Pushbutton Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Marking | Color - Actuator/Cap | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Ingress Protection | Features | Panel Cutout Dimensions | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
C1S01-R121G-H1016MM/GN/MAINTAINED/2NO2NC |
1,748 |
|
Datasheet |
- | Box | Active | Panel Mount, Front | Standard | DPDT | On-On | 5A (AC), 1A (DC) | 125 V | 30 V | Round, Button | - | Green | - | - | Solder, Quick Connect - 0.110" (2.8mm) | IP65 - Dust Tight, Water Resistant | - | Circular - 16.00mm Dia | -25°C ~ 55°C |
|
C1S02-R121Y-H1016MM/YL/MOMENTARY/2NO2NC |
2,934 |
|
- |
- | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
C1S01-R121R-H1016MM/R/MAINTAINED/2NO2NC |
4,427 |
|
Datasheet |
- | Box | Active | Panel Mount, Front | Standard | DPDT | On-On | 5A (AC), 1A (DC) | 125 V | 30 V | Round, Button | - | Red | - | - | Solder, Quick Connect - 0.110" (2.8mm) | IP65 - Dust Tight, Water Resistant | - | Circular - 16.00mm Dia | -25°C ~ 55°C |
|
C1S02-R121B-H1116MM/BL/MOMENTARY/1NO1NC |
4,332 |
|
- |
- | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
C1S01-R121R-H1116MM/R/MAINTAINED/1NO1NC |
3,381 |
|
Datasheet |
- | Box | Active | Panel Mount, Front | Standard | SPDT | On-On | 5A (AC), 1A (DC) | 125 V | 30 V | Round, Button | - | Red | - | - | Solder, Quick Connect - 0.110" (2.8mm) | IP65 - Dust Tight, Water Resistant | - | Circular - 16.00mm Dia | -25°C ~ 55°C |
|
C1S02-R121Y-H1116MM/YL/MOMENTARY/1NO1NC |
2,910 |
|
- |
- | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
C1S01-R121Y-H1016MM/YL/MAINTAINED/2NO2NC |
3,406 |
|
Datasheet |
- | Box | Active | Panel Mount, Front | Standard | DPDT | On-On | 5A (AC), 1A (DC) | 125 V | 30 V | Round, Button | - | Yellow | - | - | Solder, Quick Connect - 0.110" (2.8mm) | IP65 - Dust Tight, Water Resistant | - | Circular - 16.00mm Dia | -25°C ~ 55°C |
|
C1S02-R121G-H1016MM/GN/MOMENTARY/2NO2NC |
3,300 |
|
- |
- | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
C1S02-R121G-H1116MM/GN/MOMENTARY/1NO1NC |
2,834 |
|
- |
- | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
GHNERBRNSWITCH PB SPDT 2A 48VDC |
1,781 |
|
Datasheet |
GH | Tray | Active | Panel Mount, Front | Anti-Vandal, Illuminated | SPST | On-Mom | 2A (DC) | - | 48 V | Round, Button | - | Red | LED, Red | 2.1 VDC | Solder Lug | IP40 | - | Circular - 10.00mm Dia | -25°C ~ 55°C |
|
CH1NBBG6SSWITCH PB SPDT 1A 125VAC |
3,425 |
|
Datasheet |
CH | Tray | Active | Panel Mount, Front | Anti-Vandal, Illuminated | SPDT | On-Mom | 1A (AC/DC) | 125 V | 24 V | Round, Button, Flush | - | Black | LED, Green | 6 VDC | Solder Lug | IP67 - Dust Tight, Waterproof | - | Circular - 16.00mm Dia | -25°C ~ 70°C |
|
EH12NMSS3BXSWITCH PB SPST-NO 2A 48V |
4,680 |
|
Datasheet |
EH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST-NO | Off-Mom | 2A (DC) | - | 48 V | Round, Button | - | Red | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | Stainless Steel | Circular - 12.00mm Dia | -20°C ~ 70°C |
|
EH12NMSS7BXSWITCH PB SPST-NO 2A 48V |
2,156 |
|
Datasheet |
EH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST-NO | Off-Mom | 2A (DC) | - | 48 V | Round, Button | - | Blue | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | Stainless Steel | Circular - 12.00mm Dia | -20°C ~ 70°C |
|
EH12NMSS4BXSWITCH PB SPST-NO 2A 48V |
1,963 |
|
Datasheet |
EH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST-NO | Off-Mom | 2A (DC) | - | 48 V | Round, Button | - | Yellow | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | Stainless Steel | Circular - 12.00mm Dia | -20°C ~ 70°C |
|
EH12NMSS2BXSWITCH PB SPST-NO 2A 48V |
1,892 |
|
Datasheet |
EH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST-NO | Off-Mom | 2A (DC) | - | 48 V | Round, Button | - | Black | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | Stainless Steel | Circular - 12.00mm Dia | -20°C ~ 70°C |
|
EH12NMSS5BXSWITCH PB SPST-NO 2A 48V |
2,858 |
|
Datasheet |
EH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST-NO | Off-Mom | 2A (DC) | - | 48 V | Round, Button | - | Green | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | Stainless Steel | Circular - 12.00mm Dia | -20°C ~ 70°C |
|
C1S02-R121B-H1016MM/BL/MOMENTARY/2NO2NC |
1,283 |
|
- |
- | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
C1S01-R121G-H1116MM/GN/MAINTAINED/1NO1NC |
2,855 |
|
Datasheet |
- | Box | Active | Panel Mount, Front | Standard | SPDT | On-On | 5A (AC), 1A (DC) | 125 V | 30 V | Round, Button | - | Green | - | - | Solder, Quick Connect - 0.110" (2.8mm) | IP65 - Dust Tight, Water Resistant | - | Circular - 16.00mm Dia | -25°C ~ 55°C |
|
FHNDRBXSWITCH PB SPST 2A 48VDC |
4,419 |
|
Datasheet |
FH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST | Off-Mom | 2A (DC) | - | 48 V | Round, Button | - | Red | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | - | Circular - 12.00mm Dia | -25°C ~ 55°C |
|
FHNAUBXSWITCH PB SPST 2A 48VDC |
1,248 |
|
Datasheet |
FH | Tray | Active | Panel Mount, Front | Anti-Vandal | SPST | Off-Mom | 2A (DC) | - | 48 V | Round, Button, Flush | - | Blue | - | - | Solder Lug | IP67 - Dust Tight, Waterproof | - | Circular - 12.00mm Dia | -25°C ~ 55°C |
