Omron Automation and Safety TZ-1GV22
- Part No.:
- TZ-1GV22
- Manufacturer:
- Omron Automation and Safety
- Category:
- Limit Switches
- Package:
- Datasheet:
-
TZ-1GV22.pdf
- Description:
- SWITCH SNAP ACTION SPDT 1A 125V
- Quantity:
- Payment:

- Shipping:

Inventory:3,731
Please send an inquiry. Send us your inquiry, and we will respond immediately.
- Specifications
- FAQ
- Product Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Omron Automation and Safety
- Series:
- TZ
- Packaging:
- Tray
- Product Status:
- Active
- Circuit:
- SPDT
- Switch Function:
- On-Mom
- Current Rating (Amps):
- 1A (AC/DC)
- Voltage Rating - AC:
- 125 V
- Voltage Rating - DC:
- 30 V
- Actuator Type:
- Lever, Roller
- Mounting Type:
- Chassis Mount
- Termination Style:
- Screw Terminal
- Ingress Protection:
- IP00
- Features:
- -
- Operating Force:
- 240gf
- Release Force:
- 35gf
- Operating Position:
- 1.125" (28.6mm)
- Pretravel:
- 0.060" (1.5mm)
- Differential Travel:
- 0.025" (0.6mm)
- Overtravel:
- 0.075" (1.9mm)
- Operating Temperature:
- -65°C ~ 400°C
