DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
04010SS-05M-AL-00FAN AXIAL 40X10MM 5VDC WIRE |
2,921 |
|
- |
04010SS | Box | Active | 5VDC | Square - 40mm L x 40mm H | 10.00mm | - | - | Sleeve | Tubeaxial | Auto Restart, Locked Rotor Sensor | - | - | - | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
CFM-6010V-130-205FAN AXIAL 60X10MM 12VDC WIRE |
1,183 |
|
Datasheet |
CFM-60V | Tray | Active | 12VDC | Square - 60mm L x 60mm H | 10.00mm | 12.2 CFM (0.342m³/min) | 0.080 in H2O (20.0 Pa) | omniCOOL™ Magnetic Sleeve | Tubeaxial | Auto Restart | 20.5dB(A) | 680 mW | 3000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | 0.051 lb (23.13 g) |
|
04010SS-12L-AL-00FAN AXIAL 40X10MM 12VDC WIRE |
4,151 |
|
- |
04010SS | Box | Active | 12VDC | Square - 40mm L x 40mm H | 10.00mm | 4.9 CFM (0.137m³/min) | 0.110 in H2O (27.4 Pa) | Sleeve | Tubeaxial | Auto Restart, Locked Rotor Sensor | 21.0dB(A) | 400 mW | 5500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
04010SS-24M-AL-00DC AXIAL FAN |
4,205 |
|
Datasheet |
04010SS | Box | Active | 24VDC | Square - 40mm L x 40mm H | 10.00mm | 5.7 CFM (0.160m³/min) | 0.149 in H2O (37.1 Pa) | Sleeve | Tubeaxial | Auto Restart, Locked Rotor Sensor | 24.0dB | 0.7 W | 6500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
04010SS-24L-AL-00DC AXIAL FAN |
3,574 |
|
Datasheet |
04010SS | Box | Active | 24VDC | Square - 40mm L x 40mm H | 10.00mm | 5.0 CFM (0.140m³/min) | 0.110 in H2O (27.4 Pa) | Sleeve | Tubeaxial | Auto Restart, Locked Rotor Sensor | 21.0dB | 0.58 W | 5500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
04010SS-24M-AT-00DC AXIAL FAN |
4,254 |
|
Datasheet |
04010SS | Box | Active | 24VDC | Square - 40mm L x 40mm H | 10.00mm | 5.7 CFM (0.160m³/min) | 0.149 in H2O (37.0 Pa) | Sleeve | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 24.0dB | 0.7 W | 6500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
04010SS-24N-AL-00DC AXIAL FAN |
1,551 |
|
Datasheet |
04010SS | Box | Active | 24VDC | Square - 40mm L x 40mm H | 10.00mm | 6.8 CFM (0.190m³/min) | 0.201 in H2O (50.1 Pa) | Sleeve | Tubeaxial | Auto Restart, Locked Rotor Sensor | 29.0dB | 1.1 W | 7500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
CFM-2507CF-1140-313-22DC AXIAL FAN, 25 MM SQUARE, 7 MM |
4,315 |
|
Datasheet |
CFM-25CF | Box | Active | 12VDC | Square - 25mm L x 25mm H | 7.00mm | 3.1 CFM (0.087m³/min) | 0.250 in H2O (62.3 Pa) | omniCOOL™ Magnetic Sleeve | Tubeaxial | PWM Control, Speed Sensor (Tach) | 31.4dB(A) | 2.04 W | 14000 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-2006CF-0100-189-20DC AXIAL FAN, 20 MM SQUARE, 6 MM |
2,331 |
|
Datasheet |
CFM-20CF | Box | Active | 5VDC | Square - 19.9mm L x 19.9mm H | 6.50mm | 0.600 CFM (0.017m³/min) | 0.060 in H2O (14.9 Pa) | omniCOOL™ Magnetic Sleeve | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 18.9dB(A) | 400 mW | 10000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CBM-5015CF-035-293DC BLOWER, 51.7 X 51.25 X 14.9 M |
1,592 |
|
Datasheet |
CBM-50CF | Box | Active | 5VDC | Rectangular/Rounded - 51.6mm L x 51.2mm H | 15.00mm | 2.2 CFM (0.061m³/min) | 0.270 in H2O (67.3 Pa) | omniCOOL™ Magnetic Sleeve | Blower | - | 29.3dB(A) | 700 mW | 3500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CBM-5015CF-045-348DC BLOWER, 51.7 X 51.25 X 14.9 M |
