Coaxial Cables (RF)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Style | 1st Connector | 1st Contact Gender | 1st Connector Mounting Type | 1st Connector Mounting Feature | 2nd Connector | 2nd Contact Gender | 2nd Connector Mounting Type | 2nd Connector Mounting Feature | Length | Cable Type | Cable Impedance | Connector Impedance | Overall Impedance | Frequency - Max | Color | Features | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
73082-X-48COAX CBL SMA TO SMA |
1,412 |
|
Datasheet |
- | Bag | Active | SMA to SMA | SMA Plug | Male | Free Hanging (In-Line) | - | SMA Plug | Male | Free Hanging (In-Line) | - | 48.0" (1.2m) 4.0' | RG-142B | 50 Ohms | - | 50 Ohms | 4 GHz | Copper | Shielded | -65°C ~ 165°C | - | - |
|
LCCA31336-FT2COAX CBL SMA TO SMB |
4,530 |
|
Datasheet |
LCCA | Bulk | Active | SMA to SMB | SMA Plug | Male | Free Hanging (In-Line) | - | SMB Plug | Male | Free Hanging (In-Line) | - | 24.00" (609.60mm) | RG-316 | 50 Ohms | - | 50 Ohms | - | - | - | - | - | - |
|
|
LCCA31015-FT1COAX CBL N-TYPE TO N-TYPE |
1,414 |
|
- |
- | Bag | Active | N-Type to N-Type | N-Type Plug, Right Angle | Male | Free Hanging (In-Line), Right Angle | - | N-Type Plug, Right Angle | Male | Free Hanging (In-Line), Right Angle | - | 12.00" (304.80mm) | SPO-250 | 50 Ohms | 50 Ohms | 50 Ohms | 5.8 GHz | Black | - | -40°C ~ 85°C | - | - |
|
|
LCCA31022-FT5COAX CBL 7/16 DIN TO N-TYPE |
4,483 |
|
- |
- | Bag | Active | 7/16 DIN to N-Type | 7/16 Plug | Male | Free Hanging (In-Line) | - | N-Type Jack | Female | Free Hanging (In-Line) | - | 60.0" (1.5m) 5.0' | SPO-375 | 50 Ohms | 50 Ohms | 50 Ohms | 6 GHz | Black | - | -40°C ~ 85°C | - | - |
|
|
LCCA31071-FT4COAX CBL SMA TO SMA |
1,172 |
|
- |
- | Bag | Active | SMA to SMA | SMA Plug, Right Angle | Male | Free Hanging (In-Line), Right Angle | - | SMA Plug, Right Angle | Male | Free Hanging (In-Line), Right Angle | - | 48.0" (1.2m) 4.0' | TFT-402LF | 50 Ohms | 50 Ohms | 50 Ohms | 5.8 GHz | Blue | - | -55°C ~ 150°C | - | - |
|
|
LCCA31067-FT1COAX CBL 2.2/5 TO QMA |
3,413 |
|
- |
- | Bag | Active | 2.2/5 to QMA | 2.2/5 Plug | Male | Free Hanging (In-Line) | - | QMA Plug | Male | Free Hanging (In-Line) | - | 12.00" (304.80mm) | TFT-402LF | 50 Ohms | 50 Ohms | 50 Ohms | 3 GHz | Blue | - | -40°C ~ 85°C | - | - |
|
|
CCSC316-3COAX CBL SMC TO SMC |
4,550 |
|
- |
- | Bag | Active | SMC to SMC | SMC Plug | Male | Free Hanging (In-Line) | - | SMC Plug | Male | Free Hanging (In-Line) | - | 36.00" (914.40mm) | RG-316 | 50 Ohms | - | 50 Ohms | - | Tan | - | 165°C | - | - |
|
|
LCCA31205-FT4COAX CBL BNC TO SMB |
3,511 |
|
Datasheet |
LCCA | Bulk | Active | BNC to SMB | BNC Plug | Male | Free Hanging (In-Line) | - | SMB Jack | Female | Free Hanging (In-Line) | - | 48.0" (1.2m) 4.0' | RG-174 | 50 Ohms | - | 50 Ohms | - | - | - | - | - | - |
|
|
CC59B-25COAX CBL BNC TO BNC |
2,906 |
|
- |
- | Bag | Active | BNC to BNC | BNC Plug | Male | Free Hanging (In-Line) | - | BNC Plug | Male | Free Hanging (In-Line) | - | 300.0" (7.6m) 25.0' | RG-59 | 75 Ohms | - | 75 Ohms | - | Black | - | - | - | - |
