LED Driver Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Current - Output / Channel | Outputs and Type | Voltage - Output | Features | Voltage - Input | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ISL97682IRTZEVALZ |
7 |
|
Datasheet |
- | Box | Active | 100mA | 2 Non-Isolated Outputs | 45V | Dimmable | 4V ~ 26.5V | Board(s) | ISL97682 |
|
ISL97683IRTZEVALZ |
9 |
|
Datasheet |
- | Box | Active | 50mA | 3 Non-Isolated Outputs | 45V | Dimmable | 4V ~ 26.5V | Board(s) | ISL97683 |
|
ISL97684IRTZEVALZ |
5 |
|
Datasheet |
- | Box | Active | 50mA | 4 Non-Isolated Outputs | 45V | Dimmable | 4V ~ 26.5V | Board(s) | ISL97684 |
|
IS31FL3716-GRLS4-EB |
10 |
|
Datasheet |
- | Box | Active | - | 8 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3716 |
|
IS31FL3716-QFLS4-EB |
8 |
|
Datasheet |
- | Box | Active | - | 8 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3716 |
|
TPS61194EVM |
9 |
|
Datasheet |
- | Bulk | Active | 100mA | 4 Non-Isolated Outputs | 45V | - | 4.5V ~ 40V | Board(s) | TPS61194 |
|
MAX6966EVCMAXQU |
5 |
|
- |
- | Box | Active | 20mA | 10 Non-Isolated Outputs | 7V | - | 5.5V | Board(s) | MAX6966 |
|
MAX1553EVKIT |
9 |
|
- |
- | Box | Active | 20mA | 2 Non-Isolated Outputs | 40V | Dimmable | 2.7V ~ 5.5V | Board(s) | MAX1553, MAX1554 |
|
IS31FL3732A-QFLS2-EB |
8 |
|
Datasheet |
- | Bulk | Active | - | - | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3732A |
|
|
DC336A |
10 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | 5V | - | 3V ~ 4.2V | Board(s) | LTC3200-5 |
|
CY3261-RGB |
7 |
|
- |
PSOC™ | Bulk | Active | - | 3 Non-Isolated Outputs | - | Dimmable | 6V | Board(s), Power Supply | CY8C27443 |
|
APEK80803KET-BB-T |
9 |
|
- |
- | Bulk | Active | - | 1 Non-Isolated Output | - | Dimmable | 5V ~ 37V | Board(s) | A80803 |
|
RDK-193 |
6 |
|
Datasheet |
LinkSwitch®-PH | Box | Active | 330mA | 1 Non-Isolated Output | 21V | Dimmable | 90 ~ 265 VAC | Board(s) | LNK403EG |
|
|
AS1115-QF_DK_ST B |
8 |
|
Datasheet |
- | Box | Active | - | 8 Non-Isolated Outputs | - | - | 2.7V ~ 5.5V | Board(s) | AS1115 |
|
AS1115-QF_DK_ST R |
9 |
|
Datasheet |
- | Box | Active | - | 8 Non-Isolated Outputs | - | - | 2.7V ~ 5.5V | Board(s) | AS1115 |
|
RDK-257 |
7 |
|
Datasheet |
LinkSwitch®-PH | Box | Active | 330mA | 1 Non-Isolated Output | 36V | - | 90 ~ 265 VAC | Board(s) | LNK405EG |
|
RDK-347 |
6 |
|
Datasheet |
LYTSwitch™-4 | Box | Active | 370mA | 1 Isolated Output | 34V | Dimmable | 90 ~ 132 VAC | Board(s) | LYT4313 |
|
RDK-290 |
9 |
|
Datasheet |
LinkSwitch®-PH | Box | Active | 2.1A | 1 Isolated Output | 32V | - | 190 ~ 300 VAC | Board(s) | LNK420 |
|
RDK-355 |
6 |
|
Datasheet |
LYTSwitch™-0 | Box | Active | 110mA | 1 Non-Isolated Output | 54V | - | 90 ~ 265 VAC | Board(s) | LYT0006 |
|
RDK-378 |
5 |
|
Datasheet |
LYTSwitch™-0 | Box | Active | 82mA | 1 Non-Isolated Output | 85V | - | 190 ~ 265 VAC | Board(s) | LYT0006 |
