Pushbutton Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Marking | Color - Actuator/Cap | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Ingress Protection | Features | Panel Cutout Dimensions | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ZB5AW045COMPLETE BODY/CONTACT ASSEMBLY A |
3,582 |
|
Datasheet |
Harmony XB5 | Box | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO/NC | On-Off, Off-On | 6A (AC), 550mA (DC) | 120 V | 125 V | Rectangular, Button (Not Included) | - | - | - | 110 ~ 220 VAC | Screw Terminal | - | - | - | -40°C ~ 70°C |
|
2PB273-T2SWITCH PUSH SPDTX2 5A 250V |
2,155 |
|
Datasheet |
PB | Bulk | Active | Panel Mount, Rear | Standard | SPDT x 2 | On-Mom | 5A (AC/DC) | 250 V | 30 V | Round, Plunger | No Marking | Green | - | - | Solder Turret | - | - | - | - |
|
1PB43SWITCH PUSHBUTTON SPDT 5A 250V |
4,871 |
|
Datasheet |
PB | Bulk | Active | Panel Mount, Front | Standard | SPDT | On-Mom | 5A (AC/DC) | 250 V | 30 V | Round, Button | No Marking | Red | - | - | Solder Lug | - | - | - | - |
|
73-00001.2SWITCH PB SPST-NOX2 0.1A 30V |
3,866 |
|
Datasheet |
84 SmartBox | Bulk | Active | Chassis Mount | Standard, Illuminated | SPST-NO x 2 | Off-Mom | 100mA (DC) | - | 30 V | Round, Button | No Marking | Red, Green | LED, White | - | Connector | IP67 - Dust Tight, Waterproof | - | - | -25°C ~ 70°C |
|
A2W-TC-WC1 US1YBSWITCH PB MUSHRM YEL WIRELESS |
3,244 |
|
Datasheet |
A2W | Bulk | Active | Chassis Mount | Standard | - | - | - | - | - | Round, Button, Mushroom | No Marking | Yellow | - | - | Wireless | IP65 - Dust Tight, Water Resistant | - | - | -10°C ~ 55°C |
|
A2W-TC-WC1 US2RBSWITCH PB FULLGD RED WIRELESS |
4,055 |
|
Datasheet |
A2W | Bulk | Active | Chassis Mount | Standard | - | - | - | - | - | Round, Button, Full Guard | No Marking | Red | - | - | Wireless | IP65 - Dust Tight, Water Resistant | - | - | -10°C ~ 55°C |
|
A2W-TC-WC1 US2BYWIRELESS PB FULL GRD BLK YEL |
3,624 |
|
Datasheet |
A2W | Bulk | Active | Chassis Mount | Standard | - | - | - | - | - | Round, Button, Full Guard | No Marking | Black | - | - | Wireless | IP65 - Dust Tight, Water Resistant | - | - | -10°C ~ 55°C |
|
DX80N9Q45BL-NHSWITCH PUSHBUTTON WIRELESS |
3,386 |
|
Datasheet |
Q45BL | Bulk | Active | Chassis Mount | Standard | - | - | - | - | - | Round, Button | No Marking | - | - | - | Wireless | IP67 - Dust Tight, Waterproof | - | - | -40°C ~ 70°C |
|
SG-C1-21ENABLE GRIP SWITCH |
1,062 |
|
Datasheet |
SG-C1 | Bulk | Active | Free Hanging | - | - | Off-On | 1A (AC/DC) | 125 V | 30 V | - | No Marking | - | - | - | Solder Lug | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | -25°C ~ 60°C |
|
50HA109659CUSTOM STATION-GE LOCOMOTIVE |
3,343 |
|
- |
- | Box | Active | - | Standard | DPST-NO/NC | On-Mom, Off-Mom | - | - | - | - | - | Red | - | - | - | - | - | - | - |
|
US2:50HA1E811RCUSTOM STATION-GE LOCOMOTIVE |
2,150 |
|
- |
- | Box | Active | - | Standard | DPST-NC | On-Mom | - | - | - | - | - | Red | - | - | - | - | - | - | - |
|
DX80N9Q120BL-RGSWITCH PB PENDANT NODE 900MHZ |
4,397 |
|
Datasheet |
Q120BL | Bulk | Active | Chassis Mount | Standard | - | - | - | - | - | Round, Button | No Marking | Black | - | - | Wireless | IP67 - Dust Tight, Waterproof | - | - | -40°C ~ 70°C |
|
|
C4V-811A-DSWITCH PUSHBUTTON SPST 8A 125V |
4,507 |
|
Datasheet |
C4V | Tray | Active | Panel Mount, Side | Standard | SPST | Off-On | 8A (AC) | 125 V | - | Square, Plunger | No Marking | - | - | - | Quick Connect - 0.187" (4.7mm) | - | - | - | -10°C ~ 55°C |
|
SW-PB9-AAB00A2RE-6SEALED SUBMINIATIURE PUSHBUTTON |
3,864 |
|
Datasheet |
SW | Box | Active | Through Hole, Right Angle | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Round, Plunger | No Marking | - | - | - | PC Pin | IP67 - Dust Tight, Waterproof | - | - | -30°C ~ 85°C |
|
MPB01-1B54-S-CAP-R-DSPST, THROUGH HOLE, 5.4 MM PUSH, |
1,843 |
|
Datasheet |
MPB01 | Bag | Active | Through Hole | Standard | SPST-NO | Off-Mom | 14mA (DC) | - | 28 V | Round, Button | No Marking | Red | - | - | PC Pin | - | - | - | -25°C ~ 80°C |
|
SW-PB8-AA22A2QE-3ALTERNATE ACTING PUSHBUTTON SWIT |
4,744 |
|
Datasheet |
SW | Box | Active | Panel Mount, Rear | Standard | SPDT | On-On | 6A (AC/DC) | 125 V | 28 V | Round, Button | No Marking | Black | - | - | PC Pin | - | - | - | -30°C ~ 85°C |
|
G3PB004G3 STAINLESS STEEL DOUBLE PUSH P |
2,155 |
|
Datasheet |
- | Bulk | Active | - | - | - | - | - | - | - | - | No Marking | - | - | - | - | - | - | - | - |
|
ESANML2GBRSWITCH PB SPST-NO 125MA 125V |
4,336 |
|
Datasheet |
ES | Tray | Active | Panel Mount, Front | Standard, Illuminated | SPST-NO | Off-Mom | 125mA (AC/DC) | 125 V | 50 V | Round, Button | No Marking | Black | LED, Red | 2.1 VDC | Solder Lug | IP67 - Dust Tight, Waterproof | - | Circular - 13.60mm Dia | -30°C ~ 85°C |
|
EP11S2D1ABESWITCH PUSH SPST-NO 0.4VA 20V |
1,005 |
|
Datasheet |
EP | Tray | Active | Through Hole, Right Angle | Standard | SPST-NO | Off-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Round, Plunger | No Marking | Black | - | - | PC Pin | IP57 - Dust Protected, Waterproof | Epoxy Sealed Terminals | - | -30°C ~ 85°C |
|
TP12SH8ABESWITCH PUSH SPDT 0.4VA 20V |
3,957 |
|
Datasheet |
TP | Bulk | Active | Through Hole, Right Angle | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 20 V | 20 V | Round, Plunger | No Marking | Black | - | - | PC Pin | - | Sealed | - | -30°C ~ 85°C |
