DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
9WP1212H1011FAN AXIAL 120X38MM 12VDC WIRE |
4,535 |
|
Datasheet |
San Ace 120W | Box | Active | 12VDC | Square - 120mm L x 120mm H | 38.00mm | 99.0 CFM (2.77m³/min) | 0.283 in H2O (70.5 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 39.0dB(A) | 4.56 W | 2600 RPM | 3 Wire Leads | IP68 - Dust Tight, Waterproof | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.794 lb (360.15 g) |
|
17250VA-24N-EA-00FAN AXIAL 172.7X50.8MM 24VDC |
2,191 |
|
- |
17250VA | Bulk | Active | 24VDC | Round - 172.7mm Dia | 50.80mm | 261.3 CFM (7.32m³/min) | 0.740 in H2O (184.3 Pa) | Ball | Tubeaxial | Auto Restart | 54.0dB | 21.6 W | 3500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
|
9WPA0824P4G20180X25MM 24VDC IP68 -40C TACH PWM |
4,351 |
|
Datasheet |
San Ace 80W | Box | Active | 24VDC | Square - 80mm L x 80mm H | 25.20mm | - | - | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | - | - | - | 4 Wire Leads | IP68 - Dust Tight, Waterproof | -40 ~ 158°F (-40 ~ 70°C) | cURus, TUV | - |
|
EFB1724SHGFAN AXIAL 172X50.8MM 24VDC WIRE |
2,183 |
|
Datasheet |
EFB | Box | Active | 24VDC | Round - 172mm Dia | 50.80mm | 325.0 CFM (9.10m³/min) | 1.083 in H2O (269.8 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 59.0dB(A) | 28.08 W | 4300 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 1.9 lbs (861.8 g) |
|
|
9WPA0924P4G20192X25MM 24VDC IP68 -40C TACH PWM |
4,862 |
|
Datasheet |
San Ace 92W | Box | Active | 24VDC | Square - 92mm L x 92mm H | 25.00mm | - | - | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | - | - | - | 4 Wire Leads | IP68 - Dust Tight, Waterproof | -40 ~ 158°F (-40 ~ 70°C) | cURus, TUV | - |
|
109E4724L402FAN AXIAL 172X25.4MM 24VDC WIRE |
4,762 |
|
Datasheet |
San Ace 172 | Box | Active | 24VDC | Rectangular/Rounded - 172mm L x 147mm H | 25.40mm | 162.0 CFM (4.54m³/min) | 0.293 in H2O (73.0 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 48.0dB(A) | 10.6 W | 2500 RPM | 2 Wire Leads | - | -4 ~ 140°F (-20 ~ 60°C) | CSA, TUV, UL | 1.1 lbs (500.0 g) |
|
109E4724H4D01FAN AXIAL 172X25.4MM 24VDC WIRE |
4,223 |
|
Datasheet |
San Ace 172 | Box | Active | 24VDC | Rectangular/Rounded - 172mm L x 147mm H | 25.40mm | 226.0 CFM (6.33m³/min) | 0.542 in H2O (135.0 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 57.0dB(A) | 24 W | 3400 RPM | 3 Wire Leads | - | -4 ~ 140°F (-20 ~ 60°C) | CSA, TUV, UL | 1.1 lbs (500.0 g) |
|
109E5712P5K04FAN AXIAL 172X51MM 12VDC WIRE |
1,829 |
|
Datasheet |
San Ace 172 | Box | Active | 12VDC | Rectangular/Rounded - 172mm L x 150mm H | 51.00mm | 300.0 CFM (8.40m³/min) | 0.976 in H2O (243.0 Pa) | Ball | Tubeaxial | PWM Control, Speed Sensor (Tach) | 60.0dB(A) | 34.8 W | 4100 RPM | 4 Wire Leads | - | -4 ~ 140°F (-20 ~ 60°C) | CSA, TUV, UL | 1.7 lbs (760.0 g) |
|
EE50101S2-1000U-999FAN AXIAL 50X10MM 12VDC WIRE |
1,950 |
|
Datasheet |
EE | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 10.00mm | 11.0 CFM (0.308m³/min) | 0.110 in H2O (27.4 Pa) | Sleeve | Tubeaxial | - | 25.6dB(A) | 900 mW | 4700 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CUR, TUV, UL | 0.043 lb (19.5 g) |
