Lite-On Inc. 6N137
- Part No.:
- 6N137
- Manufacturer:
- Lite-On Inc.
- Category:
- Logic Output Optoisolators
- Package:
- 8-DIP (0.300", 7.62mm)
- Datasheet:
-
6N137.pdf
- Description:
- OPTOISO 5KV 1CH OPEN COLL 8DIP
- Quantity:
- Payment:
- Shipping:
Inventory:1,330
Please send an inquiry. Send us your inquiry, and we will respond immediately.
- Specifications
- FAQ
- Product Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Lite-On Inc.
- Series:
- -
- Package/Case:
- 8-DIP (0.300", 7.62mm)
- Packaging:
- Tube
- Product Status:
- Active
- Number of Channels:
- 1
- Inputs - Side 1/Side 2:
- 1/0
- Voltage - Isolation:
- 5000Vrms
- Common Mode Transient Immunity (Min):
- 10kV/µs
- Input Type:
- DC
- Output Type:
- Open Collector
- Current - Output / Channel:
- 50 mA
- Data Rate:
- 10MBd
- Propagation Delay tpLH / tpHL (Max):
- 75ns, 75ns
- Rise / Fall Time (Typ):
- 22ns, 6.9ns
- Voltage - Forward (Vf) (Typ):
- 1.38V
- Current - DC Forward (If) (Max):
- 20mA
- Voltage - Supply:
- 7V
- Grade:
- -
- Qualification:
- -
- Operating Temperature:
- -40°C ~ 85°C
- Mounting Type:
- Through Hole
- Supplier Device Package:
- 8-DIP
