LED Driver Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Current - Output / Channel | Outputs and Type | Voltage - Output | Features | Voltage - Input | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BCR430ULEDBOARDTOBO1 |
5 |
|
Datasheet |
- | Box | Active | 100mA | 1 Non-Isolated Output | 1.24V | - | 6V ~ 42V | Board(s) | BCR430U |
|
BCR320UHWLEDBOARDTOBO1 |
7 |
|
Datasheet |
- | Box | Active | 150mA | 1 Non-Isolated Output | - | - | 24V | Board(s) | BCR320U |
|
IS32LT3178-STLA3-EB |
9 |
|
- |
- | Bulk | Active | 150mA | 1 Non-Isolated Output | - | Dimmable | 2.6V ~ 40V | Board(s) | IS32LT3178 |
|
IS32LT3177-GRLA3-EB |
7 |
|
- |
- | Bulk | Active | 150mA | 1 Non-Isolated Output | - | Dimmable | 5V ~ 40V | Board(s) | IS32LT3177 |
|
IS31FL3218-QFLS2-EB |
9 |
|
Datasheet |
- | Box | Active | 38mA | 18 Non-Isolated Outputs | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31FL3218 |
|
|
LM3401-MR16DEMO/NOPB |
8 |
|
Datasheet |
- | Box | Active | 1A | 1 Non-Isolated Output | 6.2V | Dimmable | 12VAC | Board(s) | LM3401 |
|
TPS92550EVM/NOPB |
8 |
|
Datasheet |
- | Box | Active | 350mA | 1 Non-Isolated Output | - | Dimmable | 4.5V ~ 36V | Board(s) | TPS92550 |
|
STEVAL-ILL078V1 |
6 |
|
Datasheet |
- | Box | Active | 1A | 1 Non-Isolated Output | - | Dimmable | 4.5V ~ 60V | Board(s) | LED6000 |
|
IS31BL3508A-STLS2-EB |
6 |
|
Datasheet |
- | Bulk | Active | - | 1 Non-Isolated Output | - | Dimmable | 2.7V ~ 5.5V | Board(s) | IS31BL3508A |
|
IS32LT3361-GRLA3-EB |
9 |
|
Datasheet |
- | Box | Active | 1.3A | 1 Non-Isolated Output | - | Dimmable | 6V ~ 40V | Board(s) | IS32LT3361 |
|
STEVAL-ILL054V2 |
10 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | - | Dimmable | 3V ~ 18V | Board(s) | LED2001 |
|
STEVAL-ILL056V1 |
6 |
|
Datasheet |
- | Box | Active | - | 1 Non-Isolated Output | - | Dimmable | 5.5V ~ 48V | Board(s) | LED5000 |
|
|
XRP7613EVB |
6 |
|
Datasheet |
- | Bulk | Active | 1.2A | 1 Non-Isolated Output | - | Dimmable | 7V ~ 36V | Board(s) | XRP7613 |
|
MAX16822BEVKIT+ |
5 |
|
Datasheet |
- | Box | Active | 350mA | 1 Non-Isolated Output | 64V | Dimmable | 6V ~ 65V | Board(s) | MAX16822 |
|
MAX16832CEVKIT+ |
7 |
|
Datasheet |
- | Box | Active | 666mA | 1 Non-Isolated Output | 64V | Dimmable | 6.5V ~ 65V | Board(s) | MAX16832 |
|
MAX16820EVKIT+ |
8 |
|
Datasheet |
- | Box | Active | 1A | 1 Non-Isolated Output | 20V | Dimmable | 5V ~ 28V | Board(s) | MAX16820 |
|
REFICL8800LED43WTOBO1 |
9 |
|
Datasheet |
- | Bulk | Active | - | 1 Isolated Output | 52V | Dimmable | 90 ~ 305 VAC | Board(s) | ICL8800 |
|
IS32LT3128A-ZLA3-EB |
9 |
|
Datasheet |
- | Box | Active | 30mA | 3 Non-Isolated Outputs | - | Dimmable | 5V ~ 42V | Board(s) | IS32LT3128A |
|
178946001 |
7 |
|
Datasheet |
MagI3C | Box | Active | 450mA | 1 Non-Isolated Output | 4.5V ~ 60V | Dimmable | 4.5V ~ 60V | Board(s) | WLMDU9456001JT |
|
EVQ4425B-QB-00A |
10 |
|
Datasheet |
- | Box | Active | 1.5A | 1 Non-Isolated Output | - | Dimmable | 4V ~ 36V | Board(s) | MPQ4425B |
