Texas Instruments LP8550TLX-E00/NOPB
- Part No.:
- LP8550TLX-E00/NOPB
- Manufacturer:
- Texas Instruments
- Category:
- LED Drivers
- Package:
- 25-WFBGA, DSBGA
- Datasheet:
-
LP8550TLX-E00/NOPB.pdf
- Description:
- PROTOTYPE
- Quantity:
- Payment:

- Shipping:

Inventory:3,953
Please send an inquiry. Send us your inquiry, and we will respond immediately.
- Specifications
- FAQ
- Product Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Texas Instruments
- Series:
- -
- Package/Case:
- 25-WFBGA, DSBGA
- Packaging:
- Bulk
- Product Status:
- Active
- Type:
- DC DC Regulator
- Topology:
- Step-Up (Boost)
- Internal Switch(s):
- Yes
- Number of Outputs:
- 6
- Voltage - Supply (Min):
- 2.7V
- Voltage - Supply (Max):
- 22V
- Voltage - Output:
- 10V ~ 40V
- Current - Output / Channel:
- 50mA
- Frequency:
- 156kHz, 312kHz, 625kHz, 1.25MHz
- Dimming:
- Analog, I2C, PWM
- Applications:
- LED Lighting
- Operating Temperature:
- -30°C ~ 85°C (TA)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 25-DSBGA