3,964 |
|
Datasheet |
CBM-50CF | Box | Active | 5VDC | Rectangular/Rounded - 51.6mm L x 51.2mm H | 15.00mm | 2.9 CFM (0.081m³/min) | 0.450 in H2O (112.1 Pa) | omniCOOL™ Magnetic Sleeve | Blower | - | 34.8dB(A) | 1.05 W | 4500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CBM-5015CF-135-293DC BLOWER, 51.7 X 51.25 X 14.9 M |
2,045 |
|
Datasheet |
CBM-50CF | Box | Active | 12VDC | Rectangular/Rounded - 51.6mm L x 51.2mm H | 15.00mm | 2.2 CFM (0.061m³/min) | 0.270 in H2O (67.3 Pa) | omniCOOL™ Magnetic Sleeve | Blower | - | 29.4dB(A) | 600 mW | 3500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CBM-5015CF-145-348DC BLOWER, 51.7 X 51.25 X 14.9 M |
1,332 |
|
Datasheet |
CBM-50CF | Box | Active | 12VDC | Rectangular/Rounded - 51.6mm L x 51.2mm H | 15.00mm | 2.9 CFM (0.081m³/min) | 0.450 in H2O (112.1 Pa) | omniCOOL™ Magnetic Sleeve | Blower | - | 34.8dB(A) | 1.44 W | 4500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CBM-4020C-130-216DC BLOWER, 40 MM SQUARE, 20 MM, |
3,527 |
|
Datasheet |
CBM-40C | Box | Active | 12VDC | Square/Rounded - 40.5mm L x 40.5mm H | 20.00mm | 1.3 CFM (0.036m³/min) | 0.050 in H2O (12.4 Pa) | omniCOOL™ Magnetic Sleeve | Blower | - | 21.6dB(A) | 0.24 W | 3000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CBM-4010C-160-267-22FAN BLOWER 39.5X10MM 12VDC WIRE |
4,638 |
|
Datasheet |
CBM-40C | Box | Active | 12VDC | Square/Rounded - 39.5mm L x 39.5mm H | 10.00mm | 1.8 CFM (0.050m³/min) | 0.160 in H2O (39.8 Pa) | omniCOOL™ Magnetic Sleeve | Blower | - | 26.7dB(A) | 1.32 W | 6000 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CBM-4010C-160-267-20FAN BLOWER 39.5X10MM 12VDC WIRE |
3,609 |
|
Datasheet |
CBM-40C | Box | Active | 12VDC | Square/Rounded - 39.5mm L x 39.5mm H | 10.00mm | 1.8 CFM (0.050m³/min) | 0.160 in H2O (39.8 Pa) | omniCOOL™ Magnetic Sleeve | Blower | - | 26.7dB(A) | 1.32 W | 6000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CBM-4010C-140-178-20FAN BLOWER 39.5X10MM 12VDC WIRE |
3,134 |
|
Datasheet |
CBM-40C | Box | Active | 12VDC | Square/Rounded - 39.5mm L x 39.5mm H | 10.00mm | 1.2 CFM (0.034m³/min) | 0.070 in H2O (17.4 Pa) | omniCOOL™ Magnetic Sleeve | Blower | - | 17.8dB(A) | 960 mW | 4000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
KD2445PFSX.11.GNFAN AXIAL 45X10MM 24VDC WIRE |
3,842 |
|
Datasheet |
MagLev® KD | Bulk | Active | 24VDC | Square - 45mm L x 45mm H | 10.00mm | - | - | Sleeve | Tubeaxial | - | - | - | - | 2 Wire Leads | - | - | - | - |
|
04015SS-24M-AA-00FAN AXIAL 40X15MM 24VDC WIRE |
4,808 |
|
- |
04015SS | Box | Active | 24VDC | Square - 40mm L x 40mm H | 15.00mm | 6.4 CFM (0.179m³/min) | 0.210 in H2O (52.3 Pa) | Sleeve | Tubeaxial | Auto Restart | 29.0dB(A) | 960 mW | 7300 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
04015SS-05M-AA-00FAN AXIAL 40X15MM 5VDC WIRE |
3,514 |
|
- |
04015SS | Bulk | Active | 5VDC | Square - 40mm L x 40mm H | 15.00mm | 6.4 CFM (0.179m³/min) | 0.210 in H2O (52.3 Pa) | Sleeve | Tubeaxial | Auto Restart | 29.0dB | 650 mW | 7300 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | - | - |
