Multiple Conductor Cables
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Cable Type | Number of Conductors | Wire Gauge | Conductor Strand | Conductor Material | Jacket (Insulation) Material | Jacket (Insulation) Diameter | Shield Type | Length | Jacket Color | Ratings | Features | Voltage | Operating Temperature | Usage | Jacket (Insulation) Thickness | Conductor Insulation | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1229A1 008U1000CAT3 4PR U/UTP CMR BOX |
3,883 |
|
Datasheet |
- | Box | Active | Multi-Pair, Cat3 | 8 (4 Pair) | 24 AWG | Solid | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.197" (5.00mm) | - | 1000.0' (304.8m) | Gray | UL Style CMR | - | 300 V | -20°C ~ 75°C | Network | - | Polyolefin (PO) | - |
|
|
1266A 008U10002 #22 PP FS PVC |
4,399 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 2 (1 Pair Twisted) | 22 AWG | 7/30 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.143" (3.63mm) | Foil | 1000.0' (304.8m) | Gray | - | Drain Wire | - | -20°C ~ 60°C | - | 0.0200" (0.508mm) | Polypropylene (PP) | - |
|
|
6303UE 8771000CABLE 5COND 18AWG NATURAL |
1,346 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 5 | 18 AWG | 7/26 | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.203" (5.16mm) | - | 1000.0' (304.8m) | Natural | UL Style CMP | Rip Cord | 300 V | 0°C ~ 75°C | Security, Sound | 0.0150" (0.381mm) | Low Smoke Poly-Vinyl Chloride (LSPVC) | - |
|
|
6200UE 877U1000CABLE 2COND 16AWG NATURAL |
4,537 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 2 | 16 AWG | 19/29 | Copper, Tinned | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.184" (4.67mm) | - | 1000.0' (304.8m) | Natural | UL Style CMP | Rip Cord | 300 V | 0°C ~ 75°C | Security, Sound | 0.0150" (0.381mm) | Low Smoke Poly-Vinyl Chloride (LSPVC) | - |
|
|
6508FE 877U1000CABLE 10COND 22AWG NATURAL |
1,645 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 10 | 22 AWG | 7/30 | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.222" (5.64mm) | Foil | 1000.0' (304.8m) | Natural | UL Style CMP | Rip Cord | 300 V | 0°C ~ 75°C | Security, Sound | 0.0150" (0.381mm) | Low Smoke Poly-Vinyl Chloride (LSPVC) | - |
|
|
M13304 SL199CABLE 4COND 22AWG SLATE 3000' |
1,616 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 4 | 22 AWG | 7/30 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.185" (4.70mm) | - | 3000' (914.4m) | Slate | UL Style 2576 | - | 300 V | -20°C ~ 80°C | Audio-Video, Home | 0.0320" (0.813mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
E2036S.18.10CABLE 6COND 18AWG GRAY SHLD 500' |
2,143 |
|
Datasheet |
- | Bulk | Active | Multi-Conductor | 6 | 18 AWG | 7/26 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.221" (5.61mm) | Foil | 500.0' (152.4m) | Gray | - | Drain Wire, Rip Cord | 300 V | -20°C ~ 75°C | Alarm, Security, Sound | 0.0150" (0.381mm) | Poly-Vinyl Chloride (PVC) | - |
|
M3233 SL001CABLE 3COND 20AWG SHLD |
4,869 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 3 | 20 AWG | 7/28 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.198" (5.03mm) | Foil | 1000.0' (304.8m) | Slate | UL Style 2093 | Drain Wire | 300 V | -20°C ~ 80°C | - | 0.0200" (0.508mm) | Polyethylene (PE) | - |
|
|
5301UH 0081000CABLE 3COND 18AWG GRAY |
4,916 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 3 | 18 AWG | 7/26 | Copper, Tinned | Poly-Vinyl Chloride (PVC), Riser | 0.167" (4.24mm) | - | 1000.0' (304.8m) | Gray | UL Style CMR | Rip Cord | 300 V | -20°C ~ 75°C | Security, Sound | 0.0170" (0.432mm) | Polypropylene (PP) | - |
