AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MEH450US12-Y2ISOLATED / 450W / VOUT:12 |
3,950 |
|
Datasheet |
MAH450 (450W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 12V | - | - | - | - | - | 37.5 A | - | - | - | - | - | 250W (450W Forced Air) | ITE (Commercial), Medical | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 5.83" L x 3.15" W x 1.60" H (148.1mm x 80.0mm x 40.6mm) |
|
ABC600-1012GAC/DC CONVERTER 12V 420W |
2,216 |
|
Datasheet |
ABC600 (600W) | Box | Active | Open Frame | 1 | 90 ~ 277 VAC | 12V | - | - | - | - | - | 50 A | - | - | - | - | - | 420W (600W Forced Air) | ITE (Commercial) | 4.242 kV | -25°C ~ 70°C (With Derating) | Adjustable Output, Load Sharing, PFC, PMBus™ Interface, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 8.00" L x 5.00" W x 1.60" H (203.2mm x 127.0mm x 40.6mm) |
|
P53-1580T/MHIAAC/DC CONVERTER 5V +/-15V |
2,531 |
|
- |
P5 | Bulk | Active | Enclosed | 3 | 105 ~ 125 VAC | 5V | 15V | -15V | - | - | - | 1 A | 150 mA | 150 mA | - | - | - | - | Medical | 4 kV | -25°C ~ 71°C | - | Chassis Mount | 4.10" L x 2.50" W x 2.00" H (104.1mm x 63.5mm x 50.8mm) |
|
UCH600PS12AC/DC CONVERTER 12V 600W |
3,630 |
|
Datasheet |
UCH600 (600W) | Box | Active | Open Frame | 1 | 90 ~ 264 VAC | 12V | - | - | - | - | - | 50 A | - | - | - | - | - | 600W | ITE (Commercial), Medical | 4 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Standby Output, Universal Input | Chassis Mount | 8.00" L x 5.00" W x 1.57" H (203.2mm x 127.0mm x 40.0mm) |
|
UCH600PS48AC/DC CONVERTER 48V 600W |
4,319 |
|
Datasheet |
UCH600 (600W) | Box | Active | Open Frame | 1 | 90 ~ 264 VAC | 48V | - | - | - | - | - | 12.5 A | - | - | - | - | - | 600W | ITE (Commercial), Medical | 4 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Standby Output, Universal Input | Chassis Mount | 8.00" L x 5.00" W x 1.57" H (203.2mm x 127.0mm x 40.0mm) |
|
UCH600PS36AC/DC CONVERTER 36V 598W |
1,686 |
|
Datasheet |
UCH600 (600W) | Box | Active | Open Frame | 1 | 90 ~ 264 VAC | 36V | - | - | - | - | - | 16.6 A | - | - | - | - | - | 598W | ITE (Commercial), Medical | 4 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Standby Output, Universal Input | Chassis Mount | 8.00" L x 5.00" W x 1.57" H (203.2mm x 127.0mm x 40.0mm) |
|
PBL500PS48BAC/DC CONVERTER 48V 250W |
3,888 |
|
Datasheet |
PBL500 (500W) | Box | Active | Open Frame | 1 | 80 ~ 264 VAC | 48V | - | - | - | - | - | 5.21 A | - | - | - | - | - | 250W (500W Forced Air) | Medical | 4 kV | -10°C ~ 70°C (With Derating) | PFC, Remote On/Off, Remote Sense, Standby Output | Chassis Mount | 7.10" L x 4.00" W x 1.56" H (180.3mm x 101.6mm x 39.6mm) |
|
PBL500PS24BAC/DC CONVERTER 24V 250W |
4,586 |
|
Datasheet |
PBL500 (500W) | Box | Active | Open Frame | 1 | 80 ~ 264 VAC | 24V | - | - | - | - | - | 10.42 A | - | - | - | - | - | 250W (500W Forced Air) | Medical | 4 kV | -10°C ~ 70°C (With Derating) | PFC, Remote On/Off, Remote Sense, Standby Output | Chassis Mount | 7.10" L x 4.00" W x 1.56" H (180.3mm x 101.6mm x 39.6mm) |
|
PBL500PS36BAC/DC CONVERTER 36V 322W |
1,261 |
|
Datasheet |
PBL500 (500W) | Box | Active | Open Frame | 1 | 80 ~ 264 VAC | 36V | - | - | - | - | - | 8.94 A | - | - | - | - | - | 322W (500W Forced Air) | Medical | 4 kV | -10°C ~ 70°C (With Derating) | PFC, Remote On/Off, Remote Sense, Standby Output | Chassis Mount | 7.10" L x 4.00" W x 1.56" H (180.3mm x 101.6mm x 39.6mm) |
