Limit Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Mounting Type | Termination Style | Ingress Protection | Features | Operating Force | Release Force | Operating Position | Pretravel | Differential Travel | Overtravel | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
11HM41SWITCH SIM ROLL LEVER SPDT 3A |
2,811 |
|
Datasheet |
HM | Bulk | Active | SPDT | On-Mom | - | - | - | Lever, Straight | Chassis Mount | Solder Lug | - | - | 198gf | 28gf | 0.330" (8.4mm) | 0.030" (0.8mm) | 0.003" (0.075mm) | 0.003" (0.076mm) | -184°C ~ 121°C |
|
|
L1492MSWITCH SNAP ACTION DPST 20A 120V |
3,665 |
|
- |
L100/300 | Bulk | Active | DPST-NO (DM) | Off-Mom | 20A (AC), 5A (DC) | 120 V | 120 V | Top Rotary - No Lever | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -23°C ~ 85°C |
|
WBX1A12ABA3SWITCH SNAP ACTION SPDT |
2,516 |
|
Datasheet |
WBX | Bulk | Obsolete | SPDT | On-Mom | - | - | - | Side Rotary - No Lever | Chassis Mount | Wireless | IP67 - Dust Tight, Waterproof | Actuator Mounted Right Side | 46gfm | - | - | 17.5° | 7° | 60° | -40°C ~ 70°C |
|
|
XCRE181TGLIMIT SWITCH METAL CROSS RODS 6M |
4,895 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
18CX10ESWITCH SNAP ACTION LIMIT |
4,480 |
|
Datasheet |
CX | Bulk | Obsolete | - | - | - | - | - | - | Chassis Mount | Screw Terminal | IP66 - Dust Tight, Water Resistant | Explosion Proof | 50gfm | - | - | 15° | 10° | 90° | -25°C ~ 85°C |
|
|
LSXA3K-2JSWITCH SNAP ACTION SPDT 10A 120V |
2,714 |
|
Datasheet |
LSX | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary, Adjustable Roller | Chassis Mount | Screw Terminal | - | Nylon Roller, Front Mounted | 46gfm | - | - | 15° | 5° | 60° | -12°C ~ 121°C |
|
|
4HS19SWITCH SNAP ACT SPDT 0.5A 125V |
3,133 |
|
Datasheet |
HS | Bulk | Active | SPDT | On-Mom | 500mA (AC), 10A (DC) | 125 V | 28 V | Lever, Roller | Chassis Mount | Wire Leads | - | - | 283 ~ 624gf | 113gf | 0.806" (20.5mm) | 0.065" (1.65mm) | 0.020" (0.5mm) | 0.010" (0.25mm) | -54°C ~ 105°C |
|
|
L300WS1M2SWITCH LIMIT DPST 20A 120V |
2,522 |
|
Datasheet |
L100/300 | Bulk | Active | DPST-NO (DM) | On-Mom | 20A (AC), 5A (DC) | 120 V | 120 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -23°C ~ 85°C |
|
|
L300WS1M1SWITCH LIMIT 12A 600V |
2,213 |
|
Datasheet |
L300 | Bulk | Active | - | - | 12A (AC) | 600 V | - | - | - | - | - | - | - | - | - | - | - | - | -18°C ~ 93°C |
|
|
4HS155-320SWITCH SNAP ACT SPDT 0.5A 125V |
2,501 |
|
Datasheet |
HS | Bulk | Active | SPDT | On-Mom | 500mA (AC), 10A (DC) | 125 V | 28 V | Lever, Roller | Chassis Mount | Wire Leads | - | - | 283 ~ 624gf | 113gf | 1.070" (27.2mm) | 0.065" (1.65mm) | 0.020" (0.5mm) | 0.032" (0.81mm) | -54°C ~ 121°C |
|
|
9007TSA1SWITCH LIMIT SPDT 20A 120V |
4,863 |
|
Datasheet |
9007 | Box | Active | SPDT (DB/DM) | On-Mom | 20A (AC), 5A (DC) | 120 V | 120 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -23°C ~ 85°C |
|
|
201LS6SWITCH SNAP ACTION SPDT 10A 120V |
3,814 |
|
Datasheet |
LS | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary, Roller | Chassis Mount | Plug In | IP67 - Dust Tight, Waterproof | Steel Roller, Front Mounted | 19gfm | 3.225gfm | 20° | 20° | 12° | 30° | -29°C ~ 71°C |
|
|
51.262RFOOT SWITCHFS2U1DU1S(2X)USTDGDAT |
3,481 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
9007AW48SWITCH LIMIT 10A 600V |
4,965 |
|
Datasheet |
Square D 9007AW | Box | Active | - | - | 10A (AC) | 600 V | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
TL4024-30242SWITCH SNAP ACTION 24V |
4,531 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
L100WTLN2C2M41SWITCH LIMIT 3PDT 6A 120V |
1,384 |
|
Datasheet |
L100/300 | Bulk | Active | 3PDT (DB/DM) | On-Mom | 6A (AC) | 120 V | - | Side Rotary - No Lever | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -23°C ~ 85°C |
|
24CE2-S2SWITCH SNAP ACTION SPDT 5A 250V |
3,022 |
|
Datasheet |
24CE | Bulk | Active | SPDT (BBM) | On-Mom | 5A (AC) | 250 V | - | Roller Plunger | Chassis Mount | Cable Leads | IP67 - Dust Tight, Waterproof | Cable Length 2m | 2300gf | - | - | 0.087" (2.2mm) | - | 0.040" (1.0mm) | 0°C ~ 70°C |
|
|
21CH186-6SEALED SWITCH |
1,961 |
|
Datasheet |
- | Bulk | Active | SPST-NC | On-Off | 4A (DC) | - | 28 V | Lever, Roller | Panel Mount | Wire Leads | - | - | 2722 ~ 5443gf | 1814gf | - | 0.040" (1.0mm) | 0.020" (0.51mm) | 0.250" (6.35mm) | - |
|
|
LSXYAC3KSWITCH SNAP ACTION SPDT 10A 120V |
3,739 |
|
Datasheet |
LSX | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | - | Fluorocarbon Sealed | 46gfm | - | - | 15° | 5° | 60° | -12°C ~ 121°C |
|
|
616.2840.655FOOT SWITCH DOUBLEPEDAL F2-SU1YS |
3,814 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