|
095-850-294M20LCOAX CBL TNC TO TNC |
2,996 |
|
Datasheet |
TNC | Bag | Active | TNC to TNC | TNC Plug | Male | Free Hanging (In-Line) | - | TNC Plug | Male | Free Hanging (In-Line) | - | 787.4" (20.0m) 65.6' | RG-58 | 50 Ohms | - | 50 Ohms | 6 GHz | Black | - | - | - | - |
|
095-902-507M075COAX CBL SMA TO SMA |
1,261 |
|
Datasheet |
- | Bag | Active | SMA to SMA | SMA Jack | Female | Panel Mount | Bulkhead - Front Side Nut | SMA Plug, Right Angle | Male | Free Hanging (In-Line) | - | 29.53" (750.00mm) | LMR 200 | 50 Ohms | - | 50 Ohms | 8 GHz | Black | - | - | - | - |
|
|
095-725-121-048COAX CBL SMP TO SMP |
4,321 |
|
Datasheet |
- | Bag | Active | SMP to SMP | SMP Plug, Right Angle | Male | Free Hanging (In-Line) | - | SMP Plug, Right Angle | Male | Free Hanging (In-Line) | - | 48.0" (1.2m) 4.0' | Hand Formable .047 | - | - | 50 Ohms | 20 GHz | Gray | - | - | - | - |
|
6XV18755CE30COAX CBL N-TYPE TO RP-SMA |
4,821 |
|
Datasheet |
- | Box | Active | N-Type to RP-SMA | RP-SMA Plug | Male | Free Hanging (In-Line) | - | N-Type Plug | Male | Free Hanging (In-Line) | - | 11.811" (300.00mm) | - | - | - | 50 Ohms | 6 GHz | Aqua | - | -40°C ~ 80°C | - | - |
|
|
LIS-C9-11716-16716-01000-52CBL ASSY |
2,142 |
|
- |
LISCA | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
LCCA31123-FT6COAX CBL BNC TO SMA |
3,249 |
|
Datasheet |
- | Bulk | Active | BNC to SMA | BNC Plug | Male | Free Hanging (In-Line) | - | SMA Plug | Male | Free Hanging (In-Line) | - | 72.0" (1.8m) 6.0' | RG-316 | 50 Ohms | - | 50 Ohms | - | - | - | - | - | - |
|
095-725-107M100COAX CBL SMP TO SMP |
4,818 |
|
Datasheet |
- | Bulk | Active | SMP to SMP | SMP Plug | Female | Free Hanging (In-Line) | - | SMP Plug | Female | Free Hanging (In-Line) | - | 39.4" (1.0m) 3.3' | TFlex-405 | - | - | 50 Ohms | 20 GHz | Blue | Shielded | - | - | - |
|
ASMA1500E058L13COAX CBL SMA TO FME |
1,343 |
|
Datasheet |
- | Bulk | Active | SMA to FME | SMA Plug | Male | Free Hanging (In-Line) | - | FME Plug | Male | Free Hanging (In-Line) | - | 590.6" (15.0m) 49.2' | LLC200A | - | - | 50 Ohms | 6 GHz | Black | Shielded | - | - | - |
|
PE3C7966-12COAX CBL N-TYPE TO N-TYPE |
4,671 |
|
Datasheet |
- | Bag | Active | N-Type to N-Type | N-Type Plug | Male | Free Hanging (In-Line) | - | N-Type Plug | Male | Free Hanging (In-Line) | - | 12.00" (304.80mm) | - | 50 Ohms | 50 Ohms | 50 Ohms | 5.8 GHz | Blue | - | -40°C ~ 85°C | - | - |
|
|
LCCA31251-FT6COAX CBL FAKRA TO FAKRA |
3,261 |
|
Datasheet |
LCCA | Bulk | Active | Fakra to Fakra | Fakra Jack | Female | Free Hanging (In-Line) | - | Fakra Jack, Right Angle | Female | Free Hanging (In-Line) | - | 72.0" (1.8m) 6.0' | RG-316 | 50 Ohms | - | 50 Ohms | - | - | - | - | - | - |
|
|
CBL-240-82FT-T1-T1COAX CBL TNC TO TNC |
3,277 |
|
Datasheet |
CBL | Bulk | Active | TNC to TNC | TNC Plug | Male | Free Hanging (In-Line) | - | TNC Plug | Male | Free Hanging (In-Line) | - | 984.3" (25.0m) 82.0' | PFP 240 | - | - | - | - | Black | - | - | - | - |
