LED Driver Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Current - Output / Channel | Outputs and Type | Voltage - Output | Features | Voltage - Input | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
IS31LT3360-SDLS3-EB3CH |
6 |
|
Datasheet |
- | Box | Active | - | - | - | Dimmable | 6V ~ 40V | Board(s) | IS31LT3360 |
|
IS31BL3506A-TTLS2-EB |
5 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | - | - | 2.7V ~ 5.5V | Board(s) | IS31BL3506A |
|
IS31FL3731-QFLS2-EB |
7 |
|
Datasheet |
- | Box | Active | - | - | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3731 |
|
|
IS31LT3350-V1SDLS2-EB3CH |
10 |
|
Datasheet |
- | Box | Active | - | - | - | Dimmable | 6V ~ 40V | Board(s) | IS31LT3350 |
|
|
IS31LT3352-V1GRLS2-EBMR16 |
5 |
|
Datasheet |
- | Box | Active | - | - | - | Dimmable | 6V ~ 40V | Board(s) | IS31LT3352 |
|
MIC2297-42YML-EV |
8 |
|
Datasheet |
- | Bulk | Active | 20mA | 1 Non-Isolated Output | 42V | - | 2.5V ~ 10V | Board(s) | MIC2297 |
|
AN30888A-EVB-0 |
5 |
|
- |
- | Box | Active | - | 1 Non-Isolated Output | - | Dimmable | 3V ~ 20V | Board(s) | AN30888A |
|
IX9908-EVAL |
9 |
|
- |
- | Box | Active | 600mA | 1 Isolated Output | 19V ~ 26V | Dimmable | 90 ~ 135 VAC | Board(s) | IX9908 |
|
FEBFAN7631-L17U120A-GEVB |
8 |
|
Datasheet |
- | Box | Active | 2.4A | 1 Isolated Output | 50V | Dimmable | 85 ~ 300 VAC | Board(s) | FAN7631, FAN73402, FL7930C, FSL117MRIN |
|
CAT4104AGEVB |
5 |
|
Datasheet |
- | Box | Active | 175mA | 4 Non-Isolated Outputs | - | - | 3V ~ 5.5V | Board(s) | CAT4104 |
|
CAT4106AGEVB |
5 |
|
Datasheet |
- | Box | Active | 175mA | 4 Non-Isolated Outputs | 36V | Dimmable | 3V ~ 5.5V | Board(s) | CAT4106 |
|
LV52204MUGEVB |
10 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | - | Dimmable | 2.7V ~ 5.5V | Board(s) | LV52204 |
|
NCL30002DIM1GEVB |
6 |
|
Datasheet |
- | Box | Active | 750mA | 1 Non-Isolated Output | 22V ~ 26V | Dimmable | 100 ~ 132 VAC | Board(s) | NCL30002 |
|
NCL30002DIM2GEVB |
6 |
|
Datasheet |
- | Box | Active | 750mA | 1 Non-Isolated Output | 22V ~ 26V | Dimmable | 200 ~ 265 VAC | Board(s) | NCL30002 |
|
NCL30002LED1GEVB |
9 |
|
Datasheet |
- | Box | Active | 750mA | 1 Non-Isolated Output | 22V ~ 26V | - | 100 ~ 132 VAC | Board(s) | NCL30002 |
|
NCL30002LED2GEVB |
5 |
|
Datasheet |
- | Box | Active | 750mA | 1 Non-Isolated Output | 22V ~ 26V | - | 200 ~ 265 VAC | Board(s) | NCL30002 |
|
NCL30086SMRTGEVB |
7 |
|
Datasheet |
- | Box | Active | 100mA | 1 Non-Isolated Output | 40V ~ 80V | Dimmable | 100 ~ 265 VAC | Board(s) | NCL30086 |
|
NCL30088LED1GEVB |
8 |
|
Datasheet |
- | Box | Active | 100mA | 1 Non-Isolated Output | 90V ~ 180V | - | 100 ~ 277 VAC | Board(s) | NCL30088 |
|
|
EVB_RT4533AGJ6 |
6 |
|
Datasheet |
- | Bulk | Active | 20mA | 1 Non-Isolated Output | 36.5V | Dimmable | 2.5V ~ 5.5V | Board(s) | RT4533A |
|
|
IS31FL3730-QFLS2-EB |
8 |
|
Datasheet |
- | Bulk | Active | - | - | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3730 |
