Panasonic Electric Works CP1-12V
- Part No.:
- CP1-12V
- Manufacturer:
- Panasonic Electric Works
- Category:
- Automotive Relays
- Package:
- Datasheet:
-
CP1-12V.pdf
- Description:
- RELAY AUTOMOTIVE SPDT 20A 12V
- Quantity:
- Payment:

- Shipping:

Inventory:3,638
Please send an inquiry. Send us your inquiry, and we will respond immediately.
- Specifications
- FAQ
- Product Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Panasonic Electric Works
- Series:
- CP
- Packaging:
- Tube
- Product Status:
- Active
- Coil Type:
- Non Latching
- Coil Current:
- 53.3 mA
- Coil Voltage:
- 12VDC
- Contact Form:
- SPDT (1 Form C)
- Contact Rating (Current):
- 20 A
- Switching Voltage:
- 14VDC - Nom
- Must Operate Voltage:
- 7.2 VDC
- Must Release Voltage:
- 1 VDC
- Operate Time:
- 10 ms
- Release Time:
- 10 ms
- Features:
- Sealed - Fully
- Mounting Type:
- Through Hole
- Termination Style:
- PC Pin
- Operating Temperature:
- -40°C ~ 85°C
