Evaluation and Demonstration Boards and Kits
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Function | Embedded | Utilized IC / Part | Primary Attributes | Secondary Attributes | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TPD12S016PWREVM |
5 |
|
Datasheet |
- | Box | Active | Video | Video Processing | No | TPD12S016 | Level Shifter | 8 ESD Channels, Load Switch | Board(s) |
|
DC1503A-B |
7 |
|
Datasheet |
µModule® | Box | Active | Interface | Transceiver, RS-422, RS-485 | No | LTM2881 | 5V Supply, Isolated, Transceiver + Power | - | Board(s) |
|
DC1503A-A |
10 |
|
Datasheet |
µModule® | Box | Active | Interface | Transceiver, RS-422, RS-485 | No | LTM2881 | 3V Supply, Isolated, Transceiver + Power | - | Board(s) |
|
|
DC1079A-A |
10 |
|
Datasheet |
- | Box | Active | Interface | I2C Bus Buffer | No | LTC4310-1 | Isolated | - | Board(s) |
|
DC1029B |
10 |
|
Datasheet |
- | Box | Active | Power Management | Power Supply Supervisor/Tracker/Sequencer | No | LTC2928 | 4-Channel (Quad) | - | Board(s) |
|
DC1790A-D |
7 |
|
Datasheet |
µModule® | Box | Active | Interface | Digital Isolator | - | LTM2886-5I | - | I2C Interface(s) | Board(s) |
|
DC2432B-C |
7 |
|
Datasheet |
- | Box | Active | Power Management | Voltage Reference | No | LT6658 | 2-Channel (Dual) | - | Board(s) |
|
DC2432B-D |
6 |
|
Datasheet |
- | Box | Active | Power Management | Voltage Reference | No | LT6658 | 2-Channel (Dual) | - | Board(s) |
|
DC2432B-E |
10 |
|
Datasheet |
- | Box | Active | Power Management | Voltage Reference | No | LT6658 | 2-Channel (Dual) | - | Board(s) |
|
DC1746A-B |
7 |
|
Datasheet |
µModule® | Box | Active | Interface | Transceiver, RS-422, RS-485 | No | LTM2881 | 5V Supply, Isolated, Transceiver + Power | - | Board(s) |
|
DC1018B-A |
8 |
|
Datasheet |
- | Box | Active | Power Management | Circuit Protection | No | LT4356-1 | Overvoltage Protection | - | Board(s) |
|
DC2417A-B |
7 |
|
Datasheet |
- | Box | Active | Power Management | Circuit Protection | - | LTC4367-1 | Reverse Voltage, Overvoltage, Undervoltage Protection | On-Board LEDs | Board(s) |
|
MAX4940EVKIT+ |
5 |
|
Datasheet |
- | Box | Active | Timing | Pulse Generator | - | MAX4940 | - | - | Board(s) |
|
|
VM816CU50A-N |
7 |
|
Datasheet |
EVE2 | Box | Active | Display | LCD Controller | - | BT816 | Audio, Display and Touch Functions | USB Interface(s) | Board(s) |
|
EVB811XY-B1 |
5 |
|
- |
- | Box | Active | Interface | LIN | Yes, MCU, 16-Bit | MLX811XY | - | On-Board LEDs | Board(s) |
|
|
BQ24123EVM-002 |
10 |
|
Datasheet |
bqSWITCHER™ | Box | Active | Power Management | Battery Charger | - | BQ24123 | - | - | Board(s) |
|
|
TPS2553Q1EVM |
8 |
|
Datasheet |
- | Bulk | Active | Power Management | Power Distribution Switch (Load Switch) | - | TPS2553-Q1 | - | - | Board(s) |
|
MAXREFDES31# |
6 |
|
Datasheet |
- | Box | Active | Power Management | Power over Ethernet (PoE) | No | MAX5969B, MAX5974A | - | - | Board(s) |
|
MAX22702EVKIT# |
6 |
|
Datasheet |
- | Box | Active | Power Management | Gate Driver | - | MAX22702 | Isolated | - | Board(s) |
|
MAX14919AEVKIT# |
6 |
|
- |
- | Box | Active | Power Management | Power Distribution Switch (Load Switch) | Yes, MCU | MAX14919A | 3V ~ 5.5V Supply | On-Board LEDs, Test Points | Board(s) |
