LED Driver Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Current - Output / Channel | Outputs and Type | Voltage - Output | Features | Voltage - Input | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EV3313-C-00A |
5 |
|
Datasheet |
- | Box | Active | 25mA | 3 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | MP3313 |
|
STEVAL-ILL039V2 |
6 |
|
Datasheet |
- | Bulk | Active | 400mA | 1 Non-Isolated Output | - | Dimmable | 0.8V ~ 3.6V | Board(s) | STLDC08 |
|
OM13528UL |
8 |
|
Datasheet |
- | Bulk | Active | - | 16 Non-Isolated Outputs | - | Dimmable | - | Board(s) | PCA9532 |
|
EVB_RT8497GS |
9 |
|
Datasheet |
- | Box | Active | 150mA | 1 Non-Isolated Output | 60V | - | 90 ~ 264 VAC | Board(s) | RT8497 |
|
EVB_RT8494GS |
9 |
|
- |
- | Box | Active | - | 1 Non-Isolated Output | - | Dimmable | 4.5V ~ 36V | Board(s) | RT8494 |
|
EVB_RT8497AGS |
9 |
|
Datasheet |
- | Box | Active | 230mA | 1 Non-Isolated Output | 78V | - | 90 ~ 264 VAC | Board(s) | RT8497A |
|
AS1111A-WL_EK_ST |
9 |
|
Datasheet |
- | Box | Active | 80mA | 2 Non-Isolated Outputs | - | Dimmable | - | Board(s) | AS1111A |
|
EV3305DD-00A |
10 |
|
Datasheet |
- | Box | Active | 200A | 3 Non-Isolated Outputs | - | Dimmable | 5V | Board(s) | MP3305 |
|
EVQ2489-Q-00A |
8 |
|
Datasheet |
- | Box | Active | 500mA | 1 Non-Isolated Output | - | Dimmable | 9V ~ 24V | Board(s) | MPQ2489 |
|
EVQ2483-Q-00A |
7 |
|
Datasheet |
- | Box | Active | 2.5A | 1 Non-Isolated Output | - | Dimmable | 4.5V ~ 55V | Board(s) | MPQ2483 |
|
EV3302-J-01A |
5 |
|
Datasheet |
- | Box | Active | 1.3A | 1 Non-Isolated Output | - | Dimmable | 3.3V ~ 6V | Board(s) | MP3302 |
|
EV3304DD-00A |
8 |
|
Datasheet |
- | Box | Active | 200mA | 3 Non-Isolated Outputs | - | Dimmable | 5V | Board(s) | MP3304 |
|
EVQ2483-S-00A |
7 |
|
Datasheet |
- | Box | Active | 700mA | 4 Non-Isolated Outputs | - | Dimmable | 4.5V ~ 55V | Board(s) | MPQ2483 |
|
EV4057A-K-00A |
7 |
|
Datasheet |
- | Box | Active | 370mA | 1 Non-Isolated Output | 21V | Dimmable | 198 ~ 265 VAC | Board(s) | MP4057A |
|
STEVAL-ILL045V1 |
10 |
|
Datasheet |
- | Bulk | Active | - | 1 Non-Isolated Output | - | Dimmable | 90 ~ 132 VAC | Board(s) | HVLED815PF |
|
EVB_RT7310GE_03 |
6 |
|
Datasheet |
- | Bulk | Active | - | 1 Non-Isolated Output | - | Dimmable | 90 ~ 132 VAC | Board(s) | RT7310 |
|
EVB_RT7310GE_01 |
6 |
|
- |
- | Bulk | Active | - | 1 Non-Isolated Output | - | Dimmable | 90 ~ 132 VAC | Board(s) | RT7310 |
|
EVB_RT7306+RFID |
8 |
|
Datasheet |
- | Box | Active | - | 1 Isolated Output | - | Dimmable | 90 ~ 264 VAC | Board(s) | RT7306 |
|
EVB_RT7302GS |
10 |
|
Datasheet |
- | Bulk | Active | - | 1 Isolated Output | - | Dimmable | 90 ~ 264 VAC | Board(s) | RT7302 |
|
EVB_RT7310GE_02 |
5 |
|
Datasheet |
- | Bulk | Active | - | 1 Non-Isolated Output | - | Dimmable | 90 ~ 132 VAC | Board(s) | RT7310 |