|
PBL500PS12BAC/DC CONVERTER 12V 250W |
1,884 |
|
Datasheet |
PBL500 (500W) | Box | Active | Open Frame | 1 | 80 ~ 264 VAC | 12V | - | - | - | - | - | 20.83 A | - | - | - | - | - | 250W (450W Forced Air) | Medical | 4 kV | -10°C ~ 70°C (With Derating) | PFC, Remote On/Off, Remote Sense, Standby Output | Chassis Mount | 7.10" L x 4.00" W x 1.56" H (180.3mm x 101.6mm x 39.6mm) |
|
1011569CE-150-1006 |
3,533 |
|
Datasheet |
CE-150 (150W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 28V | - | - | - | - | - | 5.4 A | - | - | - | - | - | 150W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.00" L x 4.00" W x 1.75" H (177.8mm x 101.6mm x 44.5mm) |
|
1011564CE-150-1003 |
3,654 |
|
Datasheet |
CE-150 (150W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 12.5 A | - | - | - | - | - | 150W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.00" L x 4.00" W x 1.75" H (177.8mm x 101.6mm x 44.5mm) |
|
1011567CE-150-1005 |
3,270 |
|
Datasheet |
CE-150 (150W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 6.25 A | - | - | - | - | - | 150W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.00" L x 4.00" W x 1.75" H (177.8mm x 101.6mm x 44.5mm) |
|
1011566CE-150-1004 |
4,825 |
|
Datasheet |
CE-150 (150W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 15V | - | - | - | - | - | 10 A | - | - | - | - | - | 150W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.00" L x 4.00" W x 1.75" H (177.8mm x 101.6mm x 44.5mm) |
|
1011563CE-150-1002 |
3,721 |
|
Datasheet |
CE-150 (150W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 5V | - | - | - | - | - | 30 A | - | - | - | - | - | 150W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.00" L x 4.00" W x 1.75" H (177.8mm x 101.6mm x 44.5mm) |
|
TU425S12EFAC/DC CONVERTER 12V 386W |
4,710 |
|
Datasheet |
TU425 (425W) | Bulk | Active | Enclosed | 1 | 90 ~ 264 VAC, 120 ~ 300 VDC | 12V | - | - | - | - | - | 32.2 A | - | - | - | - | - | 386W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.20" L x 3.30" W x 1.62" H (157.5mm x 83.8mm x 41.1mm) |
|
MU425S12EFAC/DC CONVERTER 12V 264W |
3,975 |
|
Datasheet |
MU425 (425W) | Bulk | Active | Enclosed | 1 | 90 ~ 264 VAC, 120 ~ 300 VDC | 12V | - | - | - | - | - | 22 A | - | - | - | - | - | 264W (386W Forced Air) | Medical | 1.5 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.20" L x 3.30" W x 1.62" H (157.5mm x 83.8mm x 41.1mm) |
|
TU425S24EFAC/DC CONVERTER 24V 403W |
3,249 |
|
Datasheet |
TU425 (425W) | Bulk | Active | Enclosed | 1 | 90 ~ 264 VAC, 120 ~ 300 VDC | 24V | - | - | - | - | - | 16.8 A | - | - | - | - | - | 403W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.20" L x 3.30" W x 1.62" H (157.5mm x 83.8mm x 41.1mm) |
|
MU425S48EFAC/DC CONVERTER 48V 283W |
2,439 |
|
Datasheet |
MU425 (425W) | Bulk | Active | Enclosed | 1 | 90 ~ 264 VAC, 120 ~ 300 VDC | 48V | - | - | - | - | - | 5.9 A | - | - | - | - | - | 283W (403W Forced Air) | Medical | 1.5 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.20" L x 3.30" W x 1.62" H (157.5mm x 83.8mm x 41.1mm) |
|
MU425S24EFAC/DC CONVERTER 24V 286W |
3,608 |
|
Datasheet |
MU425 (425W) | Bulk | Active | Enclosed | 1 | 90 ~ 264 VAC, 120 ~ 300 VDC | 24V | - | - | - | - | - | 11.9 A | - | - | - | - | - | 286W (403W Forced Air) | Medical | 1.5 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.20" L x 3.30" W x 1.62" H (157.5mm x 83.8mm x 41.1mm) |
