Evaluation and Demonstration Boards and Kits
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Function | Embedded | Utilized IC / Part | Primary Attributes | Secondary Attributes | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EVAL-ADM3062EEB1Z |
6 |
|
Datasheet |
- | Bulk | Active | Interface | Transceiver, RS-485 | No | ADM3062E | - | Half-Duplex | Board(s) |
|
EVAL-ADM3062EEBZ |
5 |
|
Datasheet |
- | Bulk | Active | Interface | Transceiver, RS-485 | No | ADM3062E | - | Half-Duplex | Board(s) |
|
R-REF03-CAN1 |
10 |
|
Datasheet |
- | Box | Active | Interface | CANbus | - | ISO1042, R1SX‐3.305/H | Isolated | - | Board(s) |
|
MAX258EVKIT# |
6 |
|
Datasheet |
- | Box | Active | Power Management | Transformer Driver | No | MAX258 | - | - | Board(s) |
|
STEVAL-IPM10B |
7 |
|
Datasheet |
SLLIMM™ | Bulk | Active | Power Management | Motor Controller/Driver | - | STGIB10CH60TS-L | - | Over Current and Temperature Protection | Board(s) |
|
EVAL-AD5243SDZ |
7 |
|
Datasheet |
- | Bulk | Active | Data Acquisition | Digital Potentiometer | No | AD5243 | 2 Channel, 256 Position | I2C Interface(s) | Board(s) |
|
EVAL-AD5246DBZ |
8 |
|
Datasheet |
- | Box | Active | Data Acquisition | Digital Potentiometer | No | AD5246 | 1 Channel, 128 Position | I2C Interface(s) | Board(s) |
|
MAX14690EVKIT# |
7 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | - | MAX14690 | - | I2C Interface(s) | Board(s) |
|
MAX1758EVKIT+ |
9 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | - | MAX1758 | - | - | Board(s) |
|
|
DS28E17K# |
6 |
|
Datasheet |
- | Box | Active | Interface | 1-Wire to I2C | - | DS28E17 | - | Graphical User Interface (GUI) | Board(s) |
|
MAX20327EVKIT# |
5 |
|
Datasheet |
- | Box | Active | Interface | Analog Switch | - | MAX20327 | - | - | Board(s) |
|
EVKT-2661 |
6 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | - | MP2661 | Li-Ion / Li-Pol (1 Cell) | I2C Interface(s), Graphical User Interface (GUI) | Board(s), Cable(s) |
|
EVKT-MP2696B |
7 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | No | MP2696B | 4V ~ 11V Operating Range | I2C Interface(s), Graphical User Interface (GUI) | Board(s), Cable(s) |
|
DM160219 |
10 |
|
Datasheet |
- | Bulk | Active | Interface | Touch Screen Controller | - | MTCH6102 | - | - | Board(s) |
|
DT100119 |
5 |
|
- |
- | Bulk | Active | Power Management | Energy/Power Monitor | No | PAC1954 | 4-Channel (Quad) | On-Board Test Points | Board(s) |
|
MAX4080EVKIT+ |
10 |
|
Datasheet |
- | Box | Active | Power Management | Current Monitor: High Side | - | MAX4080 | - | - | Board(s) |
|
ADM00308 |
7 |
|
Datasheet |
- | Box | Active | Power Management | Motor Controller/Driver, Stepper | Yes, MCU, 8-Bit | MTS2916A, MTS62C19A, PIC16F883 | - | - | Board(s) |
|
DC1645A-B |
9 |
|
Datasheet |
µModule® | Box | Active | Power Management | Battery Charger | No | LTM8061 | Li-Ion (2 Cells) | On-Board LEDs | Board(s) |
|
MAX22565CAEVKIT# |
6 |
|
Datasheet |
- | Box | Active | Interface | Digital Isolator | No | MAX22565 | 6-Channel (Hex) | On-Board Test Points | Board(s) |
|
MAX20340EVKIT# |
5 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | - | MAX20340 | - | I2C Interface(s) | Board(s) |
