AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
GMA300F-24-J1AC/DC CONVERTER 24V 300W |
1,106 |
|
Datasheet |
GMA (300W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 12.5 A | - | - | - | - | - | 300W | ITE (Commercial), Medical | 4 kV | -20°C ~ 70°C | Adjustable Output, PFC, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.44" H (101.6mm x 50.8mm x 36.6mm) |
|
P37-T/MHIAAC-DC POWER MODULE 5VDC 500MA |
2,193 |
|
- |
P3 | Bulk | Active | Enclosed | 1 | 105 ~ 125 VAC | 5V | - | - | - | - | - | 500 mA | - | - | - | - | - | - | Medical | 4 kV | -25°C ~ 71°C | - | Chassis Mount | 4.10" L x 2.50" W x 0.88" H (104.1mm x 63.5mm x 22.2mm) |
|
PM400-14BAC/DC CONVERTER 24V 300W |
2,937 |
|
- |
PM400 (400W) | Box | Active | Open Frame | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 16.67 A | - | - | - | - | - | 300W (400W Forced Air) | ITE (Commercial), Medical | - | -10°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.00" L x 4.00" W x 1.56" H (177.8mm x 101.6mm x 39.6mm) |
|
1010035SRW-65-2005 |
1,031 |
|
Datasheet |
SRW-65 (65W) | Box | Not For New Designs | Open Frame | 2 | 100 ~ 240 VAC | 5V | - | - | - | - | - | 7 A | 1.5 A | - | - | - | - | 65W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.00" L x 4.00" W x 1.16" H (152.4mm x 101.6mm x 29.5mm) |
|
PM500-12BAC/DC CONVERTER 12V 350W |
3,232 |
|
Datasheet |
PM500 (500W) | Bag | Active | Open Frame | 1 | 90 ~ 264 VAC | 12V | - | - | - | - | - | 37.5 A | - | - | - | - | - | 350W (450W Forced Air) | ITE (Commercial), Medical | - | -10°C ~ 70°C | DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 5.50" L x 0.05" W x 1.68" H (139.7mm x 1.2mm x 42.7mm) |
|
1010034SRW-65-2004 |
2,128 |
|
Datasheet |
SRW-65 (65W) | Box | Not For New Designs | Open Frame | 2 | 100 ~ 240 VAC | 15V | - | - | - | - | - | 2.5 A | 2 A | - | - | - | - | 65W | Industrial, ITE (Commercial) | - | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.00" L x 4.00" W x 1.16" H (152.4mm x 101.6mm x 29.5mm) |
|
PM500-14BAC/DC CONVERTER 24V 534W |
3,105 |
|
Datasheet |
PM500 (500W) | Bag | Active | Open Frame | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 27.78 A | - | - | - | - | - | 534W (667W Forced Air) | ITE (Commercial), Medical | - | -10°C ~ 70°C | DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.25" L x 4.00" W x 1.68" H (158.8mm x 101.6mm x 42.7mm) |
|
PM500-14BAC/DC CONVERTER 24V 400W |
3,190 |
|
- |
PM500 (500W) | Box | Active | Open Frame | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 20.84 A | - | - | - | - | - | 400W (500W Forced Air) | ITE (Commercial), Medical | - | -10°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.00" L x 4.00" W x 1.56" H (177.8mm x 101.6mm x 39.6mm) |
|
PM500-12BAC/DC CONVERTER 12V 350W |
3,857 |
|
- |
PM500 (500W) | Box | Active | Open Frame | 1 | 90 ~ 264 VAC | 12V | - | - | - | - | - | 37.5 A | - | - | - | - | - | 350W (450W Forced Air) | ITE (Commercial), Medical | - | -10°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.00" L x 4.00" W x 1.56" H (177.8mm x 101.6mm x 39.6mm) |
|
1010471REL-110-4001 |
4,025 |
|
Datasheet |
REL-110 (110W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 3.3V | 5V | 12V | -12V | - | - | 10 A | 6 A | 2 A | 2 A | - | - | 110W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) |
|
1010474REL-110-4004 |
4,714 |
|
Datasheet |
REL-110 (110W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 5V | -5V | 12V | -12V | - | - | 10 A | 6 A | 2 A | 2 A | - | - | 110W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) |
|
1010955REL-110-4011 |
2,704 |
|
Datasheet |
REL-110 (110W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 32V | -32V | 12V | -12V | - | - | 2 A | 2 A | 1 A | 1 A | - | - | 110W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) |
|
1010475REL-110-4005 |
2,959 |
|
Datasheet |
REL-110 (110W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 5V | -5V | 15V | -15V | - | - | 10 A | 6 A | 2 A | 2 A | - | - | 110W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) |
|
1010473REL-110-4003 |
1,680 |
|
Datasheet |
REL-110 (110W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 5V | 3.3V | 15V | -15V | - | - | 10 A | 6 A | 2 A | 2 A | - | - | 110W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) |
|
1010472REL-110-4002 |
1,441 |
|
Datasheet |
REL-110 (110W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 5V | 3.3V | 12V | -12V | - | - | 10 A | 6 A | 2 A | 2 A | - | - | 110W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) |
|
1010745REL-110-4009 |
2,041 |
|
Datasheet |
REL-110 (110W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 5V | 24V | 7V | -7V | - | - | 10 A | 2 A | 2.5 A | 2.5 A | - | - | 110W | Industrial, ITE (Commercial), Laboratory, Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) |
|
ESS30-48AC/DC CONVERTER 48V 31W |
1,714 |
|
Datasheet |
ESS30 (30W) | Bulk | Active | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 48V | - | - | - | - | - | 650 mA | - | - | - | - | - | 31W | Industrial, ITE (Commercial) | 3 kV | -10°C ~ 71°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.86" L x 1.30" W x 2.68" H (98.0mm x 33.0mm x 68.0mm) |
|
ESS30-36AC/DC CONVERTER 36V 29W |
2,258 |
|
Datasheet |
ESS30 (30W) | Bulk | Active | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 36V | - | - | - | - | - | 800 mA | - | - | - | - | - | 29W | Industrial, ITE (Commercial) | 3 kV | -10°C ~ 71°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.86" L x 1.30" W x 2.68" H (98.0mm x 33.0mm x 68.0mm) |
|
ESS30-05AC/DC CONVERTER 5V 30W |
1,148 |
|
Datasheet |
ESS30 (30W) | Bulk | Active | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 5V | - | - | - | - | - | 6 A | - | - | - | - | - | 30W | Industrial, ITE (Commercial) | 3 kV | -10°C ~ 71°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.86" L x 1.30" W x 2.68" H (98.0mm x 33.0mm x 68.0mm) |
|
ESS30-24AC/DC CONVERTER 24V 31W |
1,660 |
|
Datasheet |
ESS30 (30W) | Bulk | Active | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 1.3 A | - | - | - | - | - | 31W | Industrial, ITE (Commercial) | 3 kV | -10°C ~ 71°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.86" L x 1.30" W x 2.68" H (98.0mm x 33.0mm x 68.0mm) |