|
EE50101S1-1000U-999FAN AXIAL |
1,814 |
|
Datasheet |
EE | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 10.00mm | 13.0 CFM (0.364m³/min) | 0.140 in H2O (34.9 Pa) | Sleeve | Tubeaxial | - | 30.7dB(A) | 1.08 W | 5700 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CUR, TUV, UL | - |
|
NYW14025012LL-12FAN AXIAL 140X25MM 12VDC WIRE |
2,889 |
|
Datasheet |
NYW14025 | Box | Active | 12VDC | Square - 140mm L x 140mm H | 25.00mm | 62.1 CFM (1.74m³/min) | 0.051 in H2O (12.7 Pa) | Sintec | Tubeaxial | - | 21.7dB(A) | 840 mW | 1050 RPM | 2 Wire Leads | - | - | - | - |
|
EE40100S2-1000U-999FAN AXIAL |
3,567 |
|
Datasheet |
EE | Bulk | Active | 5VDC | Square - 40mm L x 40mm H | 10.00mm | 7.1 CFM (0.199m³/min) | 0.120 in H2O (29.9 Pa) | Sleeve | Tubeaxial | - | 23.0dB(A) | 600 mW | 6100 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CUR, TUV, UL | - |
|
EE40100S1-1000U-999FAN AXIAL |
2,905 |
|
Datasheet |
EE | Bulk | Active | 5VDC | Square - 40mm L x 40mm H | 10.00mm | 8.2 CFM (0.230m³/min) | 0.190 in H2O (47.3 Pa) | Sleeve | Tubeaxial | - | 28.2dB(A) | 860 mW | 7300 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CUR, TUV, UL | - |
|
EF45101S1-1000U-999Thermal Products |
4,608 |
|
Datasheet |
EF | Bulk | Active | 12VDC | Square - 45mm L x 45mm H | 10.00mm | 10.8 CFM (0.302m³/min) | 0.160 in H2O (39.8 Pa) | Sleeve | Tubeaxial | - | 29.8dB(A) | 1.02 W | 5700 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CUR, TUV, UL | - |
|
EF45101S2-1000U-999Thermal Products |
4,789 |
|
Datasheet |
EF | Bulk | Active | 12VDC | Square - 45mm L x 45mm H | 10.00mm | 9.4 CFM (0.263m³/min) | 0.120 in H2O (29.9 Pa) | Sleeve | Tubeaxial | - | 26.1dB(A) | 720 mW | 5000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CUR, TUV, UL | - |
|
EF45101S2-1000U-C9912VDC FAN 45X10MM TACH |
3,237 |
|
Datasheet |
EF | Box | Active | 12VDC | Square - 45mm L x 45mm H | 10.00mm | 9.4 CFM (0.263m³/min) | 0.120 in H2O (29.9 Pa) | Sleeve | Tubeaxial | Speed Sensor (Tach) | 26.1dB(A) | 0.72 W | 5000 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
EF45101S1-1000U-C9912VDC FAN 45X10MM TACH |
3,497 |
|
Datasheet |
EF | Box | Active | 12VDC | Square - 45mm L x 45mm H | 10.00mm | 10.8 CFM (0.302m³/min) | 0.160 in H2O (39.8 Pa) | Sleeve | Tubeaxial | Speed Sensor (Tach) | 29.8dB(A) | 1.02 W | 5700 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
OD4006-05LSSFAN AXIAL 40X6MM 5VDC WIRE |
1,635 |
|
Datasheet |
OD4006 | Bulk | Active | 5VDC | Square - 40mm L x 40mm H | 6.00mm | - | - | Sealed Sleeve | Tubeaxial | - | - | - | - | 2 Wire Leads | - | - | - | - |
|
OD4006-12LSSFAN AXIAL 40X6MM 12VDC WIRE |
1,738 |
|
Datasheet |
OD4006 | Bulk | Active | 12VDC | Square - 40mm L x 40mm H | 6.00mm | - | - | Sealed Sleeve | Tubeaxial | - | - | - | - | 2 Wire Leads | - | - | - | - |
|
OD4006-12MSSFAN AXIAL 40X6MM 12VDC WIRE |
2,784 |
|
Datasheet |
OD4006 | Bulk | Active | 12VDC | Square - 40mm L x 40mm H | 6.00mm | - | - | Sealed Sleeve | Tubeaxial | - | - | - | - | 2 Wire Leads | - | - | - | - |
