Intel EK-10M08E144 MAX 10 FPGA Evaluation Kit — 10M08SA, Arduino R3
- Part No.:
- EK-10M08E144 MAX 10 FPGA Evaluation Kit — 10M08SA, Arduino R3
- Manufacturer:
- Intel
- Package:
EK-10M08E144 MAX 10 FPGA Evaluation Kit — 10M08SA, Arduino R3.pdf- Description:
- KIT EVALUATION MAX 10 FPGA
- Quantity:
- Payment:
- Shipping:
Inventory:413
Please send an inquiry. Send us your inquiry, and we will respond immediately.
Product details
Intel (Altera) EK-10M08E144 - MAX 10 Evaluation Kit
The EK-10M08E144 is Intel's entry-level MAX 10 FPGA evaluation kit, built around the single-supply 10M08SAE144C8G (8K logic elements) in a 144-pin EQFP. USB-powered, with an onboard USB-Blaster II, Enpirion point-of-load regulator and Arduino UNO R3 headers, it is the fastest way to bring up a MAX 10 design - configuration, programming and power measurement are all on the board.
Key Features
- 10M08SAE144C8G: 8,000 LEs, M9K memory, integrated 12-bit ADC
- Arduino UNO R3-compatible headers - accept UNO shields directly
- Onboard USB-Blaster II for JTAG programming (SOF) and flash (POF)
- Intel Enpirion EP5388QI 800 mA point-of-load DC-DC on board
- 50 MHz oscillator, replaceable; potentiometer footprint for ADC demos
- Shunt resistors and probe points for FPGA power measurement
Technical Specifications
| Manufacturer classification | Intel official: MAX 10 FPGA development kits |
| Manufacturer | Intel (Altera) / Terasic |
| Kit | EK-10M08E144 (MAX 10 Evaluation Kit, Power Solution 1) |
| FPGA on board | 10M08SAE144C8G, 144-pin EQFP |
| Logic elements | 8,000 |
| Configuration | JTAG + internal flash (dual-image capable) |
| Expansion | Arduino UNO R3 headers, through-hole vias |
| Clocking | 50 MHz oscillator (replaceable) |
| Power | USB or 5 V adapter; Enpirion EP5388QI PoL |
| Debug | Onboard USB-Blaster II, current-sense shunts |
| Software | Quartus Prime Lite (free) |
Typical Applications
Per Intel's kit documentation: entry-level MAX 10 evaluation - embedded control, analog monitoring via the integrated ADC, motor control, I/O expansion, SPI-to-I2C bridging, power-management control, and classroom/training use with Arduino shields.
Procurement & Availability
- Availability: in stock - live quantity shown above
- MOQ: 1 pc
- Lead time: ships within 24 h for orders confirmed before 15:00 CST
- Packaging: factory sealed
- Warranty: 12 months · traceability: date code and lot on request
Frequently Asked Questions
Q: EK vs DK-DEV-10M08E144-B?
A: Same 10M08SA platform; the -B is Power Solution 2 with updated regulator components and 40 dedicated GPIO. EK is the original Power Solution 1 revision.
Q: Do I need an external programmer?
A: No - the onboard USB-Blaster II programs SOF via JTAG or POF into internal flash.
Q: Arduino shields - which ones?
A: UNO R3-compatible shields work; analog channels are routed through scaling circuits to the FPGA ADC.
Parameter Sources
- Intel/Altera MAX 10 FPGA 10M08 Evaluation Kit page (10M08SAE144C8G, Arduino UNO R3, EP5388QI, 50 MHz, USB-Blaster II)
- Terasic kit contents page
Pictures are for reference only; actual product prevails. Specifications per the manufacturer datasheet - verify against the current revision before design-in.
