TVS Diodes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
.jpg)
|
PESD15VS1UBFTVS DIODE 15VWM 40VC SOD523 |
9,700 |
|
Datasheet |
SC-79, SOD-523 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 15V (Max) | 17.6V | 40V | 5A (8/20µs) | 160W | No | General Purpose | 32pF @ 1MHz | 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | SOD-523 |
|
SD36-7GENERAL PROTECTION PP SOD323 T&R |
2,272 |
|
Datasheet |
SC-76, SOD-323 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 36V (Max) | 40V | 55V | 5A (8/20µs) | 275W | No | General Purpose | 44pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
|
VCUT15A1-SD0-G4-08ESD PROTECTION DIODE CLP060315V; |
4,262 |
|
Datasheet |
0201 (0603 Metric) | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 15V (Max) | 15.8V | 26V | 2.5A (8/20µs) | 65W | No | General Purpose | 5.5pF @ 1MHz | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | CLP0603 |
|
|
VCUT05G1-SD0-G4-08ESD PROTECTION DIODE CLP0603 |
4,493 |
|
Datasheet |
0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 5.5V (Max) | 6.5V | 13V | 6A (8/20µs) | - | No | General Purpose | 13pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | CLP0603 |
|
|
VCUT03G1-SD0-G4-08TVS DIODE 3.3VWM 13VC CLP0603 |
7,682 |
|
Datasheet |
0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 3.3V (Max) | 6.5V | 13V | 6A (8/20µs) | 78W | No | General Purpose | 13pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | CLP0603 |
|
D3V3Q1B2DLP3-7TVS DIODE 3.3VWM 7.5VC ESN0603-2 |
6,931 |
|
- |
0201 (0603 Metric) | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 3.3V (Max) | 3.8V | 7.5V | 4A (8/20µs) | 30W | No | General Purpose | 6pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | X3-ESN0603-2 |
|
|
DESD5V0V1BDLP3-7TVS DIODE 5VWM 12.8VC ESN0603-2 |
9,610 |
|
Datasheet |
0201 (0603 Metric) | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 5V (Max) | 6V | 12.8V | 2A (8/20µs) | 20W | No | General Purpose | 5.3pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | X2-ESN0603-2 |
|
ESDZV18-1BF4TKTVS DIODE 24VWM 21.5VC ST0201 |
9,258 |
|
Datasheet |
0201 (0603 Metric) | ESDZ | Tape & Reel (TR) | Active | Zener | - | 1 | 24V (Max) | 18V | 21.5V (Typ) | 6A (8/20µs) | 140W | No | General Purpose | 3pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | ST0201 |
|
|
PESD15VS1ULD-QYLPESD15VS1ULD-Q/SOD882D/DFN1006 |
7,458 |
|
Datasheet |
2-XDFN | - | Tape & Reel (TR) | Active | Zener | 1 | - | 15V (Max) | 17.6V | 40V | 5A (8/20µs) | 150W | No | Telecom | 32pF @ 1MHz | -55°C ~ 150°C (TA) | Automotive | AEC-Q101 | Surface Mount, Wettable Flank | DFN1006D-2 |
|
|
VCUT10G1-SD0-G4-08TVS DIODE 10VWM 18VC CLP0603 |
7,517 |
|
Datasheet |
0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 10V (Max) | 11V | 18V | 4A (8/20µs) | 72W | No | General Purpose | 7.7pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | CLP0603 |
|
|
VCUT15G1-SD0-G4-08ESD PROTECTION DIODE CLP060315V |
5,213 |
|
Datasheet |
0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 15V (Max) | 15.8V | 26V | 2.5A (8/20µs) | 65W | No | General Purpose | 5.5pF @ 1MHz | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | CLP0603 |
|
AOZ8231ADI-05TVS DIODE 5VWM 15.5VC 2DFN |
9,516 |
|
Datasheet |
2-UDFN | - | Tape & Reel (TR) | Active | Zener | - | 1 | 5V (Max) | 5.5V | 15.5V | 5A (8/20µs) | - | No | General Purpose | 13pF @ 1MHz | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 2-DFN (1x0.6) |
|
|
AOZ8231ADI-12TVS DIODE 12VWM 26VC 2DFN |
5,940 |
|
Datasheet |
2-UDFN | - | Tape & Reel (TR) | Active | Zener | - | 1 | 12V (Max) | 13V | 26V | 4A (8/20µs) | - | No | General Purpose | 13pF @ 1MHz | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 2-DFN (1x0.6) |
|
|
AOZ8231ADI-24TVS DIODE 24VWM 39VC 2DFN |
7,151 |
|
Datasheet |
2-UDFN | - | Tape & Reel (TR) | Active | Zener | - | 1 | 24V (Max) | 29V | 39V | 2.5A (8/20µs) | - | No | General Purpose | 12pF @ 1MHz | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 2-DFN (1x0.6) |
|
AOZ8251ADI-05TVS DIODE 5VWM 28VC 2DFN |
7,936 |
|
Datasheet |
0201 (0603 Metric) | - | Tape & Reel (TR) | Not For New Designs | Zener | - | 1 | 5V (Max) | 6.5V | 28V | 4A (8/20µs) | - | No | General Purpose | 10pF @ 1MHz | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 2-DFN (0.62x0.32) |
|
|
AOZ8851ADI-05TVS DIODE 5VWM 28VC 2DFN |
8,229 |
|
Datasheet |
0201 (0603 Metric) | - | Tape & Reel (TR) | Not For New Designs | Zener | - | 1 | 5V (Max) | 6.5V | 28V | 4A (8/20µs) | - | No | General Purpose | 0.22pF @ 1MHz | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 2-DFN (0.62x0.32) |
|
|
AOZ8251BDI-05TVS DIODE 5VWM 24VC 2DFN |
7,337 |
|
Datasheet |
0201 (0603 Metric) | - | Tape & Box (TB) | Not For New Designs | Zener | - | 1 | 5V (Max) | 5.5V | 24V | 16A | - | No | General Purpose | 5pF @ 1MHz | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 2-DFN (0.62x0.32) |
|
|
AOZ8S501BDS-051CH 5V BIDIRECTIONAL TVS |
2,000 |
|
Datasheet |
2-UDFN | - | Tape & Reel (TR) | Active | Zener | - | 1 | 5V (Max) | 5.7V | 11.5V | 20A (8/20µs) | - | No | General Purpose | 35pF @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | 2-DFN (1x0.6) |
|
MMBZ33VALT3TVS DIODE 26VWM 46VC SOT23-3 |
9,986 |
|
Datasheet |
TO-236-3, SC-59, SOT-23-3 | - | Tape & Reel (TR) | Obsolete | Zener | 2 | - | 26V | 31.35V | 46V | 870mA | 40W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23-3 (TO-236) |
|
|
MMBZ6V2ALT3TVS DIODE 3VWM 8.7VC SOT23-3 |
9,933 |
|
Datasheet |
TO-236-3, SC-59, SOT-23-3 | - | Tape & Reel (TR) | Obsolete | Zener | 2 | - | 3V | 5.89V | 8.7V | 2.76A | 24W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23-3 (TO-236) |
