Littelfuse Inc. 55300-00-02-A
- Part No.:
- 55300-00-02-A
- Manufacturer:
- Littelfuse Inc.
- Category:
- Angle, Linear Position Measuring
- Package:
- Rectangular, Wire Leads
- Datasheet:
-
55300-00-02-A.pdf
- Description:
- SENSOR ROTARY 360DEG WIRE LEADS
- Quantity:
- Payment:

- Shipping:

Inventory:374
Please send an inquiry. Send us your inquiry, and we will respond immediately.
- Specifications
- FAQ
- Product Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Littelfuse Inc.
- Package/Case:
- Rectangular, Wire Leads
- Series:
- -
- Packaging:
- Box
- Product Status:
- Active
- Programmable:
- -
- For Measuring:
- Rotary Position
- Technology:
- Hall Effect
- Rotation Angle - Electrical, Mechanical:
- 0° ~ 360°
- Linear Range:
- -
- Output:
- Analog Voltage
- Output Signal:
- Clockwise Increase
- Actuator Type:
- External Magnet, Included
- Linearity:
- -
- Resistance:
- -
- Resistance Tolerance:
- -
- Voltage - Supply:
- 4.5V ~ 5.5V
- Mounting Type:
- Chassis Mount
- Termination Style:
- Wire Leads
- Operating Temperature:
- -40°C ~ 105°C
- Grade:
- -
- Qualification:
- -
- Supplier Device Package:
- -
