Pushbutton Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Marking | Color - Actuator/Cap | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Ingress Protection | Features | Panel Cutout Dimensions | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PB350STRYPUSHBUTTON, 30MA, SPST, PC PIN, |
100 |
|
Datasheet |
PB350 | Box | Active | Through Hole | Standard, Illuminated | SPST-NO | Off-Mom | 30mA (DC) | - | 28 V | Square, Button | - | Yellow | LED, Yellow | 2.2 VDC | PC Pin | - | - | - | -40°C ~ 85°C |
|
PB350STRWPUSHBUTTON, 30MA, SPST, PC PIN, |
2,929 |
|
Datasheet |
PB350 | Box | Active | Through Hole | Standard, Illuminated | SPST-NO | Off-Mom | 30mA (DC) | - | 28 V | Square, Button | - | White | LED, White | 3.2 VDC | PC Pin | - | - | - | -40°C ~ 85°C |
|
PB350STRGPUSHBUTTON, 30MA, SPST, PC PIN, |
1,444 |
|
Datasheet |
PB350 | Box | Active | Through Hole | Standard, Illuminated | SPST-NO | Off-Mom | 30mA (DC) | - | 28 V | Square, Button | - | Green | LED, Green | 3.2 VDC | PC Pin | - | - | - | -40°C ~ 85°C |
|
PB350DTRRPUSHBUTTON, 30MA, SPDT, PC PIN, |
100 |
|
Datasheet |
PB350 | Box | Active | Through Hole | Standard, Illuminated | SPDT | On-Mom | 30mA (DC) | - | 28 V | Square, Button | - | Red | LED, Red | 2.2 VDC | PC Pin | - | - | - | -40°C ~ 85°C |
|
PB350DTRBPUSHBUTTON, 30MA, SPDT, PC PIN, |
100 |
|
Datasheet |
PB350 | Box | Active | Through Hole | Standard, Illuminated | SPDT | On-Mom | 30mA (DC) | - | 28 V | Square, Button | - | Blue | LED, Blue | 3.2 VDC | PC Pin | - | - | - | -40°C ~ 85°C |
|
PB350DTRWPUSHBUTTON, 30MA, SPDT, PC PIN, |
100 |
|
Datasheet |
PB350 | Box | Active | Through Hole | Standard, Illuminated | SPDT | On-Mom | 30mA (DC) | - | 28 V | Square, Button | - | White | LED, White | 3.2 VDC | PC Pin | - | - | - | -40°C ~ 85°C |
|
PB350DTRGPUSHBUTTON, 30MA, SPDT, PC PIN, |
100 |
|
Datasheet |
PB350 | Box | Active | Through Hole | Standard, Illuminated | SPDT | On-Mom | 30mA (DC) | - | 28 V | Square, Button | - | Green | LED, Green | 3.2 VDC | PC Pin | - | - | - | -40°C ~ 85°C |
|
PB350DTRYPUSHBUTTON, 30MA, SPDT, PC PIN, |
100 |
|
Datasheet |
PB350 | Box | Active | Through Hole | Standard, Illuminated | SPDT | On-Mom | 30mA (DC) | - | 28 V | Square, Button | - | Yellow | LED, Yellow | 2.2 VDC | PC Pin | - | - | - | -40°C ~ 85°C |
|
EH12NMB7ZXSWITCH PB SPST-NO 2A 48V |
2,704 |
|
Datasheet |
EH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST-NO | Off-Mom | 2A (DC) | - | 48 V | Round, Button | - | Blue | - | - | Screw Terminal | IP67 - Dust Tight, Waterproof | - | Circular - 12.00mm Dia | -20°C ~ 70°C |
|
WBL2UOAYBQR05CLRSWITCH PUSHBUTTON DPDT 300MA 30V |
2,724 |
|
Datasheet |
WBL | Bulk | Active | Through Hole, Right Angle | Standard, Illuminated | DPDT | On-Mom | 300mA (DC) | - | 30 V | Round, Button | No Marking | Clear | LED, Blue/Yellow | 1.7, 3.5 VDC | PC Pin | - | - | - | -20°C ~ 70°C |
|
GB215AB-ASWITCH PUSH SPST-NO 0.4VA 28V |
4,356 |
|
Datasheet |
GB2 | Tray | Active | Through Hole | Standard | SPST-NO | Off-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Rectangular, Button | No Marking | Black | - | - | PC Pin | - | Epoxy Sealed Terminals | - | -25°C ~ 70°C |
|
GB215AH-CSWITCH PUSH SPST-NO 0.4VA 28V |
2,135 |
|
Datasheet |
GB2 | Tray | Active | Through Hole, Right Angle | Standard | SPST-NO | Off-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Rectangular, Button | No Marking | Red | - | - | PC Pin | - | Epoxy Sealed Terminals | - | -25°C ~ 70°C |
|
SPM1A7M9SWITCH PB SPST-NO 10A 250VAC |
3,097 |
|
Datasheet |
S | Bulk | Active | Panel Mount, Snap-In | Standard | SPST-NO | Off-Mom | 10A (AC/DC) | 125 V | 14 V | Square, Button | - | White | - | - | Quick Connect - 0.250" (6.3mm) | - | - | Rectangular - 27.94mm x 22.35mm | - |
|
BH16NMSZXSWITCH PB SPST 1A 125VAC |
4,539 |
|
Datasheet |
BH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST | Off-Mom | 1A (AC), 2A (DC) | 125 V | 36 V | Round, Button | - | Silver | - | - | Screw Terminal | IP67 - Dust Tight, Waterproof | Stainless Steel | Circular - 16.00mm Dia | -25°C ~ 55°C |
|
BH16NFGBXSWITCH PB SPST 1A 125VAC |
3,811 |
|
Datasheet |
BH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST | Off-Mom | 1A (AC), 2A (DC) | 125 V | 36 V | Round, Button, Flush | - | Green | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | - | Circular - 16.00mm Dia | -25°C ~ 55°C |
|
465031172506WS-PBTV PUSHBUTTON SWITCH |
3,547 |
|
Datasheet |
WS-PB | Tray | Active | Through Hole | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Plunger for Cap | No Marking | - | - | - | PC Pin | - | - | - | -40°C ~ 85°C |
|
GB215A2H-BCSWITCH PUSH 2XSPST-NO 0.4VA 28V |
3,014 |
|
Datasheet |
GB2 | Tray | Active | Through Hole, Right Angle | Standard | SPST-NO x 2 | Off-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Rectangular, Button | No Marking | Red, White | - | - | PC Pin | - | Epoxy Sealed Terminals | - | -25°C ~ 70°C |
|
EH12NMB7BXSWITCH PB SPST-NO 2A 48V |
3,795 |
|
Datasheet |
EH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST-NO | Off-Mom | 2A (DC) | - | 48 V | Round, Button | - | Blue | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | - | Circular - 12.00mm Dia | -20°C ~ 70°C |
|
EH12NMB4BXSWITCH PB SPST-NO 2A 48V |
1,951 |
|
Datasheet |
EH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST-NO | Off-Mom | 2A (DC) | - | 48 V | Round, Button | - | Yellow | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | - | Circular - 12.00mm Dia | -20°C ~ 70°C |
|
CTHS15CIC07ONOFFSWITCH PUSH CAPACITIVE ILLUM SQ |
100 |
|
Datasheet |
CTH | Tube | Active | Through Hole | Capacitive, Illuminated | - | Off-On | - | - | - | Square, Button | Power Symbol | Black | LED, Yellow | 3.2 VDC | PC Pin | - | - | - | - |
