AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LMF320-23B24-CAC/DC CONVERTER 24V 322W |
2,245 |
|
Datasheet |
LMF320-23Bxx-C (320W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 24V | - | - | - | - | - | 13.4 A | - | - | - | - | - | 322W | ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Standby Output, Universal Input | Chassis Mount | 8.47" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) |
|
LMF320-23B12-QAC/DC CONVERTER 12V 320W |
3,907 |
|
Datasheet |
LMF320-23Bxx-Q (320W) | Box | Not For New Designs | Enclosed, Conformal Coated | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 12V | - | - | - | - | - | 26.7 A | - | - | - | - | - | 320W | ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Standby Output, Universal Input | Chassis Mount | 8.47" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) |
|
LMF600-20B12AC/DC CONVERTER 12V 600W |
2,885 |
|
Datasheet |
LMF600-20Bxx (600W) | Box | Not For New Designs | Enclosed | 1 | 80 ~ 277 VAC, 110 ~ 390 VDC | 12V | - | - | - | - | - | 50 A | - | - | - | - | - | 600W | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote On/Off, Remote Sense, Standby Output | Chassis Mount | 4.00" L x 8.00" W x 1.60" H (101.6mm x 203.1mm x 40.6mm) |
|
LMF600-20B36AC/DC CONVERTER 36V 601W |
2,810 |
|
Datasheet |
LMF600-20Bxx (600W) | Box | Not For New Designs | Enclosed | 1 | 80 ~ 277 VAC, 110 ~ 390 VDC | 36V | - | - | - | - | - | 16.7 A | - | - | - | - | - | 601W | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote On/Off, Remote Sense, Standby Output | Chassis Mount | 4.00" L x 8.00" W x 1.60" H (101.6mm x 203.1mm x 40.6mm) |
|
LMF600-20B48AC/DC CONVERTER 48V 605W |
2,265 |
|
Datasheet |
LMF600-20Bxx (600W) | Box | Not For New Designs | Enclosed | 1 | 80 ~ 277 VAC, 110 ~ 390 VDC | 48V | - | - | - | - | - | 12.6 A | - | - | - | - | - | 605W | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote On/Off, Remote Sense, Standby Output | Chassis Mount | 4.00" L x 8.00" W x 1.60" H (101.6mm x 203.1mm x 40.6mm) |
|
LMF600-20B27AC/DC CONVERTER 27V 602W |
1,895 |
|
Datasheet |
LMF600-20Bxx (600W) | Box | Not For New Designs | Enclosed | 1 | 80 ~ 277 VAC, 110 ~ 390 VDC | 27V | - | - | - | - | - | 22.3 A | - | - | - | - | - | 602W | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote On/Off, Remote Sense, Standby Output | Chassis Mount | 4.00" L x 8.00" W x 1.60" H (101.6mm x 203.1mm x 40.6mm) |
|
LMF600-20B15AC/DC CONVERTER 15V 600W |
3,804 |
|
Datasheet |
LMF600-20Bxx (600W) | Box | Not For New Designs | Enclosed | 1 | 80 ~ 277 VAC, 110 ~ 390 VDC | 15V | - | - | - | - | - | 40 A | - | - | - | - | - | 600W | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote On/Off, Remote Sense, Standby Output | Chassis Mount | 4.00" L x 8.00" W x 1.60" H (101.6mm x 203.1mm x 40.6mm) |
|
EPL150PS36AC/DC CONVERTER 36V 100W |
1,989 |
|
Datasheet |
EPL150 (150W) | Box | Active | Open Frame | 1 | 80 ~ 264 VAC | 36V | - | - | - | - | - | 2.78 A | - | - | - | - | - | 100W (150W Forced Air) | ITE (Commercial), Medical | 4 kV | -20°C ~ 70°C (With Derating) | PFC, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 0.99" H (101.6mm x 50.8mm x 25.2mm) |
|
PMA30F-3R3AC/DC CONVERTER 3.3V |
2,608 |
|
Datasheet |
PMA (30W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC | 3.3V | - | - | - | - | - | 6 A | - | - | - | - | - | - | Medical | 2 kV | -10°C ~ 70°C | - | Chassis Mount | 4.72" L x 1.22" W x 3.23" H (119.9mm x 31.0mm x 82.0mm) |
|
LOF450-20B48-CENCLOSED AC DC CONVERTER 1 OUTPU |
3,498 |
|
Datasheet |
