AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1011429REL-185-4009 |
4,403 |
|
Datasheet |
REL-185 (185W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 5V | 12V | 28V | 12V | - | - | 15 A | 4 A | 800 mA | 2 A | - | - | 185W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.00" L x 4.25" W x 1.31" H (177.8mm x 107.9mm x 33.3mm) |
|
1010561REL-185-4002 |
3,205 |
|
Datasheet |
REL-185 (185W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 5V | 3.3V | 12V | -12V | - | - | 20 A | 10 A | 2 A | 2 A | - | - | 185W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.00" L x 4.25" W x 1.31" H (177.8mm x 107.9mm x 33.3mm) |
|
1011470REL-185-4010 |
3,965 |
|
Datasheet |
REL-185 (185W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 5V | -5V | 24V | -24V | - | - | 20 A | 10 A | 1 A | 1 A | - | - | 185W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.00" L x 4.25" W x 1.31" H (177.8mm x 107.9mm x 33.3mm) |
|
LFMWLT450-1000AC/DC CONVERTER 5V 155W |
1,547 |
|
Datasheet |
MWLT450 (450W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC, 120 ~ 390 VDC | 5V | - | - | - | - | - | 31 A | - | - | - | - | - | 155W (275W Forced Air) | Medical | 5.94 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.50" L x 4.00" W x 1.61" H (165.1mm x 101.6mm x 41.0mm) |
|
LFMWLT450-1001AC/DC CONVERTER 12V 250W |
2,098 |
|
Datasheet |
MWLT450 (450W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC, 120 ~ 390 VDC | 12V | - | - | - | - | - | 20.83 A | - | - | - | - | - | 250W (450W Forced Air) | Medical | 5.94 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.50" L x 4.00" W x 1.61" H (165.1mm x 101.6mm x 41.0mm) |
|
LFMWLT450-1003AC/DC CONVERTER 24V 295W |
3,525 |
|
Datasheet |
MWLT450 (450W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC, 120 ~ 390 VDC | 24V | - | - | - | - | - | 12.3 A | - | - | - | - | - | 295W (450W Forced Air) | Medical | 5.94 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.50" L x 4.00" W x 1.61" H (165.1mm x 101.6mm x 41.0mm) |
|
LFMWLT450-1004AC/DC CONVERTER 48V 300W |
1,178 |
|
Datasheet |
MWLT450 (450W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC, 120 ~ 390 VDC | 48V | - | - | - | - | - | 6.25 A | - | - | - | - | - | 300W (450W Forced Air) | Medical | 5.94 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.50" L x 4.00" W x 1.61" H (165.1mm x 101.6mm x 41.0mm) |
|
400040-01-0AC/DC CONVERTER +/-12V 372W |
3,738 |
|
Datasheet |
XL375 (375W) | Box | Active | Open Frame | 2 | 90 ~ 264 VAC | 12V | -12V | - | - | - | - | 30 A | 1 A | - | - | - | - | 372W | ITE (Commercial) | 3 kV | -25°C ~ 70°C (With Derating) | Hot Swappable, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 5.00" L x 3.33" W x 1.50" H (127.0mm x 84.6mm x 38.1mm) |
|
1010090SRW-115-4005 |
3,206 |
|
Datasheet |
SRW-115 (115W) | Box | Not For New Designs | Open Frame | 4 | 100 ~ 240 VAC | 5V | 12V | 24V | -12V | - | - | 12 A | 1 A | 3 A | 1 A | - | - | 115W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.00" L x 4.25" W x 1.45" H (177.8mm x 108.0mm x 36.8mm) |
|
1010089SRW-115-4004 |
4,369 |
|
Datasheet |
SRW-115 (115W) | Box | Not For New Designs | Open Frame | 4 | 100 ~ 240 VAC | 5V | 24V | 15V | -15V | - | - | 12 A | 1 A | 3 A | 2 A | - | - | 115W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.00" L x 4.25" W x 1.45" H (177.8mm x 108.0mm x 36.8mm) |
|
1010086SRW-115-4001 |
