AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MPE-S20524V/6.25A 150W convection, 200W |
4,688 |
|
Datasheet |
MPE-S200 (200W) | Bulk | Active | Open Frame | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 8.33 A | - | - | - | - | - | 150W (200W Forced Air) | ITE (Commercial) | 3 kV | -20°C ~ 80°C (With Derating) | Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.48" H (101.6mm x 50.8mm x 37.6mm) |
|
CFM202S480CAC/DC CONVERTER 48V 180W |
3,579 |
|
Datasheet |
CFM202S (200W) | Box | Active | Enclosed | 1 | 90 ~ 264 VAC | 48V | - | - | - | - | - | 4.17 A | - | - | - | - | - | 180W (200W Forced Air) | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 80°C (With Derating) | PFC, Standby Output, Universal Input | Chassis Mount | 4.60" L x 2.52" W x 1.36" H (116.8mm x 64.0mm x 34.5mm) |
|
ASM30D-0606-BNH-0F0AC/DC CONVERTER +/-6V 30W |
4,955 |
|
Datasheet |
ASM30 | Box | Active | Open Frame | 2 | 80 ~ 264 VAC | 6V | -6V | - | - | - | - | 2.5 A | 2.5 A | - | - | - | - | 30W | ITE (Commercial), Medical | 4 kV | -40°C ~ 80°C | - | - | 3.00" L x 2.00" W x 0.85" H (76.2mm x 80.8mm x 21.7mm) |
|
ASM30D-1212-BNH-0F0AC/DC CONVERTER +/-12V 30W |
1,473 |
|
Datasheet |
ASM30 | Box | Active | Open Frame | 2 | 80 ~ 264 VAC | 12V | -12V | - | - | - | - | 1.25 A | 1.25 A | - | - | - | - | 30W | ITE (Commercial), Medical | 4 kV | -40°C ~ 80°C | - | - | 3.00" L x 2.00" W x 0.85" H (76.2mm x 80.8mm x 21.7mm) |
|
ASM30D-0524-BNH-0F0AC/DC CONVERTER 24V 5V 30W |
2,733 |
|
Datasheet |
ASM30 | Box | Active | Open Frame | 2 | 80 ~ 264 VAC | 24V | 5V | - | - | - | - | 730 mA | 2.5 A | - | - | - | - | 30W | ITE (Commercial), Medical | 4 kV | -40°C ~ 80°C | - | - | 3.00" L x 2.00" W x 0.85" H (76.2mm x 80.8mm x 21.7mm) |
|
ASM30D-1515-BNH-0F0AC/DC CONVERTER +/-15V 30W |
1,211 |
|
Datasheet |
ASM30 | Box | Active | Open Frame | 2 | 80 ~ 264 VAC | 15V | -15V | - | - | - | - | 1 A | 1 A | - | - | - | - | 30W | ITE (Commercial), Medical | 4 kV | -40°C ~ 80°C | - | - | 3.00" L x 2.00" W x 0.85" H (76.2mm x 80.8mm x 21.7mm) |
|
ASM30D-3306-BNH-0F0AC/DC CONVERTER 6V 3.3V 30W |
2,981 |
|
Datasheet |
ASM30 | Box | Active | Open Frame | 2 | 80 ~ 264 VAC | 6V | 3.3V | - | - | - | - | 1.67 A | 3 A | - | - | - | - | 30W | ITE (Commercial), Medical | 4 kV | -40°C ~ 80°C | - | - | 3.00" L x 2.00" W x 0.85" H (76.2mm x 80.8mm x 21.7mm) |
|
ASL40D-3AC/DC CONVERTER 5V 24V 24W |
3,595 |
|
Datasheet |
ASL40 (40W) | Bulk | Active | Open Frame | 2 | 90 ~ 264 VAC | 5V | 24V | - | - | - | - | 3.3 A | 1 A | - | - | - | - | 24W | ITE (Commercial), Medical | 3 kV | -20°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.24" H (101.6mm x 50.8mm x 31.6mm) |
|
ASM30-280-BNH-0F0AC/DC CONVERTER 28V 30W |
3,590 |
|
Datasheet |
ASM30 | Box | Active | Open Frame | 1 | 80 ~ 264 VAC | 28V | - | - | - | - | - | 1.07 A | - | - | - | - | - | 30W | ITE (Commercial), Medical | 4 kV | -40°C ~ 80°C | - | - | 3.00" L x 1.60" W x 0.85" H (76.2mm x 40.6mm x 21.7mm) |
|
ASL40D-1AC/DC CONVERTER 5V 12V 24W |
3,424 |
|
Datasheet |
ASL40 (40W) | Bulk | Active | Open Frame | 2 | 90 ~ 264 VAC | 5V | 12V | - | - | - | - | 3.3 A | 2 A | - | - | - | - | 24W | ITE (Commercial), Medical | 3 kV | -20°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.24" H (101.6mm x 50.8mm x 31.6mm) |
|
PV75-2YB24R3ISOLATED MODULE DC DC CONVERTER |
3,631 |
|
Datasheet |
