Stepper Motors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Coil Type | Voltage - Rated | Current Rating (Amps) | Steps per Revolution | Step Angle | Accuracy | Torque - Holding (oz-in / mNm) | Size / Dimension | NEMA Frame Size | Diameter - Shaft | Length - Shaft and Bearing | Mounting Hole Spacing | Termination Style | Operating Temperature | Coil Resistance | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NEMA11-20-02D-AMT112SSTEPPER MOTOR W/ INCREMENTAL ENC |
1,442 |
|
Datasheet |
NEMA11-AMT112S | Box | Active | - | Bipolar | 24 ~ 48VDC | 1.3 A | 200.0 | 1.8° | ±0.2% | 16.6 / 117.22 | Square - 1.110" x 1.110" (28.20mm x 28.20mm) | 11 | 0.197" (5.00mm) | 0.791" (20.10mm) | 0.909" (23.10mm) | Connector | -20°C ~ 50°C | 1.9 Ohms | Integrated Encoder |
|
82924020STEPPER MOTOR PM GEARED BI 6.3V |
3,962 |
|
- |
82924 | Bulk | Active | Permanent Magnet Gear Motor | Bipolar | 6.3VDC | 590 mA | 48.0 | 7.5° | ±5% | 9.91 / 70 | Round - 2.020" Dia (51.30mm) | 21 | 0.157" (4.00mm) | 0.520" (13.20mm) | 1.874" (47.60mm) | Wire Leads | -30°C ~ 70°C | 10.7 Ohms | Flatted Shaft |
|
82924022STEPPER MOTOR PM GEARED BI 6.3V |
2,482 |
|
- |
82924 | Bulk | Active | Permanent Magnet Gear Motor | Bipolar | 6.3VDC | 590 mA | 48.0 | 7.5° | ±5% | 9.91 / 70 | Round - 2.020" Dia (51.30mm) | 21 | 0.157" (4.00mm) | 0.520" (13.20mm) | 1.874" (47.60mm) | Wire Leads | -30°C ~ 70°C | 10.7 Ohms | Flatted Shaft |
|
82924030STEPPER MOTOR PM GEARED UNI 6.3V |
3,526 |
|
- |
82924 | Bulk | Active | Permanent Magnet Gear Motor | Unipolar | 6.3VDC | 590 mA | 48.0 | 7.5° | ±5% | 9.91 / 70 | Round - 2.020" Dia (51.30mm) | 21 | 0.157" (4.00mm) | 0.520" (13.20mm) | 1.874" (47.60mm) | Wire Leads | -30°C ~ 70°C | 10.7 Ohms | Flatted Shaft |
|
82924048STEPPER MOTOR PM GEARED UNI 6.3V |
1,185 |
|
- |
82924 | Bulk | Active | Permanent Magnet Gear Motor | Unipolar | 6.3VDC | 280 mA | 48.0 | 7.5° | ±5% | 9.91 / 70 | Round - 2.020" Dia (51.30mm) | 21 | 0.157" (4.00mm) | 0.520" (13.20mm) | 1.874" (47.60mm) | Wire Leads | -30°C ~ 70°C | 46 Ohms | Flatted Shaft |
|
82924049STEPPER MOTOR PM GEARED UNI 6.3V |
2,349 |
|
- |
82924 | Bulk | Active | Permanent Magnet Gear Motor | Unipolar | 6.3VDC | 280 mA | 48.0 | 7.5° | ±5% | 9.91 / 70 | Round - 2.020" Dia (51.30mm) | 21 | 0.157" (4.00mm) | 0.520" (13.20mm) | 1.874" (47.60mm) | Wire Leads | -30°C ~ 70°C | 46 Ohms | Flatted Shaft |
|
82924055STEPPER MOTOR PM GEARED UNI 6.3V |
3,188 |
|
- |
82924 | Bulk | Active | Permanent Magnet Gear Motor | Unipolar | 6.3VDC | 590 mA | 48.0 | 7.5° | ±5% | 9.91 / 70 | Round - 2.020" Dia (51.30mm) | 21 | 0.157" (4.00mm) | 0.520" (13.20mm) | 1.874" (47.60mm) | Wire Leads | -30°C ~ 70°C | 10.7 Ohms | Flatted Shaft |
|
34KM-K012-00WSTEP MOTOR HYBRID UNIPOLAR 24V |
3,895 |
|
Datasheet |
34KM | Bulk | Active | Hybrid | Unipolar | 24VDC | 3 A | 200.0 | 1.8° | ±5% | 354.07 / 2500 | Square - 3.347" x 3.347" (85.00mm x 85.00mm) | 34 | 0.551" (14.00mm) | 1.457" (37.00mm) | 2.740" (69.60mm) | Wire Leads | -10°C ~ 50°C | 1.1 Ohms | Double Flatted Shaft |
|
34KM-K006-00WSTEP MOTOR HYBRID UNIPOLAR 24V |
4,912 |
|
Datasheet |
34KM | Bulk | Active | Hybrid | Unipolar | 24VDC | 4.8 A | 200.0 | 1.8° | ±5% | 354.07 / 2500 | Square - 3.347" x 3.347" (85.00mm x 85.00mm) | 34 | 0.551" (14.00mm) | 1.457" (37.00mm) | 2.740" (69.60mm) | Wire Leads | -10°C ~ 50°C | 0.45 Ohms | Double Flatted Shaft |
|
34KM-K023-99WSTEP MOTOR HYBRID DUAL SHAFT 24V |
3,877 |
|
Datasheet |
