LED Driver Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Current - Output / Channel | Outputs and Type | Voltage - Output | Features | Voltage - Input | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AL8805EV1 |
10 |
|
- |
- | Box | Not For New Designs | 680mA | 1 Non-Isolated Output | - | Dimmable | 6V ~ 30V | Board(s) | AL8805 |
|
AL8805EV2 |
8 |
|
- |
- | Box | Not For New Designs | 680mA | 1 Non-Isolated Output | - | - | 12VAC, 12V ~ 20V | Board(s) | AL8805 |
|
STEVAL-ILL037V1 |
7 |
|
Datasheet |
- | Box | Active | 200mA | 1 Isolated Output | 16V | - | 90 ~ 265 VAC | Board(s) | HVLED805 |
|
AL5809EV1-150 |
5 |
|
Datasheet |
- | Box | Active | 150mA | 1 Non-Isolated Output | - | Dimmable | 2.5V ~ 60V | Board(s) | AL5809 |
|
IS31FL3293-UTLS4-EB |
10 |
|
Datasheet |
- | Box | Active | 20mA | 3 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3293 |
|
MAX16824EVKIT+ |
6 |
|
Datasheet |
- | Box | Active | 100mA | 3 Non-Isolated Outputs | 26.3V | Dimmable | 6.5V ~ 28V | Board(s) | MAX16824 |
|
EVB_RT4531WSC |
9 |
|
Datasheet |
- | Bulk | Active | 20mA | 2 Non-Isolated Outputs | 31V | Dimmable | 2.5V ~ 5.5V | Board(s) | RT4531 |
|
EVB_RT8555WSC |
10 |
|
Datasheet |
- | Box | Active | 20mA | 6 Non-Isolated Outputs | 36V | Dimmable | 2.7V ~ 24V | Board(s) | RT8555 |
|
AL5809EV1-60 |
7 |
|
Datasheet |
- | Box | Active | 60mA | 1 Non-Isolated Output | - | Dimmable | 2.5V ~ 60V | Board(s) | AL5809 |
|
AL8806EV6 |
5 |
|
- |
- | Box | Not For New Designs | 1.1A | 1 Non-Isolated Output | - | - | 9V ~ 30V | Board(s) | AL8806 |
|
EVB_RT7304GE_03 |
8 |
|
Datasheet |
- | Bulk | Active | - | 1 Isolated Output | - | - | 90 ~ 264 VAC | Board(s) | RT7304 |
|
EVB_RT4832AWSC |
6 |
|
Datasheet |
- | Bulk | Active | - | - | - | - | 2.5V ~ 5.5V | Board(s) | RT4832A |
|
|
DEMOBOARDTLE4242GTOBO1 |
10 |
|
Datasheet |
LITIX™ | Box | Not For New Designs | 370mA | 1 Non-Isolated Output | 6V ~ 8V | - | 8V ~ 16V | Board(s) | TLE4242G |
|
|
STEVAL-ILL062V1 |
6 |
|
Datasheet |
- | Box | Active | - | 32 Non-Isolated Outputs | - | - | 6V ~ 24V | Board(s) | L7981D, STP16CPC26, STM8S |
|
EVB_RT4532WSC |
9 |
|
Datasheet |
- | Box | Active | - | 2 Isolated Outputs | 17V | Dimmable | 2.5V ~ 5.5V | Board(s) | RT4532 |
|
EVB_RT8498GE |
7 |
|
Datasheet |
- | Bulk | Active | 1A | 1 Non-Isolated Output | 3V | Dimmable | 4.5V ~ 18V | Board(s) | RT8498 |
|
|
STEVAL-ILL003V2 |
9 |
|
Datasheet |
- | Bulk | Active | 100mA | 32 Non-Isolated Outputs | 4V | Dimmable | 5V ~ 35V | Board(s) | STP16CP05 |
|
AL8806EV1 |
10 |
|
- |
- | Box | Not For New Designs | 1.5A | 1 Non-Isolated Output | - | Dimmable | 9V ~ 30V | Board(s) | AL8806 |
|
AL8806EV4 |
8 |
|
- |
- | Box | Not For New Designs | 1.5A | 1 Non-Isolated Output | - | Dimmable | 9V ~ 30V | Board(s) | AL8806 |
|
EV3318-C-00A |
5 |
|
Datasheet |
- | Box | Active | 25mA | 3 Non-Isolated Outputs | 38V | Dimmable | 2.7V ~ 5.5V | Board(s) | MP3318 |
