Pushbutton Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Marking | Color - Actuator/Cap | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Ingress Protection | Features | Panel Cutout Dimensions | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XB5FW36B5HARMONY XB5, ANTIMICROBIAL ILLUM |
1,510 |
|
Datasheet |
XB5F | Box | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO/NC | On-Off, Off-On | 6A (AC), 550mA (DC) | 120 V | 125 V | Round, Button, Flush | - | Blue | LED, Blue | 24 VAC/DC | Screw Terminal | IP66/IP67/IP69/IP69K - Dust Tight, Water Resistant, Waterproof | - | Circular - 30.50mm Dia | -40°C ~ 70°C |
|
XB5FW35M5HARMONY XB5, ANTIMICROBIAL ILLUM |
3,122 |
|
Datasheet |
XB5F | Box | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO/NC | On-Off, Off-On | 6A (AC), 550mA (DC) | 120 V | 125 V | Round, Button, Flush | - | Orange | LED, Orange | 220 ~ 240 VAC | Screw Terminal | IP66/IP67/IP69/IP69K - Dust Tight, Water Resistant, Waterproof | - | Circular - 30.50mm Dia | -40°C ~ 70°C |
|
XB5FW34M5HARMONY XB5, ANTIMICROBIAL ILLUM |
2,079 |
|
Datasheet |
XB5F | Box | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO/NC | On-Off, Off-On | 6A (AC), 550mA (DC) | 120 V | 125 V | Round, Button, Flush | - | Red | Neon, Red | 220 ~ 240 VAC | Screw Terminal | IP66/IP67/IP69/IP69K - Dust Tight, Water Resistant, Waterproof | - | Circular - 30.50mm Dia | -40°C ~ 70°C |
|
XB5FW35G5HARMONY XB5, ANTIMICROBIAL ILLUM |
4,029 |
|
Datasheet |
XB5F | Box | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO/NC | On-Off, Off-On | 6A (AC), 550mA (DC) | 120 V | 125 V | Round, Button, Flush | - | Orange | Neon, Orange | 110 ~ 120 VAC | Screw Terminal | IP66/IP67/IP69/IP69K - Dust Tight, Water Resistant, Waterproof | - | Circular - 30.50mm Dia | -40°C ~ 70°C |
|
XB5FW31G5HARMONY XB5, ANTIMICROBIAL ILLUM |
4,908 |
|
Datasheet |
XB5F | Box | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO/NC | On-Off, Off-On | 6A (AC), 550mA (DC) | 120 V | 125 V | Round, Button, Flush | - | White | Neon, White | 110 ~ 120 VAC | Screw Terminal | IP66/IP67/IP69/IP69K - Dust Tight, Water Resistant, Waterproof | - | Circular - 30.50mm Dia | -40°C ~ 70°C |
|
A3PJ-90C11-24EGSWITCH PUSHBUTTON DPDT 5A 125V |
4,485 |
|
Datasheet |
A3P | Bulk | Active | Panel Mount, Snap-In | Standard, Illuminated | DPDT | On-Mom | 5A (AC), 4A (DC) | 125 V | 30 V | Rectangular, Button | No Marking | Green | LED, Green | 24 VDC | Solder, Quick Connect - 0.110" (2.8mm) | IP40 | - | Rectangular - 30.50mm x 23.50mm | -10°C ~ 40°C |
|
A3KA-90C1-24EWPUSHBUTTON SWITCH |
2,047 |
|
Datasheet |
A3K | Box | Active | Panel Mount, Snap-In | Standard, Illuminated | SPDT | On-Mom | 3A (AC), 2A (DC) | 125 V | 30 V | Square, Button | - | White | LED, White | 24 VDC | Quick Connect - 0.110" (2.8mm) | IP00 | - | Square - 16.20mm x 16.20mm | -10°C ~ 50°C |
|
XB5AW73731G5HARMONY XB5, ILLUMINATED DOUBLE- |
2,661 |
|
Datasheet |
Harmony XB5 | Box | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO/NC | On-Off, Off-On | 6A (AC), 550mA (DC) | 120 V | 125 V | Rectangular, Button, Flush | - | Green | LED, Green | 110 ~ 120 VAC | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.00mm Dia | -40°C ~ 70°C |
|
XB5FW36G5HARMONY XB5, ANTIMICROBIAL ILLUM |
3,851 |
|
Datasheet |
XB5F | Box | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO/NC | On-Off, Off-On | 6A (AC), 550mA (DC) | 120 V | 125 V | Round, Button, Flush | - | Blue | Neon, Blue | 110 ~ 120 VAC | Screw Terminal | IP66/IP67/IP69/IP69K - Dust Tight, Water Resistant, Waterproof | - | Circular - 30.50mm Dia | -40°C ~ 70°C |
