AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1010023SRW-65-4004 |
3,805 |
|
Datasheet |
SRW-65 (65W) | Box | Not For New Designs | Open Frame | 4 | 100 ~ 240 VAC | 5V | -5V | 15V | -15V | - | - | 5 A | 3 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.00" L x 4.00" W x 1.16" H (152.4mm x 101.6mm x 29.5mm) |
|
1010021SRW-65-4002 |
2,044 |
|
Datasheet |
SRW-65 (65W) | Box | Not For New Designs | Open Frame | 4 | 100 ~ 240 VAC | 5V | 12V | 12V | -12V | - | - | 5 A | 1 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.00" L x 4.00" W x 1.16" H (152.4mm x 101.6mm x 29.5mm) |
|
1010196SRW-65-4007 |
2,067 |
|
Datasheet |
SRW-65 (65W) | Box | Not For New Designs | Open Frame | 4 | 100 ~ 240 VAC | 5V | 26V | 15V | -15V | - | - | 5 A | 1 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.00" L x 4.00" W x 1.16" H (152.4mm x 101.6mm x 29.5mm) |
|
1010020SRW-65-4001 |
4,969 |
|
Datasheet |
SRW-65 (65W) | Box | Not For New Designs | Open Frame | 4 | 100 ~ 240 VAC | 5V | -5V | 12V | -12V | - | - | 5 A | 3 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.00" L x 4.00" W x 1.16" H (152.4mm x 101.6mm x 29.5mm) |
|
LFP300F-48-GTYAC/DC CONVERTER 48V |
1,390 |
|
Datasheet |
LFP (300W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC | 48V | - | - | - | - | - | 6.3 A | - | - | - | - | - | - | ITE (Commercial) | 3 kV | -10°C ~ 70°C | - | Chassis Mount | 8.74" L x 3.74" W x 2.07" H (222.0mm x 95.0mm x 52.6mm) |
|
PM500F-12BAC/DC CONVERTER 12V 250W |
3,002 |
|
- |
PM500F (500W) | Box | Active | Open Frame | 1 | 80 ~ 264 VAC | 12V | - | - | - | - | - | 37.5 A | - | - | - | - | - | 250W (450W Forced Air) | Medical | - | -10°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.00" L x 4.21" W x 1.56" H (101.6mm x 106.9mm x 39.6mm) |
|
PM500F-14BAC/DC CONVERTER 24V 250W |
1,097 |
|
- |
PM500F (500W) | Box | Active | Open Frame | 1 | 80 ~ 264 VAC | 24V | - | - | - | - | - | 20.84 A | - | - | - | - | - | 250W (500W Forced Air) | Medical | - | -10°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.00" L x 4.21" W x 1.56" H (101.6mm x 106.9mm x 39.6mm) |
|
MDCC-0307AC/DC CONVERTER +/-15V 30W |
4,965 |
|
Datasheet |
MCA-30 (30W) | Bulk | Active | Enclosed | 2 | 90 ~ 264 VAC | 15V | -15V | - | - | - | - | 1 A | 1 A | - | - | - | - | 30W | ITE (Commercial), Medical | 3 kV | 0°C ~ 50°C | Universal Input | Chassis Mount | 4.76" L x 2.56" W x 1.00" H (120.9mm x 65.0mm x 25.4mm) |
|
P33-12XT/MHIAAC/DC CONVERTER +/-12V |
4,051 |
|
- |
P3 | Bulk | Active | Enclosed | 2 | 105 ~ 220 VAC | 12V | -12V | - | - | - | - | 100 mA | 100 mA | - | - | - | - | - | Medical | 4 kV | -25°C ~ 71°C | - | Chassis Mount | 4.10" L x 2.50" W x 0.88" H (104.1mm x 63.5mm x 22.2mm) |
|
FXA350015AAC/DC CONVERTER 15V 250W |
3,902 |
|
Datasheet |
FXA350 (350W) | Bulk | Active | Open Frame | 1 | 85 ~ 264 VAC | 15V | - | - | - | - | - | 16.5 A | - | - | - | - | - | 250W (350W Forced Air) | ITE (Commercial) | - | 0°C ~ 70°C (With Derating) | PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 8.00" L x 5.00" W x 1.50" H (203.2mm x 127.0mm x 38.1mm) |
|
P33-1T/MHIAAC/DC CONVERTER +/-15V |
1,043 |
|
- |
P3 | Bulk | Active | Enclosed | 2 | 105 ~ 125 VAC | 15V | -15V | - | - | - | - | 100 mA | 100 mA | - | - | - | - | - | Medical | 4 kV | -25°C ~ 71°C | - | Chassis Mount | 4.10" L x 2.50" W x 0.88" H (104.1mm x 63.5mm x 22.2mm) |
|
P33-12T/MHIAAC/DC CONVERTER +/-12V |
3,085 |
|
- |
P3 | Bulk | Active | Enclosed | 2 | 105 ~ 125 VAC | 12V | -12V | - | - | - | - | 100 mA | 100 mA | - | - | - | - | - | Medical | 4 kV | -25°C ~ 71°C | - | Chassis Mount | 4.10" L x 2.50" W x 0.88" H (104.1mm x 63.5mm x 22.2mm) |
|
PMK150S-15AC/DC CONVERTER 15V 150W |
4,719 |
|
Datasheet |
PMK150 (150W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC | 15V | - | - | - | - | - | 10 A | - | - | - | - | - | 150W | ITE (Commercial) | 4.242 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | - |
|
PMK150S-24AC/DC CONVERTER 24V 151W |
4,057 |
|
Datasheet |
PMK150 (150W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 6.3 A | - | - | - | - | - | 151W | ITE (Commercial) | 4.242 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | - |
|
1010510REL-150-2001 |
4,309 |
|
Datasheet |
REL-150 (150W) | Box | Active | Open Frame | 2 | 85 ~ 264 VAC | 3.3V | 5V | - | - | - | - | 15 A | 8 A | - | - | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) |
|
1010514REL-150-2005 |
4,373 |
|
Datasheet |
REL-150 (150W) | Box | Active | Open Frame | 2 | 85 ~ 264 VAC | 15V | -15V | - | - | - | - | 5 A | 5 A | - | - | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) |
|
1010512REL-150-2003 |
2,523 |
|
Datasheet |
REL-150 (150W) | Box | Active | Open Frame | 2 | 85 ~ 264 VAC | 5V | 24V | - | - | - | - | 15 A | 3 A | - | - | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) |
|
1010511REL-150-2002 |
4,378 |
|
Datasheet |
REL-150 (150W) | Box | Active | Open Frame | 2 | 85 ~ 264 VAC | 5V | 12V | - | - | - | - | 15 A | 5 A | - | - | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) |
|
1010580REL-185-1007 |
3,867 |
|
Datasheet |
REL-185 (185W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC | 28V | - | - | - | - | - | 6.6 A | - | - | - | - | - | 185W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.00" L x 4.25" W x 1.31" H (177.8mm x 107.9mm x 33.3mm) |
|
1010577REL-185-1004 |
1,782 |
|
Datasheet |
REL-185 (185W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 15.4 A | - | - | - | - | - | 185W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.00" L x 4.25" W x 1.31" H (177.8mm x 107.9mm x 33.3mm) |
