Multiple Conductor Cables
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Cable Type | Number of Conductors | Wire Gauge | Conductor Strand | Conductor Material | Jacket (Insulation) Material | Jacket (Insulation) Diameter | Shield Type | Length | Jacket Color | Ratings | Features | Voltage | Operating Temperature | Usage | Jacket (Insulation) Thickness | Conductor Insulation | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
11700A 0021000CABLE CAT5E 8CON 24AWG RED |
1,069 |
|
Datasheet |
DataTuff® | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.285" (7.24mm) | - | 1000.0' (304.8m) | Red | UL Style CMR | Oil Resistant, Rip Cord, UV Resistant | 300 V | -40°C ~ 75°C | Industrial, Network | 0.0350" (0.889mm) | Polyolefin (PO) | - |
|
|
11700A 1NH1000CABLE CAT5E 8CON 24AWG |
3,996 |
|
Datasheet |
DataTuff® | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.285" (7.24mm) | - | 1000.0' (304.8m) | Teal | UL Style CMR | Oil Resistant, Rip Cord, UV Resistant | 300 V | -40°C ~ 75°C | Industrial, Network | 0.0350" (0.889mm) | Polyolefin (PO) | - |
|
|
57008 SL002CABLE 8COND 24AWG SLATE SHLD |
3,773 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 8 | 24 AWG | 7/32 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.167" (4.24mm) | Foil | 500.0' (152.4m) | Slate | - | - | 300 V | -5°C ~ 75°C | - | 0.0154" (0.390mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
8759 06010001 PR#20 PVC SHLD PVC |
1,878 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 2 (1 Pair Twisted) | 20 AWG | 7/28 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.199" (5.06mm) | Spiral | 1000.0' (304.8m) | Chrome | UL Style CMG | - | 300 V | -20°C ~ 80°C | Audio, Instrumentation | 0.0250" (0.635mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
8759 060U10001 PR #20 PVC SHLD PVC |
1,069 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 2 (1 Pair Twisted) | 20 AWG | 7/28 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.199" (5.06mm) | Spiral | 1000.0' (304.8m) | Chrome | UL Style CMG | - | 300 V | -20°C ~ 80°C | Audio, Instrumentation | 0.0250" (0.635mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
9451DP 009Z10002 FSPR #22 FEP PLENUM PVC |
2,714 |
|
Datasheet |
- | Bulk | Obsolete | Multi-Pair | 4 (2 Pair Twisted) | 22 AWG | 7/30 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.127" (3.23mm) | Foil | 1000.0' (304.8m) | White | - | - | 300 V | -20°C ~ 75°C | - | 0.0170" (0.432mm) | Fluorinated Ethylene-Propylene (FEP) | - |
|
|
CXA-0094-22-3/5/6/9CS2973CABLE 4COND 22AWG BLU/GRN/ORG/WH |
1,362 |
|
- |
- | Bulk | Active | Multi-Conductor | 4 (1 Twisted Quad) | 22 AWG | 19/34 | Copper, Tinned | - | 0.126" (3.20mm) | - | - | Blue, Green, Orange, White | - | - | 600 V | 150°C | - | - | Ethylene Tetrafluoroethylene (ETFE) | - |
|
|
8441 01050002 #22 PVC SH PVC |
1,669 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 2 (1 Pair Twisted) | 22 AWG | 7/30 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.194" (4.93mm) | Braid | 5000' (1524.0m) | Black | UL Style CMG | Drain Wire | 300 V | -20°C ~ 80°C | Audio, Control, Instrumentation | 0.0250" (0.635mm) | Poly-Vinyl Chloride (PVC) | - |
|
9462ZH 0101000CABLE 2COND 22AWG BLK SHLD |
