LED Driver Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Current - Output / Channel | Outputs and Type | Voltage - Output | Features | Voltage - Input | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NCL30186SMRTGEVB |
6 |
|
Datasheet |
- | Bulk | Active | 100mA | 1 Non-Isolated Output | 40V ~ 80V | Dimmable | 100 ~ 265 VAC | Board(s) | NCL30186 |
|
HV9922DB1 |
10 |
|
Datasheet |
- | Box | Active | 50mA | 1 Non-Isolated Output | - | - | 80 ~ 265 VAC | Board(s) | HV9922 |
|
HV9912DB1 |
10 |
|
Datasheet |
- | Box | Active | 350mA | 1 Non-Isolated Output | 35V ~ 80V | Dimmable | 21V ~ 27V | Board(s) | HV9912 |
|
IS31FL3194-CLS2-EB |
10 |
|
Datasheet |
- | Bulk | Active | 40mA | 3 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3194 |
|
IS31FL3196A-QFLS2-EB |
10 |
|
Datasheet |
- | Bulk | Active | 40mA | 6 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3196A |
|
IS31LT3948-GRLS4-EB |
9 |
|
Datasheet |
- | Bulk | Active | 2A | 1 Non-Isolated Output | - | Dimmable | 5V ~ 100V | Board(s) | IS31LT3948 |
|
IS31LT3954A-GRLS4-EB |
6 |
|
Datasheet |
- | Bulk | Active | 3A | 1 Non-Isolated Output | - | Dimmable | 4.5V ~ 38V | Board(s) | IS31LT3954A |
|
IS31LT3957-ZLS4-EBBOOST |
7 |
|
Datasheet |
- | Bulk | Active | - | 1 Non-Isolated Output | - | Dimmable | 5V ~ 75V | Board(s) | IS31LT3957 |
|
IS32LT3126-ZLA3-EB |
10 |
|
Datasheet |
- | Bulk | Active | 150mA | 2 Non-Isolated Outputs | - | Dimmable | 5V ~ 42V | Board(s) | IS32LT3126 |
|
IS32LT3952-GRLA3-EB |
6 |
|
Datasheet |
- | Bulk | Active | 1.5A | 1 Non-Isolated Output | - | Dimmable | 4.5V ~ 40V | Board(s) | IS32LT3952 |
|
IS32LT3954-GRLA3-EB |
8 |
|
Datasheet |
- | Bulk | Active | 3A | 1 Non-Isolated Output | - | Dimmable | 4.5V ~ 40V | Board(s) | IS32LT3954 |
|
EV4027-J-01A |
6 |
|
Datasheet |
- | Box | Active | 350mA | 1 Non-Isolated Output | 20V | Dimmable | 90 ~ 265 VAC | Board(s) | MP4027 |
