Evaluation and Demonstration Boards and Kits
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Function | Embedded | Utilized IC / Part | Primary Attributes | Secondary Attributes | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
MAX9064EVKIT+ |
6 |
|
Datasheet |
- | Box | Active | Linear | Comparator, Single | No | MAX9064 | 0.2V Internal Voltage Reference | Push-Pull Output | Board(s) |
|
|
MAX9061EVKIT+ |
6 |
|
Datasheet |
- | Box | Active | Linear | Comparator, Single | No | MAX9061 | 0.9 V ~ 5.5V External Voltage Reference Required | Open-Drain Output | Board(s) |
|
EVAL-ADM3068EEBZ |
8 |
|
Datasheet |
- | Box | Active | Interface | Transceiver, RS-485 | - | ADM3068E | 1 Driver, 1 Receiver | 3V ~ 5.5V Supply | Board(s) |
|
MCP3905RD-PM1 |
7 |
|
Datasheet |
- | Bulk | Active | Power Management | Energy/Power Meter | No | MCP3905/6 | 1-Phase, 220 VAC, In Case, With Mechanical Counter | On Board Transformerless AC/DC 5V Supply | Board(s) |
|
MCP73831EV |
5 |
|
Datasheet |
- | Bulk | Active | Power Management | Battery Charger | - | MCP73831 | - | - | Board(s) |
|
GP22-EVA MODULE |
9 |
|
- |
- | Box | Active | Interface | Time-to-Digital Converter | - | TDC-GP22 | 2-Channel (Dual) | - | Board(s) |
|
GP22-DEMO MODULE |
10 |
|
- |
- | Box | Active | Interface | Time-to-Digital Converter | - | TDC-GP22 | 2-Channel (Dual) | - | Board(s) |
|
GP30-DEMO MODULE |
7 |
|
Datasheet |
- | Box | Active | Interface | Time-to-Digital Converter | Yes, MCU, 32-Bit | TDC-GP30 | - | - | Board(s) |
|
MAX20067EVKIT# |
6 |
|
Datasheet |
- | Box | Active | Power Management | Special Purpose | No | MAX20067 | 3-Channel (Triple) | I2C Interface(s) | Board(s) |
|
|
GP30-DEMO-US-F01 |
5 |
|
- |
- | Box | Active | Interface | Time-to-Digital Converter | - | TDC-GP30 | - | - | Board(s) |
|
IL3585-01 |
10 |
|
Datasheet |
IsoLoop® | Bulk | Active | Interface | Isolated, RS-485 | - | IL3585E | - | Thermal Shutdown Circuit | Board(s) |
|
EVAL-AD5259DBZ |
10 |
|
Datasheet |
- | Box | Active | Data Acquisition | Digital Potentiometer | No | AD5259 | 1 Channel, 256 Position | I2C Interface(s) | Board(s) |
|
|
DC2062A-B |
7 |
|
Datasheet |
- | Box | Active | Circuit Protection | Surge Suppression | No | LT4363-2 | Auto-Retry | Reverse Protection | Board(s) |
|
|
DC1935A-B |
9 |
|
Datasheet |
- | Box | Active | Circuit Protection | Surge Suppression | No | LT4363-2 | Auto-Retry | Reverse Protection | Board(s) |
|
MAX20337EVKIT# |
9 |
|
Datasheet |
- | Box | Active | Interface | Switch, SPDT, 2:1 | No | MAX20337 | - | 1.65 ~ 5.5V Supply | Board(s) |
|
BQ27426EVM-738 |
5 |
|
Datasheet |
- | Bulk | Active | Power Management | Fuel Gauge | - | BQ27426 | - | - | Board(s) |
|
MAX20360EVKIT# |
6 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | No | MAX20360 | Pmod™-Compatible | I2C/USB Interface(s) | Board(s), Cable(s) |
|
BD71631QWZ-EVK-001 |
8 |
|
Datasheet |
- | Bulk | Active | Power Management | Battery Charger | No | BD71631 | 4.5V ~ 5.5V Input Voltage | On-Board LEDs | Board(s) |
|
|
MAX9926UEVKIT+ |
5 |
|
Datasheet |
- | Box | Active | Interface | Sensor, Variable Reluctance | No | MAX9926U | Differential Inputs | 4.5V ~ 5.5V Supply | Board(s) |
|
|
MAX9924UEVKIT+ |
8 |
|
Datasheet |
- | Box | Active | Interface | Sensor, Variable Reluctance | No | MAX9924U | Differential Inputs | 4.5V ~ 5.5V Supply | Board(s) |
