Lattice Semiconductor Corporation LCMXO3LF-2100E-5UWG49CTR1K MachXO3LF — 2100 LUTs, WLCSP-49
- Part No.:
- LCMXO3LF-2100E-5UWG49CTR1K MachXO3LF — 2100 LUTs, WLCSP-49
- Manufacturer:
- Lattice Semiconductor Corporation
- Category:
- FPGAs (Field Programmable Gate Array)
- Package:
- 49-UFBGA, WLCSP
LCMXO3LF-2100E-5UWG49CTR1K MachXO3LF — 2100 LUTs, WLCSP-49.pdf- Description:
- IC FPGA 38 I/O 49WLCSP
- Quantity:
- Payment:
- Shipping:
Inventory:14,533
Please send an inquiry. Send us your inquiry, and we will respond immediately.
Product details
Lattice Semiconductor LCMXO3LF-2100E-5UWG49CTR1K - MachXO3LF CPLD/FPGA
The LCMXO3LF-2100E-5UWG49CTR1K packs the MachXO3LF-2100 - 2,100 LUTs, 74 kb EBR, 80 kb UFM, one fractional-N-capable PLL - into a 49-ball WLCSP of just 3.2 × 3.2 mm. The E suffix denotes the 1.2 V low-power core; the LF suffix means reprogrammable flash with instant-on boot, dual-boot recovery and password-protected security.
Key Features
- 2,100 LUTs with reprogrammable flash - instant-on boot
- 74 kb sysMEM EBR + 16 kb distributed RAM; 80 kb UFM user flash
- 1 PLL with fractional-N synthesis (7–400 MHz input range)
- Hardened 2× I2C, 1× SPI, timer/counter, on-chip oscillator
- UWG49 - 49-ball WLCSP 3.2 × 3.2 mm, 38 I/O, 0.4 mm pitch
- Security: password protection, dual-boot error recovery, soft-error detect/correct
Technical Specifications
| Manufacturer classification | Lattice official: MachXO3 - Control PLD and bridging FPGA |
| Manufacturer | Lattice Semiconductor |
| Series | MachXO3LF, flash |
| Device | LCMXO3LF-2100E |
| LUTs | 2,100 |
| EBR SRAM | 74 kb |
| Distributed RAM | 16 kb |
| UFM user flash | 80 kb (100k write cycles C/I) |
| PLL | 1 (fractional-N) |
| Hardened functions | 2× I2C, 1× SPI, timer/counter, oscillator, MIPI D-PHY emulated |
| Configuration | Internal flash, dual-boot, background programming |
| Package | UWG49 - 49-ball WLCSP 3.2 × 3.2 mm, 38 I/O |
| Speed grade | -5 (E, 1.2 V core) |
| Supply | 1.2 V core |
| RoHS | Compliant |
Typical Applications
Per the MachXO3 data sheet: control PLD and bridging in space-constrained, battery-sensitive products - MIPI DSI/CSI-2 bridging, sensor aggregation, power and thermal management in servers and portable devices, and automotive-adjacent system control (AEC-Q100 grade exists in family).
Procurement & Availability
- Availability: in stock - live quantity shown above
- MOQ: 1 pc
- Lead time: ships within 24 h for orders confirmed before 15:00 CST
- Packaging: factory sealed
- Warranty: 12 months · traceability: date code and lot on request
Frequently Asked Questions
Q: Why WLCSP for a control PLD?
A: 3.2 × 3.2 mm fits under shields and beside camera modules - typical for MIPI bridging in mobile designs.
Q: E grade means?
A: 1.2 V low-power core (E). C parts (2.5/3.3 V) exist in the same family for higher speed.
Q: TR1K reel size?
A: TR1K = 1,000-unit tape-and-reel for production runs.
Parameter Sources
- Lattice MachXO3 Family Data Sheet (2100 = 2,100 LUT, 74 kb EBR, 80 kb UFM, 1 PLL; UWG49 = 38 I/O WLCSP)
- Lattice MachXO3 product page (security, dual-boot, TransFR)
Pictures are for reference only; actual product prevails. Specifications per the manufacturer datasheet - verify against the current revision before design-in.