LOF450-20Bxx-C(-CF) (450W) | Box | Not For New Designs | Enclosed, Conformal Coated | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 48V | - | - | - | - | - | 9.4 A | - | - | - | - | - | 254W (451W Forced Air) | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 5.12" L x 3.39" W x 1.69" H (130.0mm x 86.0mm x 43.0mm) |
|
LOF450-20B24-CENCLOSED AC DC CONVERTER 1 OUTPU |
2,520 |
|
Datasheet |
LOF450-20Bxx-C(-CF) (450W) | Box | Not For New Designs | Enclosed, Conformal Coated | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 24V | - | - | - | - | - | 18.75 A | - | - | - | - | - | 252W (450W Forced Air) | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 5.12" L x 3.39" W x 1.69" H (130.0mm x 86.0mm x 43.0mm) |
|
LOF450-20B12-CENCLOSED AC DC CONVERTER 1 OUTPU |
2,485 |
|
Datasheet |
LOF450-20Bxx-C(-CF) (450W) | Box | Not For New Designs | Enclosed, Conformal Coated | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 12V | - | - | - | - | - | 33.3 A | - | - | - | - | - | 250W (400W Forced Air) | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 5.12" L x 3.39" W x 1.69" H (130.0mm x 86.0mm x 43.0mm) |
|
VOF-450C-27AC/DC CONVERTER 27V 451W |
2,902 |
|
Datasheet |
VOF-450C (450W) | Tray | Not For New Designs | Open Frame | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 27V | - | - | - | - | - | 16.7 A | - | - | - | - | - | 451W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.52" H (127.0mm x 76.2mm x 38.5mm) |
|
|
LFA100F-15-YAC/DC CONVERTER 15V |
1,106 |
|
Datasheet |
LFA (100W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC | 15V | - | - | - | - | - | 6.7 A | - | - | - | - | - | - | ITE (Commercial) | 3 kV | -10°C ~ 70°C | - | Chassis Mount | 6.10" L x 2.44" W x 1.32" H (154.9mm x 62.0mm x 33.5mm) |
|
1011400GRN-45-2004 OVP |
3,504 |
|
Datasheet |
GRN-45 (45W) | Box | Active | Open Frame | 2 | 85 ~ 264 VAC | 15V | -15V | - | - | - | - | 2 A | 2 A | - | - | - | - | 45W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.25" L x 2.50" W x 0.83" H (108.0mm x 63.5mm x 21.1mm) |
|
1011399GRN-45-2003 OVP |
1,336 |
|
Datasheet |
GRN-45 (45W) | Box | Active | Open Frame | 2 | 85 ~ 264 VAC | 12V | -12V | - | - | - | - | 2 A | 2 A | - | - | - | - | 45W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.25" L x 2.50" W x 0.83" H (108.0mm x 63.5mm x 21.1mm) |
|
VOF-350C-27AC/DC CONVERTER 27V 351W |
2,262 |
|
Datasheet |
VOF-350C (350W) | Tray | Not For New Designs | Open Frame | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 27V | - | - | - | - | - | 13 A | - | - | - | - | - | 351W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.00" H (127.0mm x 76.2mm x 25.4mm) |
|
WLP350-1002-IIAC/DC CONVERTER 15V 180W |
4,241 |
|
Datasheet |
WLP350 (350W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC, 390VDC | 15V | - | - | - | - | - | 12 A | - | - | - | - | - | 180W (325W Forced Air) | ITE (Commercial) | 3 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, PFC, Standby Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.00" H (127.0mm x 76.2mm x 25.4mm) |
|
VMS-350C-36AC/DC CONVERTER 36V 350W |
2,498 |
|
Datasheet |
VMS-350C (350W) | Tray | Not For New Designs | Open Frame | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 36V | - | - | - | - | - | 9.73 A | - | - | - | - | - | 350W | Household Appliances, Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.00" H (127.0mm x 76.2mm x 25.4mm) |
|
VMS-350C-15AC/DC CONVERTER 15V 325W |
2,485 |
|
Datasheet |
VMS-350C (350W) | Tray | Not For New Designs | Open Frame | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 15V | - | - | - | - | - | 21.67 A | - | - | - | - | - | 325W | Household Appliances, Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.00" H (127.0mm x 76.2mm x 25.4mm) |
