Pushbutton Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Marking | Color - Actuator/Cap | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Ingress Protection | Features | Panel Cutout Dimensions | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MB-1605-TL-QSWITCH MOMENTARY16MM 5A 36V 1NO |
1,795 |
|
- |
- | Retail Package | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
A22NN-BNM-NWA-G112-NNPUSHBUTTON SWITCH |
2,971 |
|
Datasheet |
A22NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-2NO/1NC | On-Mom, Off-Mom | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Flush | - | White | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 70°C |
|
A22NN-BGM-NGA-P222-NNPUSHBUTTON SWITCH |
2,247 |
|
Datasheet |
A22NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-NC | On-Mom | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Full Guard (Clear) | - | Green | - | - | Spring Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 70°C |
|
A30NN-MMM-NYA-P111-NNPUSHBUTTON SWITCH |
3,884 |
|
Datasheet |
A30NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-NO | Off-Mom | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Mushroom | - | Yellow | - | - | Spring Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 30.50mm Dia | -25°C ~ 70°C |
|
A30NN-MNA-NAA-G122-NNPUSHBUTTON SWITCH |
1,054 |
|
Datasheet |
A30NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-2NC/1NO | On-Off, Off-On | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Flush | - | Blue | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 30.50mm Dia | -25°C ~ 70°C |
|
A30NN-MPA-NAA-G111-NNPUSHBUTTON SWITCH |
4,672 |
|
Datasheet |
A30NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-NO | Off-On | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button | - | Blue | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 30.50mm Dia | -25°C ~ 70°C |
|
A22NL-MMA-TRA-G100-RCSWITCH PUSH |
1,630 |
|
Datasheet |
A22NL | Bulk | Active | Panel Mount, Front | Standard, Illuminated | SPST-NO | Off-On | 10A (AC/DC) | 120 V | 24 V | Round, Button, Mushroom | No Marking | Clear (Red Filter/Diffuser) | LED, Red | 24 VAC/DC | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 55°C |
|
A22NN-MNA-NGA-G222-NNPUSHBUTTON SWITCH |
3,520 |
|
Datasheet |
A22NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-NC | On-Off | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Flush | - | Green | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 70°C |
|
A22NN-MGA-NGA-G122-NNPUSHBUTTON SWITCH |
2,820 |
|
Datasheet |
A22NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-2NC/1NO | On-Off, Off-On | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Full Guard (Clear) | - | Green | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 70°C |
|
A22NN-BMA-NYA-G222-NNPUSHBUTTON SWITCH |
3,217 |
|
Datasheet |
A22NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-NC | On-Off | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Mushroom | - | Yellow | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 70°C |
|
A30NN-MNM-NGA-G222-NNPUSHBUTTON SWITCH |
3,895 |
|
Datasheet |
A30NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-NC | On-Mom | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Flush | - | Green | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 30.50mm Dia | -25°C ~ 70°C |
|
A22NL-MMA-TGA-G101-GESWITCH PUSH |
4,495 |
|
Datasheet |
A22NL | Bulk | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO | Off-On | 10A (AC/DC) | 120 V | 24 V | Round, Button, Mushroom | No Marking | Clear (Green Filter/Diffuser) | LED, Green | 200 ~ 240 VAC | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 55°C |
|
A22NN-BMM-NGA-G102-NNPUSHBUTTON SWITCH |
3,684 |
|
Datasheet |
A22NN | Bulk | Active | Panel Mount, Front | Standard | DPST-NO/NC | On-Mom, Off-Mom | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Mushroom | - | Green | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 70°C |
|
A30NN-MGM-NWA-P101-NNPUSHBUTTON SWITCH |
2,947 |
|
Datasheet |
A30NN | Bulk | Active | Panel Mount, Front | Standard | DPST-NO | Off-Mom | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Full Guard (Clear) | - | White | - | - | Spring Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 30.50mm Dia | -25°C ~ 70°C |
|
A22NN-MGM-NAA-G111-NNPUSHBUTTON SWITCH |
3,006 |
|
Datasheet |
A22NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-NO | Off-Mom | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Full Guard (Clear) | - | Blue | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 70°C |
|
A22NN-MNA-NAA-P111-NNPUSHBUTTON SWITCH |
3,581 |
|
Datasheet |
A22NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-NO | Off-On | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Flush | - | Blue | - | - | Spring Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 70°C |
|
A22NL-MNA-TRA-G101-RESWITCH PUSH DPST-NO 10A 120V |
2,011 |
|
Datasheet |
A22NL | Bulk | Active | Panel Mount, Front | Standard, Illuminated | DPST-NO | Off-On | 10A (AC/DC) | 120 V | 24 V | Round, Button, Flush | No Marking | Clear (Red Filter/Diffuser) | LED, Red | 200 ~ 240 VAC | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 55°C |
|
A30NN-MMM-NAA-P100-NNPUSHBUTTON SWITCH |
3,279 |
|
Datasheet |
A30NN | Bulk | Active | Panel Mount, Front | Standard | SPST-NO | Off-Mom | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Mushroom | - | Blue | - | - | Spring Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 30.50mm Dia | -25°C ~ 70°C |
|
A30NN-MNA-NRA-G222-NNPUSHBUTTON SWITCH |
1,124 |
|
Datasheet |
A30NN | Bulk | Active | Panel Mount, Front | Standard | 3PST-NC | On-Off | 10A (AC), 8A (DC) | 120 V | 24 V | Round, Button, Flush | - | Red | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 30.50mm Dia | -25°C ~ 70°C |
|
A22NL-MNA-TAA-P100-AESWITCH PUSH |
3,909 |
|
Datasheet |
A22NL | Bulk | Active | Panel Mount, Front | Standard, Illuminated | SPST-NO | Off-On | 10A (AC/DC) | 120 V | 24 V | Round, Button, Flush | No Marking | Clear (Blue Filter/Diffuser) | LED, Blue | 200 ~ 240 VAC | Spring Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 55°C |
