3.3 V I/O on 0.1" headers + 2×6 Pmod connector
  • Micron 32 Mbit N25Q32 SPI flash; 5 user LEDs; 12 MHz MEMS oscillator

Technical Specifications

Manufacturer classificationLattice official: iCE40 evaluation kits (iCEstick)
ManufacturerLattice Semiconductor
KitiCEstick Evaluation Kit
FPGAiCE40HX1K-CT144 (HX family)
Logic / EBR / PLL1,280 LC / 64 kb / 1
USBFTDI 2232H (prog + UART)
IrDAVishay TFDU4101, up to 115 kbps
User I/O16 × 3.3 V CMOS/TTL on 0.1" pins, 1 Pmod
Flash32 Mbit Micron N25Q32 SPI
Clock12 MHz Discera MEMS oscillator
PowerUSB bus-powered
SoftwareiCEcube2 + Diamond Programmer (also IceStorm)

Typical Applications

Per Lattice's iCEstick documentation: low-cost iCE40 prototyping - UART and IR communications experiments, Pmod sensor peripherals, educational FPGA design, and SRAM-reprogrammable research platforms (the board is a community standard for the open-source IceStorm toolchain).

Procurement & Availability

  • Availability: in stock - live quantity shown above
  • MOQ: 1 pc
  • Lead time: ships within 24 h for orders confirmed before 15:00 CST
  • Packaging: factory sealed
  • Warranty: 12 months · traceability: date code and lot on request

Frequently Asked Questions

Q: HX vs LP iCE40?
A: HX trades some static power for faster fabric - 1,280 LC with 64 kb EBR and a PLL, no LED-driver hard blocks of the Ultra family.

Q: Do I need a programmer?
A: No - FTDI 2232H handles JTAG/SPI programming and gives you a UART over the same USB cable.

Q: Open-source toolchain?
A: Yes - the iCE40 bitstream is fully documented via Project IceStorm; iCEcube2 is the official free flow.

Parameter Sources

  • Lattice iCEstick Evaluation Kit user guide/datasheet (HX1K-CT144, FTDI 2232H, TFDU4101, N25Q32, Pmod, 16 I/O)
  • Lattice/DigiKey iCEstick pages

Pictures are for reference only; actual product prevails. Specifications per the manufacturer datasheet - verify against the current revision before design-in.