1,544 |
|
Datasheet |
SRW-115 (115W) | Box | Not For New Designs | Open Frame | 4 | 100 ~ 240 VAC | 5V | -5V | 12V | -12V | - | - | 12 A | 4 A | 4 A | 2 A | - | - | 115W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.00" L x 4.25" W x 1.45" H (177.8mm x 108.0mm x 36.8mm) |
|
1010088SRW-115-4003 |
1,266 |
|
Datasheet |
SRW-115 (115W) | Box | Not For New Designs | Open Frame | 4 | 100 ~ 240 VAC | 5V | -5V | 15V | -15V | - | - | 12 A | 4 A | 3 A | 2 A | - | - | 115W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.00" L x 4.25" W x 1.45" H (177.8mm x 108.0mm x 36.8mm) |
|
1010237SRW-115-4012 |
3,345 |
|
Datasheet |
SRW-115 (115W) | Box | Not For New Designs | Open Frame | 4 | 100 ~ 240 VAC | 5V | 12V | 24V | -12V | - | - | 5 A | 1 A | 3 A | 1 A | - | - | 115W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.00" L x 4.25" W x 1.45" H (177.8mm x 108.0mm x 36.8mm) |
|
TU425S48ECAC/DC CONVERTER 48V 182W |
2,590 |
|
Datasheet |
TU425 (425W) | Bulk | Active | Enclosed | 1 | 90 ~ 264 VAC, 120 ~ 300 VDC | 48V | - | - | - | - | - | 3.8 A | - | - | - | - | - | 182W (312W Forced Air) | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.20" L x 3.30" W x 1.62" H (157.5mm x 83.8mm x 41.1mm) |
|
MEH450US24-Y2AC/DC CONVERTER 24V 450W |
4,516 |
|
Datasheet |
MEH450 | Box | Active | Enclosed | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 24V | - | - | - | - | - | 18.75 A | - | - | - | - | - | 450W | ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 5.83" L x 3.15" W x 1.60" H (148.1mm x 80.0mm x 40.6mm) |
|
TU425S56EAC/DC CONVERTER 56V 300W |
4,677 |
|
Datasheet |
TU425 (425W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC | 56V | - | - | - | - | - | 5.1 A | - | - | - | - | - | 300W (425W Forced Air) | ITE (Commercial) | 4 kV | -10°C ~ 70°C (With Derating) | DC Input Capable, Load Sharing, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.20" L x 3.30" W x 1.62" H (157.4mm x 83.8mm x 41.1mm) |
|
ESS50-12AC/DC CONVERTER 12V 52W |
2,983 |
|
Datasheet |
ESS50 (50W) | Bulk | Active | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 350 VDC | 12V | - | - | - | - | - | 4.3 A | - | - | - | - | - | 52W | Industrial, ITE (Commercial) | 3 kV | -10°C ~ 71°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.33" L x 1.30" W x 3.11" H (110.0mm x 33.0mm x 79.0mm) |
|
ESS50-36AC/DC CONVERTER 36V 50W |
3,634 |
|
Datasheet |
ESS50 (50W) | Bulk | Active | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 350 VDC | 36V | - | - | - | - | - | 1.4 A | - | - | - | - | - | 50W | Industrial, ITE (Commercial) | 3 kV | -10°C ~ 71°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.33" L x 1.30" W x 3.11" H (110.0mm x 33.0mm x 79.0mm) |
|
ESS50-15AC/DC CONVERTER 15V 53W |
2,444 |
|
Datasheet |
ESS50 (50W) | Bulk | Active | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 350 VDC | 15V | - | - | - | - | - | 3.5 A | - | - | - | - | - | 53W | Industrial, ITE (Commercial) | 3 kV | -10°C ~ 71°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.33" L x 1.30" W x 3.11" H (110.0mm x 33.0mm x 79.0mm) |
|
P53-15T/MHIAAC/DC CONVERTER 5V +/-15V |
2,636 |
|
- |
P5 | Bulk | Active | Enclosed | 3 | 105 ~ 125 VAC | 5V | 15V | -15V | - | - | - | 500 mA | 100 mA | 100 mA | - | - | - | - | Medical | 4 kV | -25°C ~ 71°C | - | Chassis Mount | 4.10" L x 2.50" W x 1.56" H (104.1mm x 63.5mm x 39.6mm) |