|
|
5504G1 0101000CABLE 6COND 22AWG BLK SHLD |
4,974 |
|
Datasheet |
- | Spool | Active | Multi-Conductor | 6 (1 Pair Twisted) | 22 AWG | 7/30 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.268" (6.81mm) | Foil | 1000.0' (304.8m) | Black | - | Drain Wire, Rip Cord | 300 V | -20°C ~ 105°C | Security, Sound | 0.0250" (0.635mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
652402 SL001CABLE 2COND 24AWG SLATE |
1,123 |
|
Datasheet |
Xtra-Guard® Flex | Spool | Active | Multi-Conductor | 2 | 24 AWG | 7/32 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.212" (5.38mm) | - | 1000.0' (304.8m) | Slate | UL Style 2587 | Oil Resistant | 600 V | - | - | 0.0350" (0.889mm) | Poly-Vinyl Chloride (PVC) | - |
|
1585A 009U1000CABLE CAT5E 8CON 24AWG WHT |
1,692 |
|
Datasheet |
- | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.190" (4.83mm) | - | 1000.0' (304.8m) | White | UL Style CMP | Rip Cord | 300 V | -20°C ~ 75°C | Network | - | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | - |
|
1585A 0041000CABLE CAT5E 8COND 24AWG YL |
4,093 |
|
Datasheet |
- | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.190" (4.83mm) | - | 1000.0' (304.8m) | Yellow | UL Style CMP | Rip Cord | 300 V | -20°C ~ 75°C | Network | - | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | - |
|
|
1585A 0091000CABLE CAT5E 8CON 24AWG WHT |
2,388 |
|
Datasheet |
- | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.190" (4.83mm) | - | 1000.0' (304.8m) | White | UL Style CMP | Rip Cord | 300 V | -20°C ~ 75°C | Network | - | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | - |
|
|
1585A 0101000CABLE CAT5E 8CON 24AWG BLK |
2,661 |
|
Datasheet |
- | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.190" (4.83mm) | - | 1000.0' (304.8m) | Black | UL Style CMP | Rip Cord | 300 V | -20°C ~ 75°C | Network | - | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | - |
|
|
1585A 8771000CABLE CAT5E 8CON 24AWG NAT |
1,142 |
|
Datasheet |
- | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.190" (4.83mm) | - | 1000.0' (304.8m) | Natural | UL Style CMP | Rip Cord | 300 V | -20°C ~ 75°C | Network | - | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | - |
|
|
1585A D151000CABLE CAT5E 8CON 24AWG BLU |
4,726 |
|
Datasheet |
- | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.190" (4.83mm) | - | 1000.0' (304.8m) | Blue | UL Style CMP | Rip Cord | 300 V | -20°C ~ 75°C | Network | - | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | - |
|
|
1585A 002U1000CABLE CAT5E 8CON 24AWG RED |
3,206 |
|
Datasheet |
- | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.190" (4.83mm) | - | 1000.0' (304.8m) | Red | UL Style CMP | Rip Cord | 300 V | -20°C ~ 75°C | Network | - | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | - |
|
|
1585A 003U1000CABLE CAT5E 8COND 24AWG |
4,854 |
|
Datasheet |
- | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.190" (4.83mm) | - | 1000.0' (304.8m) | Orange | UL Style CMP | Rip Cord | 300 V | -20°C ~ 75°C | Network | - | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | - |
|
|
1585A 004U1000CABLE CAT5E 8COND 24AWG YL |
1,649 |
|
Datasheet |
- | Spool | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.190" (4.83mm) | - | 1000.0' (304.8m) | Yellow | UL Style CMP | Rip Cord | 300 V | -20°C ~ 75°C | Network | - | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) | - |
