AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LCW320PS24AC/DC CONVERTER 24V 322W |
3,292 |
|
Datasheet |
LCW320 (320W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 24V | - | - | - | - | - | 13.4 A | - | - | - | - | - | 322W | ITE (Commercial), Industrial | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC | Chassis Mount | 8.47" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) |
|
LFA50F-3R3-J1YAC/DC CONVERTER 3.3V |
3,818 |
|
Datasheet |
LFA (50W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC | 3.3V | - | - | - | - | - | 10 A | - | - | - | - | - | - | ITE (Commercial) | 3 kV | -10°C ~ 70°C | - | Chassis Mount | 5.20" L x 1.97" W x 1.04" H (132.1mm x 50.0mm x 26.4mm) |
|
VGS-200D-15AC/DC CONVERTER 15V 201W |
4,204 |
|
Datasheet |
VGS-200D (201W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 15V | - | - | - | - | - | 13.4 A | - | - | - | - | - | 201W | Household Appliances, ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
VGS-200D-48AC/DC CONVERTER 48V 202W |
3,905 |
|
Datasheet |
VGS-200D (201W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 48V | - | - | - | - | - | 4.2 A | - | - | - | - | - | 202W | Household Appliances, ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
VGS-320D-12-AAC/DC CONVERTER 12V 320W |
4,427 |
|
Datasheet |
VGS-320D | Box | Not For New Designs | Enclosed | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 12V | - | - | - | - | - | 26.7 A | - | - | - | - | - | 320W | ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC | Chassis Mount | 8.47" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) |
|
LMF320-23B05AC/DC CONVERTER 5V 300W |
2,459 |
|
Datasheet |
305RAC / LMF-23B | Box | Not For New Designs | Enclosed | 1 | 85 ~ 305 VAC, 100 ~ 430 VDC | 5V | - | - | - | - | - | 60 A | - | - | - | - | - | 300W | ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC | Chassis Mount | 8.47" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) |
|
VMS-225C-12AC/DC CONVERTER 12V 225W |
3,922 |
|
Datasheet |
VMS-225C (225W) | Tray | Not For New Designs | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 12V | - | - | - | - | - | 18.75 A | - | - | - | - | - | 225W | Household Appliances, Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.00" H (101.6mm x 50.8mm x 25.4mm) |
|
OFM-0200AC/DC CONVERTER 3.3V 18W |
4,533 |
|
Datasheet |
OFM20 (20W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC | 3.3V | - | - | - | - | - | 5.4 A | - | - | - | - | - | 18W | ITE (Commercial) | 3 kV | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | - |
|
ASM30D-1212-BEH-0F0AC/DC CONVERTER +/-12V 30W |
2,571 |
|
Datasheet |
ASM30 | Box | Active | Enclosed | 2 | 80 ~ 264 VAC | 12V | -12V | - | - | - | - | 1.25 A | 1.25 A | - | - | - | - | 30W | ITE (Commercial), Medical | 4 kV | -40°C ~ 80°C | - | - | 3.25" L x 2.48" W x 1.20" H (82.5mm x 63.0mm x 30.5mm) |
|
VGS-320D-12-BAC/DC CONVERTER 12V 320W |
4,897 |
|
Datasheet |
VGS-320D | Box | Not For New Designs | Enclosed, Conformal Coated | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 12V | - | - | - | - | - | 26.7 A | - | - | - | - | - | 320W | ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC | Chassis Mount | 8.47" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) |
|
WRM23FWX-OUNIVERSAL, DUAL OUTPUT, ENCLOSED |
2,380 |
|
Datasheet |
WRM-FMX-O (15W | Bulk | Active | Enclosed | 2 | 85 ~ 264 VAC, 125 ~ 370 VDC | 15V | 15V | - | - | - | - | 500 mA | 500 mA | - | - | - | - | 15W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 3.31" L x 3.20" W x 1.24" H (84.0mm x 81.2mm x 31.5mm) |
|
WRM22FWX-OUNIVERSAL, DUAL OUTPUT, ENCLOSED |
2,278 |
|
Datasheet |
WRM-FMX-O (15W | Bulk | Active | Enclosed | 2 | 85 ~ 264 VAC, 125 ~ 370 VDC | 12V | 12V | - | - | - | - | 700 mA | 700 mA | - | - | - | - | 17W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 3.31" L x 3.20" W x 1.24" H (84.0mm x 81.2mm x 31.5mm) |
|
LMF200-23B24-CAC/DC CONVERTER 24V 202W |
1,302 |
|
Datasheet |
LMF200-23Bxx-C (200W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 24V | - | - | - | - | - | 8.4 A | - | - | - | - | - | 202W | Household Appliances, ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
LMF200-23B24-QAC/DC CONVERTER 24V 202W |
3,161 |
|
Datasheet |
LMF200-23Bxx-Q (200W) | Box | Not For New Designs | Enclosed, Conformal Coated | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 24V | - | - | - | - | - | 8.4 A | - | - | - | - | - | 202W | Household Appliances, ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
LMF200-23B12-QAC/DC CONVERTER 12V 200W |
4,332 |
|
Datasheet |
LMF200-23Bxx-Q (200W) | Box | Not For New Designs | Enclosed, Conformal Coated | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 12V | - | - | - | - | - | 16.7 A | - | - | - | - | - | 200W | Household Appliances, ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
1010428SRP-25-1005 |
2,857 |
|
Datasheet |
SRP-25 (25W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 24V | - | - | - | - | - | 1.04 A | - | - | - | - | - | 25W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.00" L x 2.25" W x 1.00" H (101.6mm x 57.2mm x 25.4mm) |
|
1010426SRP-25-1003 |
3,302 |
|
Datasheet |
SRP-25 (25W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 12V | - | - | - | - | - | 2.08 A | - | - | - | - | - | 25W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.00" L x 2.25" W x 1.00" H (101.6mm x 57.2mm x 25.4mm) |
|
VOF-180C-48-CNFAC/DC CONVERTER 48V 180W |
4,949 |
|
Datasheet |
VOF-180C-CNF (180W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 48V | - | - | - | - | - | 3.75 A | - | - | - | - | - | 180W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 4.07" L x 2.44" W x 1.46" H (103.4mm x 62.0mm x 37.0mm) |
|
|
LGA100A-48AC/DC CONVERTER 48V |
2,935 |
|
Datasheet |
LGA (100W) | Box | Active | Open Frame | 1 | 85 ~ 132 VAC | 48V | - | - | - | - | - | 2.1 A | - | - | - | - | - | - | ITE (Commercial) | 2 kV | -10°C ~ 60°C | - | Chassis Mount | 6.10" L x 2.44" W x 1.40" H (154.9mm x 62.0mm x 35.6mm) |
|
VMS-180C-36-CNFAC/DC CONVERTER 36V 180W |
1,576 |
|
Datasheet |
VMS-180C-CNF (180W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 36V | - | - | - | - | - | 5 A | - | - | - | - | - | 180W | Household Appliances, Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 4.07" L x 2.44" W x 1.46" H (103.4mm x 62.0mm x 37.0mm) |
