Rotary Potentiometers, Rheostats
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Resistance (Ohms) | Tolerance | Power (Watts) | Built in Switch | Number of Turns | Features | Taper | Number of Gangs | Adjustment Type | Temperature Coefficient | Rotation | Resistive Material | Termination Style | Actuator Type | Actuator Length | Actuator Diameter | Bushing Thread | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
8148R2KL.25SSPRECISION ROTARY POTENTIOMETER |
4,175 |
|
- |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
M-22S10 50KPOT 50K OHM 2W WIREWOUND LINEAR |
4,220 |
|
Datasheet |
M-22 | Bulk | Active | 50k | ±0.2% | 2W | None | 10.0 | - | Linear | 1 | User Defined | ±50ppm/°C | 3600° | Wirewound | Solder Lug | Slotted | 0.906" (23.00mm) | 0.236" (6.00mm) | M9 x 0.75 | Panel Mount |
|
M-22S10 500POT 500 OHM 2W WIREWOUND LINEAR |
3,578 |
|
Datasheet |
M-22 | Bulk | Active | 500 | ±0.2% | 2W | None | 10.0 | - | Linear | 1 | User Defined | ±50ppm/°C | 3600° | Wirewound | Solder Lug | Slotted | 0.906" (23.00mm) | 0.236" (6.00mm) | M9 x 0.75 | Panel Mount |
|
M-22S10 200POT 200 OHM 2W WIREWOUND LINEAR |
4,228 |
|
Datasheet |
M-22 | Bulk | Active | 200 | ±0.2% | 2W | None | 10.0 | - | Linear | 1 | User Defined | ±50ppm/°C | 3600° | Wirewound | Solder Lug | Slotted | 0.906" (23.00mm) | 0.236" (6.00mm) | M9 x 0.75 | Panel Mount |
|
M-22S10 100POT 100 OHM 2W WIREWOUND LINEAR |
1,407 |
|
Datasheet |
M-22 | Bulk | Active | 100 | ±0.2% | 2W | None | 10.0 | - | Linear | 1 | User Defined | ±50ppm/°C | 3600° | Wirewound | Solder Lug | Slotted | 0.906" (23.00mm) | 0.236" (6.00mm) | M9 x 0.75 | Panel Mount |
|
P11S2V0FRSX00R0149POT CERMET |
1,543 |
|
Datasheet |
P11S | Box | Active | - | - | - | - | 1.0 | - | - | 2 | Side Adjustment | ±500ppm/°C | 300° | Cermet | PC Pins | Slotted | 1.969" (50.00mm) | 0.236" (6.00mm) | M10 x 0.75 | Panel Mount |
|
P11S2V0FRSX00R0085POT CERMET |
2,658 |
|
Datasheet |
P11S | Box | Active | - | - | - | - | 1.0 | - | - | 2 | Side Adjustment | ±500ppm/°C | 300° | Cermet | PC Pins | Slotted | 1.969" (50.00mm) | 0.236" (6.00mm) | M10 x 0.75 | Panel Mount |
|
P11L3F0GJSX13502KAPOT 5K OHM 1/10W CERMET LINEAR |
1,335 |
|
Datasheet |
P11L | Box | Active | 5k | ±10% | 0.1W, 1/10W | - | 1.0 | Long Life | Linear | 3 | Side Adjustment | ±150ppm/°C | 300° | Cermet | PC Pins | Slotted | 0.875" (22.23mm) | 0.250" (6.35mm) | 3/8-32 | Panel Mount |
|
P11S3F0GGSY00102KAPOT 1K OHM 1W CERMET LINEAR |
2,691 |
|
Datasheet |
P11S | Box | Active | 1k | ±10% | 1W | - | 1.0 | - | Linear | 3 | User Defined | ±500ppm/°C | 300° | Cermet | Solder Lug | Slotted | 0.625" (15.88mm) | 0.250" (6.35mm) | 3/8-32 | Panel Mount |
|
P11S3F0GGSZ10503KAPOT 50K OHM 1W CERMET LINEAR |
4,449 |
|
Datasheet |
P11S | Box | Active | 50k | ±10% | 1W | - | 1.0 | - | Linear | 3 | Side Adjustment | ±500ppm/°C | 300° | Cermet | PC Pins | Slotted | 0.625" (15.88mm) | 0.250" (6.35mm) | 3/8-32 | Panel Mount |
|
P11S3V0FLSY00104KAPOT 100K OHM 1W CERMET LINEAR |
1,172 |
|
Datasheet |
P11S | Box | Active | 100k | ±10% | 1W | - | 1.0 | - | Linear | 3 | User Defined | ±500ppm/°C | 300° | Cermet | Solder Lug | Slotted | 0.984" (25.00mm) | 0.236" (6.00mm) | M10 x 0.75 | Panel Mount |
|
P9A2R0PMFFRX1103MAPOT |
4,655 |
|
- |
* | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
86A2A-B24-A15/R51LPOT 10K OHM 2W CERMET LINEAR |
4,971 |
|
Datasheet |
86 | Tray | Active | 10k | ±10% | 2W | Rotary, DPST | 1.0 | - | Linear | 1 | User Defined | ±150ppm/°C | 300° | Cermet | Solder Hook | Slotted | 0.750" (19.05mm) | 0.250" (6.35mm) | 3/8-32 | Panel Mount |
|
14921B0BBSY03103KAPOT CERMET ELEMENT |
1,889 |
|
Datasheet |
* | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
P11A2Q0EBSX03103KLPOT 10K OHM 1/4W PLASTIC LOG |
1,532 |
|
Datasheet |
P11A | Box | Active | 10k | ±10% | 0.25W, 1/4W | - | 1.0 | - | Logarithmic | 2 | Side Adjustment | ±500ppm/°C | 300° | Conductive Plastic | PC Pins | Slotted | 0.492" (12.50mm) | 0.157" (4.00mm) | M7 x 0.75 | Panel Mount |
|
6186R2KL.5LTPRECISION ROTARY POTENTIOMETER |
4,992 |
|
- |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
14921A0BBSY03102KAPOT CERMET ELEMENT |
3,366 |
|
Datasheet |
* | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
P11S2V0FLSY00R0037POT CERMET |
4,854 |
|
Datasheet |
P11S | Box | Active | - | - | - | - | 1.0 | - | - | 2 | User Defined | ±500ppm/°C | 300° | Cermet | Solder Lug | Slotted | 0.984" (25.00mm) | 0.236" (6.00mm) | M10 x 0.75 | Panel Mount |
|
M-1303 500POT 500 OHM 3/4W WIREWOUND LIN |
1,174 |
|
Datasheet |
M-13 | Bulk | Active | 500 | ±5% | 0.75W, 3/4W | None | 3.0 | - | Linear | 1 | User Defined | ±50ppm/°C | 1080° | Wirewound | Solder Lug | Slotted | 0.650" (16.50mm) | 0.118" (3.00mm) | M6 x 0.75 | Panel Mount |
|
M-1303 2KPOT 2K OHM 3/4W WIREWOUND LINEAR |
2,309 |
|
Datasheet |
M-13 | Bulk | Active | 2k | ±5% | 0.75W, 3/4W | None | 3.0 | - | Linear | 1 | User Defined | ±50ppm/°C | 1080° | Wirewound | Solder Lug | Slotted | 0.650" (16.50mm) | 0.118" (3.00mm) | M6 x 0.75 | Panel Mount |
