LED Driver Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Current - Output / Channel | Outputs and Type | Voltage - Output | Features | Voltage - Input | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CCR120PS3AGEVB |
8 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | - | - | 100 ~ 130 VAC | Board(s) | NSIC2030B, NSIC2050B |
|
60WLEDBULBGEVB |
5 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | - | Dimmable | 100 ~ 140 VAC | Board(s) | NSIC2030JBT3G, NSIC2050JBT3G |
|
MAX20090BEVKIT# |
7 |
|
Datasheet |
- | Box | Active | 1A | 1 Non-Isolated Output | 3V ~ 24V | Dimmable | 6V ~ 18V | Board(s) | MAX20090B |
|
NCV7681AGEVB |
8 |
|
Datasheet |
- | Box | Active | 100mA | 8 Non-Isolated Outputs | - | - | 28V | Board(s) | NCV7681 |
|
NCV7681LGEVB |
5 |
|
Datasheet |
- | Box | Active | 100mA | 8 Non-Isolated Outputs | - | - | 28V | Board(s) | NCV7681 |
|
|
NCV7680PWR2GEVB |
5 |
|
Datasheet |
- | Box | Active | - | 8 Non-Isolated Outputs | - | Dimmable | - | Board(s) | NCV7680 |
|
DC986A |
7 |
|
Datasheet |
- | Box | Active | 500mA | 3 Non-Isolated Outputs | 31V | Dimmable | 45V | Board(s) | LT3496 |
|
CCR120PS3GEVK |
9 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | - | - | 100 ~ 130 VAC | Board(s) | NSIC2030B, NSIC2050B |
|
CCR230PS3AGEVB |
7 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | - | - | 200 ~ 240 VAC | Board(s) | NSIC2030B, NSIC2050B |
|
|
LP3943ISQEV |
8 |
|
Datasheet |
- | Bulk | Active | 25mA | 16 Non-Isolated Outputs | 4V | Dimmable | 2.3V ~ 5.5V | Board(s) | LP3943 |
|
LM3424BKBSTEVAL/NOPB |
8 |
|
Datasheet |
- | Box | Active | 1A | 1 Non-Isolated Output | - | Dimmable | 10V ~ 70V | Board(s) | LM3424 |
|
LM3424BSTEVAL/NOPB |
9 |
|
Datasheet |
- | Box | Active | 1A | 1 Non-Isolated Output | - | Dimmable | 10V ~ 26V | Board(s) | LM3424 |
|
NCL2801LED2GEVB |
5 |
|
Datasheet |
- | Bulk | Active | 1.5A | 1 Non-Isolated Output | 50V | Dimmable | 90 ~ 305 VAC | Board(s) | NCL2801, NCP13992 |
|
EVAL-LT8374-1-AZ |
5 |
|
Datasheet |
- | Box | Active | 1A | 1 Non-Isolated Output | 15V | Dimmable | 18V ~ 47V | Board(s) | LT8374-1 |
|
DC773A |
9 |
|
Datasheet |
- | Box | Active | 1A | 1 Non-Isolated Output | 3.9V | Dimmable | 3V ~ 4.2V | Board(s) | LTC3441 |
|
NCV7691GEVK |
5 |
|
Datasheet |
- | Box | Active | - | 3 Non-Isolated Outputs | - | Dimmable | 7V ~ 16V | Board(s) | NCV7691 |
|
NCV7692DRLV1GEVB |
10 |
|
Datasheet |
- | Box | Active | 540mA | 1 Non-Isolated Output | - | - | 7V ~ 40V | Board(s) | NCV7692 |
|
NCV7694GEVB |
8 |
|
Datasheet |
- | Box | Active | 3A | 1 Non-Isolated Output | 11.8V | - | 8V ~ 18V | Board(s) | NCV7694 |
|
MAX25201EVKIT# |
5 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | 4.5V ~ 60V | - | 4.5V ~ 42V | Board(s) | MAX25201 |
|
CCR230PS3GEVK |
5 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | - | - | 200 ~ 240 VAC | Board(s) | NSIC2030B, NSIC2050B |
