Pushbutton Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Marking | Color - Actuator/Cap | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Ingress Protection | Features | Panel Cutout Dimensions | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EH12NMB4ZXSWITCH PB SPST-NO 2A 48V |
2,514 |
|
Datasheet |
EH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST-NO | Off-Mom | 2A (DC) | - | 48 V | Round, Button | - | Yellow | - | - | Screw Terminal | IP67 - Dust Tight, Waterproof | - | Circular - 12.00mm Dia | -20°C ~ 70°C |
|
CTHS15CIC05ALARMSWITCH PUSH CAPACITIVE ILLUM SQ |
100 |
|
Datasheet |
CTH | Tube | Active | Through Hole | Capacitive, Illuminated | - | Off-On | - | - | - | Square, Button | Alarm Symbol | Black | LED, Green | 3.2 VDC | PC Pin | - | - | - | - |
|
BH19NFNZXSWITCH PB SPST 1A 125VAC |
1,036 |
|
Datasheet |
BH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST | Off-Mom | 1A (AC), 2A (DC) | 125 V | 36 V | Round, Button, Flush | - | Silver | - | - | Screw Terminal | IP67 - Dust Tight, Waterproof | - | Circular - 19.00mm Dia | -25°C ~ 55°C |
|
M2B15BA5G03-CHSWITCH PUSH SPDT 0.4VA 28V |
1,047 |
|
Datasheet |
M2 | Tray | Active | Through Hole | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Round, Button | No Marking | Gray | - | - | PC Pin | - | Process Sealed | - | -30°C ~ 85°C |
|
FC7105P/B SWITCH DPDT MOM-SOLDER TAG |
3,149 |
|
Datasheet |
4066 | Bag | Active | Panel Mount, Rear | Standard | DPDT | On-Mom | 4A (AC) | 125 V | - | Round, Button | - | - | - | - | Solder Lug | - | - | - | -20°C ~ 65°C |
|
AB15AV/328SWITCH PUSH SPDT 0.4VA 28V |
4,905 |
|
Datasheet |
AB | Box | Active | Through Hole, Right Angle, Vertical | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Plunger for Cap | No Marking | White | - | - | PC Pin | - | Low Temperature Lubricant | - | -30°C ~ 85°C |
|
AB15BP-FASWITCH PUSH SPDT 0.4VA 28V |
1,395 |
|
Datasheet |
AB | Tray | Active | Through Hole | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Round, Button | No Marking | Black | - | - | PC Pin | - | Sealed - Fully | - | -30°C ~ 85°C |
|
EB2065-BBSWITCH PUSHBUTTON SPDT 3A 125V |
4,991 |
|
Datasheet |
EB | Bulk | Active | Panel Mount, Rear | Standard | SPDT | On-On | 3A (AC) | 125 V | - | Round, Button | No Marking | White | - | - | Solder Lug | - | Epoxy Sealed Terminals | Circular - 6.35mm Dia | -10°C ~ 70°C |
|
EB2065-BFSWITCH PUSHBUTTON SPDT 3A 125V |
4,266 |
|
Datasheet |
EB | Bulk | Active | Panel Mount, Rear | Standard | SPDT | On-On | 3A (AC) | 125 V | - | Round, Button | No Marking | Green | - | - | Solder Lug | - | Epoxy Sealed Terminals | Circular - 6.35mm Dia | -10°C ~ 70°C |
|
EB2065-BCSWITCH PUSHBUTTON SPDT 3A 125V |
2,365 |
|
Datasheet |
EB | Bulk | Active | Panel Mount, Rear | Standard | SPDT | On-On | 3A (AC) | 125 V | - | Round, Button | No Marking | Red | - | - | Solder Lug | - | Epoxy Sealed Terminals | Circular - 6.35mm Dia | -10°C ~ 70°C |
|
BH19NMUBXSWITCH PB SPST 1A 125VAC |
2,483 |
|
Datasheet |
BH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST | Off-Mom | 1A (AC), 2A (DC) | 125 V | 36 V | Round, Button | - | Blue | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | - | Circular - 19.00mm Dia | -25°C ~ 55°C |
|
5876KAILH MECHANICAL KEY SWITCHES - |
4,066 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
GB25AH-XASWITCH PUSH DPDT 0.4VA 28V |
2,416 |
|
Datasheet |
GB | Tray | Active | Through Hole, Right Angle | Standard | DPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Round, Button | No Marking | Black | - | - | PC Pin | - | - | - | -30°C ~ 85°C |
|
G3B15AB-S-XASWITCH PUSH SPDT 0.4VA 28V |
3,083 |
|
Datasheet |
G3B | Tube | Active | Surface Mount | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Round, Button | No Marking | Black | - | - | Gull Wing | - | Process Sealed | - | -30°C ~ 85°C |
|
|
BB25ABSWITCH PUSH DPDT 0.4VA 28V |
2,136 |
|
Datasheet |
BB | Bulk | Active | Through Hole | Standard | DPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Plunger for Cap | No Marking | White | - | - | PC Pin | - | Antistatic | - | -30°C ~ 85°C |
|
BH16NBSBOSWITCH PB SPST 1A 125VAC |
3,380 |
|
Datasheet |
BH | Tray | Active | Panel Mount, Front | Anti-Vandal, Illuminated | SPST | Off-Mom | 1A (AC), 2A (DC) | 125 V | 36 V | Round, Button, Flush | - | Silver | LED, Orange | 2 VDC | Solder Lug | IP67 - Dust Tight, Waterproof | Stainless Steel | Circular - 16.00mm Dia | -25°C ~ 55°C |
|
GB15AV-XBSWITCH PUSH SPDT 0.4VA 28V |
3,242 |
|
Datasheet |
GB | Tray | Active | Through Hole, Right Angle, Vertical | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Round, Button | No Marking | White | - | - | PC Pin | - | - | - | -30°C ~ 85°C |
|
FC71055P/B SWITCH DPDT ON/OFF/ST |
2,349 |
|
Datasheet |
4066 | Bag | Active | Panel Mount, Rear | Standard | DPDT | On-On | 4A (AC) | 125 V | - | Round, Button | - | - | - | - | Solder Lug | - | - | - | -20°C ~ 65°C |
|
M2B15AA5G13SWITCH PUSH SPDT 0.4VA 28V |
132 |
|
Datasheet |
M2 | Bulk | Active | Through Hole | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Plunger for Cap | No Marking | - | - | - | PC Pin | - | Process Sealed | - | -30°C ~ 85°C |
|
EB2085PSWITCH PUSHBUTTON DPDT 3A 125V |
3,677 |
|
Datasheet |
EB | Bulk | Active | Panel Mount, Rear | Standard | DPDT | On-On | 3A (AC) | 125 V | - | Plunger for Cap | No Marking | - | - | - | PC Pin | - | Epoxy Sealed Terminals | Circular - 6.35mm Dia | -10°C ~ 70°C |
