DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
OD5010-05LSS01AFAN AXIAL 50X10.5MM 5VDC WIRE |
2,445 |
|
Datasheet |
OD5010 | Bulk | Active | 5VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5010-05LSS02AFAN AXIAL 50X10.5MM 5VDC WIRE |
1,439 |
|
Datasheet |
OD5010 | Bulk | Active | 5VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Locked Rotor Sensor | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5010-05MSS01AFAN AXIAL 50X10.5MM 5VDC WIRE |
2,860 |
|
Datasheet |
OD5010 | Bulk | Active | 5VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5010-05MSS02AFAN AXIAL 50X10.5MM 5VDC WIRE |
4,985 |
|
Datasheet |
OD5010 | Bulk | Active | 5VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Locked Rotor Sensor | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5010-12HHHSS01AFAN AXIAL 50X10.5MM 12VDC WIRE |
3,345 |
|
Datasheet |
OD5010 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5010-12HSS01AFAN AXIAL 50X10.5MM 12VDC WIRE |
4,772 |
|
Datasheet |
OD5010 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 10.50mm | 11.2 CFM (0.314m³/min) | 0.100 in H2O (24.9 Pa) | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | 26.0dB | 1.1 W | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | cURus | - |
|
OD5010-12HSS02AFAN AXIAL 50X10.5MM 12VDC WIRE |
4,826 |
|
Datasheet |
OD5010 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 10.50mm | 11.2 CFM (0.314m³/min) | 0.100 in H2O (24.9 Pa) | Sealed Sleeve | Tubeaxial | Locked Rotor Sensor | 26.0dB | 1.1 W | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | cURus | - |
|
OD5010-12LSS01AFAN AXIAL 50X10.5MM 12VDC WIRE |
4,812 |
|
Datasheet |
OD5010 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5010-12LSS02AFAN AXIAL 50X10.5MM 12VDC WIRE |
4,584 |
|
Datasheet |
OD5010 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Locked Rotor Sensor | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5010-12MSS01AFAN AXIAL 50X10.5MM 12VDC WIRE |
3,485 |
|
Datasheet |
OD5010 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5010-12MSS02AFAN AXIAL 50X10.5MM 12VDC WIRE |
2,675 |
|
Datasheet |
OD5010 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Locked Rotor Sensor | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5010-24HSS01AFAN AXIAL 50X10.5MM 24VDC WIRE |
1,918 |
|
Datasheet |
OD5010 | Bulk | Active | 24VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5010-24MSS01AFAN AXIAL 50X10.5MM 24VDC WIRE |
4,566 |
|
Datasheet |
OD5010 | Bulk | Active | 24VDC | Square - 50mm L x 50mm H | 10.50mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | cURus | - |
|
OD5015-12HHSS01AFAN AXIAL 50X15MM 12VDC WIRE |
4,076 |
|
Datasheet |
OD5015 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 15.00mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | cURus, TUV | - |
|
OD5015-12HHSS02AFAN AXIAL 50X15MM 12VDC WIRE |
1,684 |
|
Datasheet |
OD5015 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 15.00mm | - | - | Sealed Sleeve | Tubeaxial | Locked Rotor Sensor | - | - | - | 3 Wire Leads | - | - | cURus, TUV | - |
|
OD5015-12HSS01AFAN AXIAL 50X15MM 12VDC WIRE |
3,192 |
|
Datasheet |
OD5015 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 15.00mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | cURus, TUV | - |
|
OD5015-12HSS02AFAN AXIAL 50X15MM 12VDC WIRE |
1,908 |
|
Datasheet |
OD5015 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 15.00mm | - | - | Sealed Sleeve | Tubeaxial | Locked Rotor Sensor | - | - | - | 3 Wire Leads | - | - | cURus, TUV | - |
|
OD5015-12LSS01AFAN AXIAL 50X15MM 12VDC WIRE |
2,964 |
|
Datasheet |
OD5015 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 15.00mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | UR | - |
|
OD5015-12LSS02AFAN AXIAL 50X15MM 12VDC WIRE |
4,097 |
|
Datasheet |
OD5015 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 15.00mm | - | - | Sealed Sleeve | Tubeaxial | Locked Rotor Sensor | - | - | - | 3 Wire Leads | - | - | UR | - |
|
OD5015-12MSS01AFAN AXIAL 50X15MM 12VDC WIRE |
2,594 |
|
Datasheet |
OD5015 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 15.00mm | - | - | Sealed Sleeve | Tubeaxial | Speed Sensor (Tach) | - | - | - | 3 Wire Leads | - | - | UR | - |