34KM | Bulk | Active | Hybrid, Dual Shaft | Unipolar | 24VDC | 1.9 A | 200.0 | 1.8° | ±5% | 354.07 / 2500 | Square - 3.347" x 3.347" (85.00mm x 85.00mm) | 34 | 0.551" (14.00mm) | 1.457" (37.00mm) | 2.740" (69.60mm) | Wire Leads | -10°C ~ 50°C | 2.8 Ohms | Double Flatted Shaft |
|
34KM-K012-99WSTEP MOTOR HYBRID DUAL SHAFT 24V |
3,646 |
|
Datasheet |
34KM | Bulk | Active | Hybrid, Dual Shaft | Unipolar | 24VDC | 3 A | 200.0 | 1.8° | ±5% | 354.07 / 2500 | Square - 3.347" x 3.347" (85.00mm x 85.00mm) | 34 | 0.551" (14.00mm) | 1.457" (37.00mm) | 2.740" (69.60mm) | Wire Leads | -10°C ~ 50°C | 1.1 Ohms | Double Flatted Shaft |
|
34KM-K006-99WSTEP MOTOR HYBRID DUAL SHAFT 24V |
1,601 |
|
Datasheet |
34KM | Bulk | Active | Hybrid, Dual Shaft | Unipolar | 24VDC | 4.8 A | 200.0 | 1.8° | ±5% | 354.07 / 2500 | Square - 3.347" x 3.347" (85.00mm x 85.00mm) | 34 | 0.551" (14.00mm) | 1.457" (37.00mm) | 2.740" (69.60mm) | Wire Leads | -10°C ~ 50°C | 0.45 Ohms | Double Flatted Shaft |
|
GS0036-17M001HYBRID 17 STEP MOTOR 1:3.6 GEARB |
4,068 |
|
Datasheet |
GS | Bulk | Active | Hybrid Gear Motor | Unipolar | 24VDC | 850 mA | 720.0 | 0.5° | - | 28.33 / 200 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | 0.787" (20.00mm) | 1.220" (31.00mm) | Wire Leads | -10°C ~ 50°C | 4.2 Ohms | Flatted Shaft |
|
GS0072-17M001HYBRID 17 STEP MOTOR 1:7.2 GEARB |
2,535 |
|
Datasheet |
GS | Bulk | Active | Hybrid Gear Motor | Unipolar | 24VDC | 850 mA | 1440.0 | 0.25° | - | 56.66 / 400 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | 0.787" (20.00mm) | 1.220" (31.00mm) | Wire Leads | -10°C ~ 50°C | 4.2 Ohms | Flatted Shaft |
|
GS0090-17M001HYBRID 17 STEP MOTOR 1:9 GEARBOX |
3,474 |
|
Datasheet |
GS | Bulk | Active | Hybrid Gear Motor | Unipolar | 24VDC | 850 mA | 1800.0 | 0.2° | - | 70.82 / 500 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | 0.787" (20.00mm) | 1.220" (31.00mm) | Wire Leads | -10°C ~ 50°C | 4.2 Ohms | Flatted Shaft |
|
GS0100-17M001HYBRID 17 STEP MOTOR 1:10 GEARBO |
4,764 |
|
Datasheet |
GS | Bulk | Active | Hybrid Gear Motor | Unipolar | 24VDC | 850 mA | 2000.0 | 0.18° | - | 79.32 / 560 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | 0.787" (20.00mm) | 1.220" (31.00mm) | Wire Leads | -10°C ~ 50°C | 4.2 Ohms | Flatted Shaft |
|
GT0036-17M000HYBRID 17 STEP MOTOR LOW BACKLAS |
4,400 |
|
Datasheet |
GT | Bulk | Active | Hybrid Gear Motor | Unipolar | 24VDC | 1 A | 720.0 | 0.5° | - | 49.56 / 350 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.236" (6.00mm) | 0.787" (20.00mm) | 1.220" (31.00mm) | Wire Leads | -10°C ~ 50°C | 3.1 Ohms | Flatted Shaft |
|
GT0072-17M000HYBRID 17 STEP MOTOR LOW BACKLAS |
2,710 |
|
Datasheet |
GT | Bulk | Active | Hybrid Gear Motor | Unipolar | 24VDC | 1 A | 1440.0 | 0.25° | - | 99.1 / 700 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.236" (6.00mm) | 0.787" (20.00mm) | 1.220" (31.00mm) | Wire Leads | -10°C ~ 50°C | 3.1 Ohms | Flatted Shaft |
|
GS0180-17M001HYBRID 17 STEP MOTOR 1:18 GEARBO |
3,348 |
|
Datasheet |
GS | Bulk | Active | Hybrid Gear Motor | Unipolar | 24VDC | 850 mA | 3600.0 | 0.1° | - | 113.30 / 800 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.197" (5.00mm) | 0.787" (20.00mm) | 1.220" (31.00mm) | Wire Leads | -10°C ~ 50°C | 4.2 Ohms | Flatted Shaft |
|
GT0100-17M000HYBRID 17 STEP MOTOR LOW BACKLAS |
3,609 |
|
Datasheet |
GT | Bulk | Active | Hybrid Gear Motor | Unipolar | 24VDC | 1 A | 2000.0 | 0.18° | - | 141.63 / 1000 | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | 17 | 0.236" (6.00mm) | 0.787" (20.00mm) | 1.220" (31.00mm) | Wire Leads | -10°C ~ 50°C | 3.1 Ohms | Flatted Shaft |