3,261 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 2 (1 Pair Twisted) | 22 AWG | 7/30 | Copper, Tinned | Low Smoke Zero Halogen (LSZH) | - | Foil | 1000.0' (304.8m) | Black | UL Style 21307 | Drain Wire | 300 V | -20°C ~ 75°C | - | 0.0350" (0.889mm) | Polypropylene (PP) | - |
|
|
55A0124-26-0/955A0124-26-0/9 |
2,297 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
55A0124-26-6/955A0124-26-6/9 |
4,703 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
55A0124-28-6/955A0124-28-6/9 |
3,625 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
44AM4121-18-9/96-9CS2275CABLE 2COND 18AWG WHITE |
3,015 |
|
Datasheet |
- | Bulk | Active | Multi-Conductor | 2 | 18 AWG | 19/30 | Copper, Tinned | Polyvinylidene Fluoride (PVDF) | 0.146" (3.71mm) | - | - | White | - | - | 600 V | -55°C ~ 150°C | - | 0.0050" (0.127mm) | Polyvinylidene Fluoride (PVDF) | - |
|
|
M33505 SL199CABLE 5COND 18AWG SLATE 3000' |
3,202 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 5 | 18 AWG | 16/30 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.264" (6.71mm) | - | 3000' (914.4m) | Slate | UL Style 2509 | - | 300 V | -20°C ~ 80°C | - | 0.0250" (0.635mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
M38908 SL199CABLE 8COND 24AWG SLATE 3000' |
1,967 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 8 | 24 AWG | 7/32 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.213" (5.41mm) | - | 3000' (914.4m) | Slate | UL Style 2464 | - | 300 V | -20°C ~ 80°C | - | 0.0320" (0.813mm) | Poly-Vinyl Chloride (PVC) | - |
|
1552200001CABLE 3COND 24AWG BLACK 600M |
3,226 |
|
Datasheet |
Flamar 155220 | Bulk | Active | Multi-Conductor | 3 | 24 AWG | 32/0.0039" | Copper, Bare | Weld-Slag Oil Resistant (WSOR) | 0.177" (4.50mm) | - | 1968.5' (600.0m) | Black | UL Style 21215 | - | 600 V | -25°C ~ 80°C | Industrial, Signal, Control | 0.0098" (0.250mm) | Thermoplastic Elastomer (TPE) | - |
|
|
1552200004CABLE 3COND 24AWG GRAY 600M |
1,231 |
|
Datasheet |
Flamar 155220 | Bulk | Active | Multi-Conductor | 3 | 24 AWG | 32/0.0039" | Copper, Bare | Weld-Slag Oil Resistant (WSOR) | 0.177" (4.50mm) | - | 1968.5' (600.0m) | Gray | UL Style 21215 | - | 600 V | -25°C ~ 80°C | Industrial, Signal, Control | 0.0098" (0.250mm) | Thermoplastic Elastomer (TPE) | - |
|
|
1552200007CABLE 3COND 24AWG YELLOW 600M |
3,479 |
|
Datasheet |
Flamar 155220 | Bulk | Active | Multi-Conductor | 3 | 24 AWG | 32/0.0039" | Copper, Bare | Weld-Slag Oil Resistant (WSOR) | 0.177" (4.50mm) | - | 1968.5' (600.0m) | Yellow | UL Style 21215 | - | 600 V | -25°C ~ 80°C | Industrial, Signal, Control | 0.0098" (0.250mm) | Thermoplastic Elastomer (TPE) | - |
|
|
1552200010CABLE 3COND 24AWG ORANGE 600M |
4,701 |
|
Datasheet |
Flamar 155220 | Bulk | Active | Multi-Conductor | 3 | 24 AWG | 32/0.0039" | Copper, Bare | Weld-Slag Oil Resistant (WSOR) | 0.177" (4.50mm) | - | 1968.5' (600.0m) | Orange | UL Style 21215 | - | 600 V | -25°C ~ 80°C | Industrial, Signal, Control | 0.0098" (0.250mm) | Thermoplastic Elastomer (TPE) | - |
|
9409 0602500CABLE 2COND 18AWG CHROME |
4,067 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 2 (1 Pair) | 18 AWG | 19/30 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.230" (5.84mm) | - | 2500' (762.0m) | Chrome | UL Style 2464 | UV Resistant | - | -30°C ~ 105°C | Instrumentation | 0.0370" (0.940mm) | Poly-Vinyl Chloride (PVC) | - |
