LED Driver Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Current - Output / Channel | Outputs and Type | Voltage - Output | Features | Voltage - Input | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IS32LT3961-ZLA3-EB |
5 |
|
Datasheet |
- | Box | Active | 2A | 1 Non-Isolated Output | - | Dimmable | 5V ~ 60V | Board(s) | IS32LT3961 |
|
IS32LT3965-QWCLA3-EB |
9 |
|
Datasheet |
- | Box | Active | 1.5A | 1 Non-Isolated Output | - | Dimmable | 4V ~ 38V | Board(s) | IS32LT3965 |
|
IS32LT3140B-GRLA3-EB |
5 |
|
Datasheet |
- | Box | Active | 450mA | 1 Non-Isolated Output | - | Dimmable | 4.5V ~ 40V | Board(s) | IS32LT3140B |
|
IS31FL3294-UTLS4-EB |
9 |
|
Datasheet |
- | Box | Active | 40mA | 4 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3294 |
|
KTD2052AEVAA-MMEV01 |
10 |
|
Datasheet |
- | Bulk | Active | 24mA | 12 Non-Isolated Outputs | - | Dimmable | 2.5V ~ 5.5V | Board(s) | KTD2052A |
|
IS31FL3726A-ZLS4-EB |
6 |
|
Datasheet |
- | Box | Active | 60mA | 16 Non-Isolated Outputs | - | Dimmable | 3V ~ 5.5V | Board(s) | IS31FL3726A |
|
IS31FL3296-QFLS4-EB |
8 |
|
Datasheet |
- | Box | Active | 40mA | 6 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3296 |
|
IS31FL3299-QFLS4-EB |
9 |
|
Datasheet |
- | Box | Active | 40mA | 9 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3299 |
|
IS32FL3248-QWLA3-EB |
8 |
|
Datasheet |
- | Bulk | Active | 33mA | 48 Non-Isolated Outputs | - | - | 3V ~ 5.5V | Board(s) | IS32FL3248 |
|
IS31FL3265A-ZLS4-EB |
10 |
|
Datasheet |
- | Box | Active | 60mA | 18 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3265A |
|
AP8801EV2 |
7 |
|
Datasheet |
- | Bulk | Active | 460mA | 1 Non-Isolated Output | - | Dimmable | 8V ~ 45V | Board(s) | AP8801 |
|
NCL30083BB1GEVB |
8 |
|
Datasheet |
- | Box | Active | 195mA | 1 Non-Isolated Output | 30V ~ 60V | Dimmable | 100 ~ 265 VAC | Board(s) | NCL30083 |
|
NCL30083FLYGEVB |
6 |
|
Datasheet |
- | Box | Active | 500mA | 1 Isolated Output | 9.6V ~ 22.1V | Dimmable | 100 ~ 265 VAC | Board(s) | NCL30083 |
|
NCL30073LED2GEVB |
10 |
|
Datasheet |
- | Box | Active | 415mA | 1 Isolated Output | 36V | Dimmable | 207 ~ 253 VAC | Board(s) | NCL30073 |
|
NCL30073LED3GEVB |
7 |
|
Datasheet |
- | Box | Active | 200mA | 1 Non-Isolated Output | 72V | Dimmable | 108 ~ 132 VAC | Board(s) | NCL30073 |
|
NCL30073LED4GEVB |
8 |
|
Datasheet |
- | Box | Active | 200mA | 1 Non-Isolated Output | 72V | Dimmable | 207 ~ 253 VAC | Board(s) | NCL30073 |
|
TPS92310-12FB/NOPB |
8 |
|
Datasheet |
- | Box | Active | 350mA | 1 Isolated Output | 21V | - | 90 ~ 132 VAC | Board(s) | TPS92310 |
|
FL7760LED1GEVK |
9 |
|
Datasheet |
- | Bulk | Active | 1A | 1 Non-Isolated Output | 2.5V ~ 5V | Dimmable | 10.8V ~ 13.2V | Board(s) | FL7760 |
|
IS32FL3265A-ZLA3-EB |
8 |
|
Datasheet |
- | Box | Active | 60mA | 18 Non-Isolated Outputs | - | - | 2.7V ~ 5.5V | Board(s) | IS32FL3265A |
|
IS31FL3763-QFLS4-EB |
5 |
|
Datasheet |
- | Box | Active | 40mA | 18 Non-Isolated Outputs | - | Dimmable | 3V ~ 5.5V | Board(s) | IS31FL3763 |