PV75-2YBxxR3 (75W) | Box | Not For New Designs | Enclosed | 1 | 80 ~ 1000 VDC | 24V | - | - | - | - | - | 3.125 A | - | - | - | - | - | 75W | ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | DC Input Capable | Chassis Mount | 5.51" L x 2.76" W x 1.65" H (140.0mm x 70.0mm x 42.0mm) |
|
ASL60D-2AC/DC CONVERTER 5V 15V 36W |
3,206 |
|
Datasheet |
ASL60 (60W) | Bulk | Active | Open Frame | 2 | 90 ~ 264 VAC | 5V | 15V | - | - | - | - | 5 A | 2.4 A | - | - | - | - | 36W | ITE (Commercial), Medical | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.24" H (101.6mm x 50.8mm x 31.6mm) |
|
TMPW 50-115-JAC/DC CONVERTER 15V 50W |
4,899 |
|
Datasheet |
TMPW 50-J (50W) | Box | Active | Enclosed | 1 | 90 ~ 305 VAC, 100 ~ 250 VDC | 15V | - | - | - | - | - | 3.333 A | - | - | - | - | - | 50W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 70°C (With Derating) | - | Chassis Mount | 3.82" L x 1.90" W x 1.00" H (97.0mm x 48.3mm x 25.4mm) |
|
LOF225-20B36AC/DC CONVERTER 36V 140W |
3,729 |
|
Datasheet |
LOF225-20Bxx (225W) | Tray | Not For New Designs | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 36V | - | - | - | - | - | 3.88 A | - | - | - | - | - | 140W | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, PFC, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.00" H (101.6mm x 50.8mm x 25.4mm) |
|
ZPS60-48AC/DC CONVERTER 48V 60W |
2,875 |
|
Datasheet |
ZP60 (60W) | Bulk | Not For New Designs | Open Frame | 1 | 90 ~ 264 VAC | 48V | - | - | - | - | - | 1.25 A | - | - | - | - | - | 60W | ITE (Commercial) | 3 kV | 0°C ~ 70°C (With Derating) | DC Input Capable, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.07" H (101.6mm x 50.8mm x 27.1mm) |
|
VOF-100C-27-CNFAC/DC CONVERTER 27V 100W |
4,482 |
|
Datasheet |
VOF-100C-CNF (100W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 27V | - | - | - | - | - | 3.7 A | - | - | - | - | - | 100W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 3.15" L x 2.44" W x 1.57" H (80.0mm x 62.0mm x 40.0mm) |
|
VMS-100C-36-CNFAC/DC CONVERTER 36V 100W |
4,989 |
|
Datasheet |
VMS-100C-CNF (100W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 36V | - | - | - | - | - | 2.78 A | - | - | - | - | - | 100W | Household Appliances, Medical | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 3.15" L x 2.44" W x 1.57" H (80.0mm x 62.0mm x 40.0mm) |
|
VMS-100C-15-CNFAC/DC CONVERTER 15V 100W |
2,098 |
|
Datasheet |
VMS-100C-CNF (100W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 15V | - | - | - | - | - | 6.66 A | - | - | - | - | - | 100W | Household Appliances, Medical | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 3.15" L x 2.44" W x 1.57" H (80.0mm x 62.0mm x 40.0mm) |
|
LMF150-23B15-CAC/DC CONVERTER 15V 150W |
1,409 |
|
Datasheet |
LMF150-23Bxx-C (150W) | Box | Not For New Designs | Enclosed | 1 | 85 ~ 305 VAC, 120 ~ 430 VDC | 15V | - | - | - | - | - | 10 A | - | - | - | - | - | 150W | Household Appliances, ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | PFC, Remote On/Off, Universal Input | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
MAD40US12DAC/DC CONVERTER 12V 40W |
3,522 |
|
Datasheet |
MAD40 Single (40W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 12V | - | - | - | - | - | 3.34 A | - | - | - | - | - | 40W | ITE (Commercial), Medical | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 3.00" L x 2.00" W x 0.94" H (76.2mm x 50.8mm x 23.9mm) |
