Evaluation and Demonstration Boards and Kits
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Function | Embedded | Utilized IC / Part | Primary Attributes | Secondary Attributes | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
MAX22191EVKIT# |
9 |
|
Datasheet |
- | Box | Active | Interface | Digital Isolator | - | MAX22191 | - | On-Board Test Points | Board(s) |
|
EVAL6235Q |
6 |
|
Datasheet |
- | Bulk | Active | Power Management | Motor Controller/Driver | No | L6235 | Motors (BLDC) | Over Current and Temperature Protection | Board(s) |
|
EVALSTDRIVE601 |
9 |
|
Datasheet |
- | Bulk | Active | Power Management | Gate Driver | - | STDRIVE601 | - | On-Board Test Points | Board(s) |
|
DC1354B-A |
10 |
|
Datasheet |
- | Box | Active | Power Management | Hot Swap Controller | No | LT4256-1 | Latch-Off | On-Board LEDs | Board(s) |
|
|
SIP32430EVB |
10 |
|
Datasheet |
- | Bulk | Active | Power Management | Power Distribution Switch (Load Switch) | No | SIP32430 | - | - | Board(s) |
|
SIP32429EVB |
6 |
|
Datasheet |
- | Bulk | Active | Power Management | Power Distribution Switch (Load Switch) | No | SIP32429 | - | - | Board(s) |
|
|
EVAL-AD5116EBZ |
7 |
|
Datasheet |
- | Bulk | Active | Data Acquisition | Digital Potentiometer | No | AD5116 | 1 Channel, 256 Position | - | Board(s) |
|
EVAL-ADGS1612SDZ |
6 |
|
Datasheet |
- | Box | Active | Interface | Analog Switch | - | ADGS1612 | SPST | - | Board(s) |
|
MAXNANOPWRBD# |
5 |
|
Datasheet |
- | Box | Active | Test and Measurement | Digital Voltmeter (DVM) | Yes, MCU, 32-Bit | MAX9119, MAX9634, MAX11615, MAX17222, MAX32660, MAX40018 | - | - | Board(s) |
|
SC18IS604-EVB |
6 |
|
Datasheet |
- | Bulk | Active | Interface | I2C to SPI | No | SC18IS604 | 1.71V ~ 3.6V Operating Range | - | Board(s) |
|
SC18IS606-EVB |
7 |
|
Datasheet |
- | Bulk | Active | Interface | I2C to SPI | No | SC18IS606 | 1.71V ~ 3.6V Operating Range | - | Board(s) |
|
|
MAX14851EVKIT# |
7 |
|
Datasheet |
- | Box | Active | Interface | Digital Isolator | - | MAX14851 | 6-Channel (Hex) | - | Board(s) |
|
|
EVAL-ADG5209FEBZ |
8 |
|
Datasheet |
- | Box | Active | Interface | 4:1 Multiplexer | - | ADG5209F | 2-Channel (Dual) | - | Board(s) |
|
|
IL3685-3-01 |
8 |
|
Datasheet |
IsoLoop® | Bulk | Active | Interface | Digital Isolator | - | IL3685-3E | PROFIBUS RS-485 Transceiver | - | Board(s) |
|
|
MAX13485EEVKIT+ |
7 |
|
Datasheet |
- | Box | Active | Interface | Transceiver, RS-422, RS-485 | No | MAX13485E | 1 Driver, 1 Receiver | Half-Duplex, ESD-Protected | Board(s) |
|
TSCS42XX-EVAL |
9 |
|
Datasheet |
- | Box | Active | Audio | CODEC | No | TSCS42xx | - | - | Board(s) |
|
|
MAX5969BEVKIT+ |
10 |
|
Datasheet |
- | Box | Active | Power Management | Hot Swap Controller | No | MAX5969 | - | Temperature Protection | Board(s) |
|
|
EVAL-ADG788EBZ |
7 |
|
Datasheet |
- | Box | Active | Interface | Analog Switch | - | ADG788 | - | - | Board(s) |
|
|
SI5XX-EVB |
5 |
|
Datasheet |
- | Bulk | Active | Timing | Clock Oscillation | - | Si5xx | 100kHz ~ 1.417GHz Frequency Range | - | Board(s) |
|
ME812A-WH50R |
6 |
|
Datasheet |
- | Box | Active | Display | LCD Touch Screen | - | FT812 | 5" 800x480 WVGA | SPI Interface(s) | Board(s) |