|
K30APPBXXQK30 SERIES EZ-LIGHT: NO COLOR PU |
3,951 |
|
Datasheet |
K30 | Box | Active | Panel Mount, Front | Standard, Illuminated | SPST-NO | Off-Mom | 150mA (DC) | - | 30 V | Round, Button, Domed | No Marking | - | - | - | Connector | IP65 - Dust Tight, Water Resistant | - | Circular - 22.00mm Dia | -40°C ~ 50°C |
|
84-ASKS-B14-04A0SWITCH PB 0.2A 32V CAPACITIVE |
2,771 |
|
Datasheet |
84 | Box | Active | Panel Mount, Front | Capacitive, Illuminated | - | - | 200mA (DC) | - | 32 V | Round, Button, Flush | - | - | LED, Green/Red | - | Connector | IP69K - Dust Tight, High Temp Water Jets, Waterproof | - | Circular - 22.50mm Dia | -30°C ~ 65°C |
|
84-ASKS-B10-049CSWITCH PB 0.2A 32V CAPACITIVE |
1,004 |
|
Datasheet |
84 | Box | Active | Panel Mount, Front | Capacitive, Illuminated | - | - | 200mA (DC) | - | 32 V | Round, Button, Flush | - | - | LED, Green/Red | - | Connector | IP69K - Dust Tight, High Temp Water Jets, Waterproof | - | Circular - 22.50mm Dia | -30°C ~ 65°C |
|
AV09C7L3D2406ESWITCH PUSH SPST-NO 0.05A 24V |
1,744 |
|
Datasheet |
AV | Bulk | Active | Panel Mount, Front | Anti-Vandal, Illuminated | SPST-NO | Off-Mom | 50mA (DC) | - | 24 V | Round, Button, Flush | No Marking | Silver | LED, Red | 2 VDC | Solder Lug | IP54 - Dust Protected, Water Resistant | - | Circular - 19.20mm Dia | -30°C ~ 70°C |
|
49SAP05PUSHBUTTON"A1" START-STOP |
3,777 |
|
Datasheet |
- | Box | Active | - | - | - | - | - | - | - | Round, Button | - | - | - | - | - | - | - | - | - |
|
AV22PNA62SWITCH PUSHBUTTON SPDT 5A 250V |
3,440 |
|
Datasheet |
AV | Bulk | Active | Panel Mount, Front | Anti-Vandal | SPDT | On-Mom | 5A (AC) | 250 V | - | Round, Button, Mushroom | No Marking | Red | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | Sealed - Fully | Circular - 22.20mm Dia | -20°C ~ 55°C |
|
AV09C7L3D2403ESWITCH PUSH SPST-NO 0.05A 24V |
1,374 |
|
Datasheet |
AV | Bulk | Active | Panel Mount, Front | Anti-Vandal, Illuminated | SPST-NO | Off-Mom | 50mA (DC) | - | 24 V | Round, Button, Flush | No Marking | Silver | LED, Green | 2 VDC | Solder Lug | IP54 - Dust Protected, Water Resistant | - | Circular - 19.20mm Dia | -30°C ~ 70°C |
|
AV22PNA24SWITCH PUSHBUTTON SPDT 5A 250V |
4,114 |
|
Datasheet |
AV | Bulk | Active | Panel Mount, Front | Anti-Vandal | SPDT | On-Mom | 5A (AC) | 250 V | - | Round, Button, Mushroom | No Marking | Black | - | - | Quick Connect - 0.110" (2.8mm) | IP67 - Dust Tight, Waterproof | Sealed - Fully | Circular - 22.20mm Dia | -20°C ~ 55°C |
|
|
1.22.251.242/3501SWITCH PUSHBUTTON DPST 100MA |
1,094 |
|
Datasheet |
- | Bulk | Active | Free Hanging | Standard | DPST-NO/NC | On-Mom, Off-Mom | 100mA (AC/DC) | - | - | Round, Button, Dual | No Marking | Red, Green | - | - | Connector | IP65 - Dust Tight, Water Resistant | Control Box Enclosure | - | -25°C ~ 70°C |
|
XB5AW3345HARMONY XB5, ILLUMINATED PUSH BU |
4,374 |
|
Datasheet |
Harmony XB5 | Box | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO/NC | On-Off, Off-On | 6A (AC), 550mA (DC) | 120 V | 125 V | Round, Button, Flush | - | Green | LED, Green | 220 ~ 240 VAC | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.00mm Dia | -40°C ~ 70°C |
|
84-ADKS-B13-04ADSWITCH PB 0.2A 32V CAPACITIVE |
3,709 |
|
Datasheet |
84 | Box | Active | Panel Mount, Front | Capacitive, Illuminated | - | - | 200mA (DC) | - | 32 V | Round, Button, Flush | - | - | LED, Green/Red | - | Connector | IP69K - Dust Tight, High Temp Water Jets, Waterproof | - | Circular - 22.50mm Dia | -30°C ~ 65°C |
