Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2474R-47KFIXED IND 6.8MH 150MA 15 OHM TH |
4,403 |
|
Datasheet |
2474R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 6.8 mH | ±10% | 150 mA | 80mA | Unshielded | 15Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.240" Dia x 0.740" L (6.10mm x 18.80mm) | - |
|
|
2474R-48KFIXED IND 8.2MH 130MA 20.8OHM TH |
2,609 |
|
Datasheet |
2474R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 8.2 mH | ±10% | 130 mA | 70mA | Unshielded | 20.8Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.240" Dia x 0.740" L (6.10mm x 18.80mm) | - |
|
|
2474R-49KFIXED IND 10MH 120MA 23.4 OHM TH |
2,837 |
|
Datasheet |
2474R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 10 mH | ±10% | 120 mA | 60mA | Unshielded | 23.4Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.240" Dia x 0.740" L (6.10mm x 18.80mm) | - |
|
|
2474R-50KFIXED IND 12MH 120MA 26 OHM TH |
1,360 |
|
Datasheet |
2474R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 12 mH | ±10% | 120 mA | 60mA | Unshielded | 26Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.240" Dia x 0.740" L (6.10mm x 18.80mm) | - |
|
|
2474R-51KFIXED IND 15MH 100MA 36 OHM TH |
1,288 |
|
Datasheet |
2474R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 15 mH | ±10% | 100 mA | 50mA | Unshielded | 36Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.240" Dia x 0.740" L (6.10mm x 18.80mm) | - |
|
|
2474R-52KFIXED IND 18MH 90MA 40 OHM TH |
1,362 |
|
Datasheet |
2474R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 18 mH | ±10% | 90 mA | 50mA | Unshielded | 40Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.240" Dia x 0.740" L (6.10mm x 18.80mm) | - |
|
|
GA40-152KHIGH CURRENT AXIAL POWER CHOKE |
1,946 |
|
Datasheet |
GA40 | Axial | Tape & Reel (TR) | Active | Wirewound | Ferrite | 15 µH | ±10% | 4.547 mA | 7.34A | Unshielded | 22mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.450" Dia x 0.900" L (11.43mm x 22.86mm) | - |
|
HCF1007-R30-RFIXED IND 300NH 30A 0.9 MOHM SMD |
4,644 |
|
Datasheet |
HCF1007 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 300 nH | ±20% | 30 A | 48A | Unshielded | 0.9mOhm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.398" L x 0.307" W (10.10mm x 7.80mm) | 0.262" (6.65mm) |
|
CSBX1809-6R8MSMD HIGH CURRENT POWER INDUCTOR |
4,384 |
|
Datasheet |
CSBX1809 | Nonstandard | Active | Wirewound | Metal Composite | 6.8 µH | ±20% | 18.5 A | 31A | Shielded | 4.7mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.362" (9.20mm) | |
|
|
1330R-78HFIXED IND 270UH 47MA 25 OHM SMD |
2,987 |
|
Datasheet |
1330R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 270 µH | ±3% | 47 mA | - | Unshielded | 25Ohm Max | 30 @ 790kHz | 8MHz | - | -55°C ~ 105°C | 790 kHz | - | Surface Mount | - | 0.313" L x 0.115" W (7.95mm x 2.92mm) | 0.145" (3.68mm) |
|
|
1330R-80HFIXED IND 330UH 45MA 28 OHM SMD |
4,785 |
|
Datasheet |
1330R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 330 µH | ±3% | 45 mA | - | Unshielded | 28Ohm Max | 30 @ 790kHz | 7MHz | - | -55°C ~ 105°C | 790 kHz | - | Surface Mount | - | 0.313" L x 0.115" W (7.95mm x 2.92mm) | 0.145" (3.68mm) |
|
|
1330R-82HFIXED IND 390UH 40MA 35 OHM SMD |
1,965 |
|
Datasheet |
1330R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 390 µH | ±3% | 40 mA | - | Unshielded | 35Ohm Max | 30 @ 790kHz | 6.5MHz | - | -55°C ~ 105°C | 790 kHz | - | Surface Mount | - | 0.313" L x 0.115" W (7.95mm x 2.92mm) | 0.145" (3.68mm) |
|
|
1330R-84HFIXED IND 470UH 36MA 42 OHM SMD |
2,472 |
|
Datasheet |
1330R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 470 µH | ±3% | 36 mA | - | Unshielded | 42Ohm Max | 30 @ 790kHz | 6MHz | - | -55°C ~ 105°C | 790 kHz | - | Surface Mount | - | 0.313" L x 0.115" W (7.95mm x 2.92mm) | 0.145" (3.68mm) |
|
|
1330R-86HFIXED IND 560UH 35MA 46 OHM SMD |
1,463 |
|
Datasheet |
1330R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 560 µH | ±3% | 35 mA | - | Unshielded | 46Ohm Max | 30 @ 790kHz | 5MHz | - | -55°C ~ 105°C | 790 kHz | - | Surface Mount | - | 0.313" L x 0.115" W (7.95mm x 2.92mm) | 0.145" (3.68mm) |
|
|
1330R-88HFIXED IND 680UH 30MA 60 OHM SMD |
2,898 |
|
Datasheet |
1330R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 680 µH | ±3% | 30 mA | - | Unshielded | 60Ohm Max | 30 @ 790kHz | 4.2MHz | - | -55°C ~ 105°C | 790 kHz | - | Surface Mount | - | 0.313" L x 0.115" W (7.95mm x 2.92mm) | 0.145" (3.68mm) |
|
|
1330R-90HFIXED IND 820UH 29MA 65 OHM SMD |
1,104 |
|
Datasheet |
1330R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 820 µH | ±3% | 29 mA | - | Unshielded | 65Ohm Max | 30 @ 790kHz | 3.8MHz | - | -55°C ~ 105°C | 790 kHz | - | Surface Mount | - | 0.313" L x 0.115" W (7.95mm x 2.92mm) | 0.145" (3.68mm) |
|
|
1330R-92HFIXED IND 1MH 28MA 72 OHM SMD |
3,826 |
|
Datasheet |
1330R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 1 mH | ±3% | 28 mA | - | Unshielded | 72Ohm Max | 30 @ 790kHz | 3.4MHz | - | -55°C ~ 105°C | 790 kHz | - | Surface Mount | - | 0.313" L x 0.115" W (7.95mm x 2.92mm) | 0.145" (3.68mm) |
|
IHSM4825ER181LFIXED IND 180UH 500MA 1.37OHM SM |
2,820 |
|
Datasheet |
IHSM-4825 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 180 µH | ±15% | 500 mA | 350mA | Unshielded | 1.37Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.540" L x 0.250" W (13.72mm x 6.35mm) | 0.225" (5.72mm) |
|
|
IHSM4825ER102LFIXED IND 1MH 240MA 6.9 OHM SMD |
1,622 |
|
Datasheet |
IHSM-4825 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 1 mH | ±15% | 240 mA | 150mA | Unshielded | 6.9Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.540" L x 0.250" W (13.72mm x 6.35mm) | 0.225" (5.72mm) |
|
|
DB1-821RADIAL POWR LINE CHOKE |
2,649 |
|
Datasheet |
DB1 | Radial, Vertical Cylinder (Open) | Bulk | Active | Wirewound | Ferrite | 8.2 µH | ±20% | 9 A | 24.5A | Unshielded | 8mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 0.650" Dia (16.51mm) | 0.712" (18.08mm) |
