Evaluation and Demonstration Boards and Kits
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Function | Embedded | Utilized IC / Part | Primary Attributes | Secondary Attributes | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NICHICON-SLB SERIES-EVB-01 |
8 |
|
Datasheet |
SLB | Box | Active | Power Management | Battery Monitor | No | XC6140, XC6240 | 1.1V ~ 6V Input Voltage | - | Board(s) |
|
KITDRIVER2EDN7524GTOBO1 |
6 |
|
Datasheet |
- | Bulk | Active | Power Management | Gate Driver | - | 2EDN7524G | - | - | Board(s) |
|
NGK INSULATOR-EC SERIES-EVB-01 |
9 |
|
Datasheet |
EC | Box | Active | Power Management | Battery Charger | No | XC6810 | 3.5V ~ 28V Input Voltage | - | Board(s) |
|
BM61M22BFJ-EVK002 |
9 |
|
Datasheet |
- | Bulk | Active | Power Management | Gate Driver | Yes, MCU | BM61M22B | 4.5V ~ 5.5V Supply | - | Board(s) |
|
KTA1170GVAE-MMEV01 |
8 |
|
Datasheet |
- | Bulk | Active | Power Management | Bridge Rectifier | No | KTA1170 | 2.7V ~ 75V Input Voltage | - | Board(s) |
|
KITDRIVER1EDN7512GTOBO1 |
10 |
|
Datasheet |
- | Bulk | Active | Power Management | Gate Driver | - | 1EDN7512G | - | - | Board(s) |
|
TMC5272-BOB |
9 |
|
Datasheet |
- | Box | Active | Power Management | Motor Controller/Driver, Stepper | No | TMC5272 | Motors (Stepper) | On-Board LEDs | Board(s) |
|
TPS22995HQ1EVM |
7 |
|
Datasheet |
- | Box | Active | Power Management | Power Distribution Switch (Load Switch) | No | TPS22995H-Q1 | 0.8V ~ 5.5V Input Voltage | On-Board Test Points | Board(s) |
|
TXV0106-EVM |
9 |
|
Datasheet |
- | Box | Active | Interface | Logic-Level Translator | No | TXV0106 | - | On-Board Test Points | Board(s) |
|
TPS2113AEVM-581 |
6 |
|
Datasheet |
- | Box | Active | Power Management | Power Distribution Switch (Load Switch) | No | TPS2113A | 2 Inputs, 1 Output Power Multiplexer | 2.8V ~ 5.5V Supply | Board(s) |
|
TPS22924DEVM-532 |
8 |
|
Datasheet |
- | Box | Active | Power Management | Power Distribution Switch (Load Switch) | No | TPS22924D | - | - | Board(s) |
|
KAS-700-0165 |
8 |
|
Datasheet |
SiSonic™ | Bulk | Active | Audio | MEMS Omnidirectional Microphones | No | SPH11C3LR5H-1 | - | Analog Output | Board(s) |
|
KAS-700-0172 |
10 |
|
Datasheet |
SiSonic™ | Bulk | Active | Audio | MEMS Omnidirectional Microphones | No | SPH18R1LM4H-1 | - | Digital Output | Board(s) |
|
MXL83434E-AGA-EVK-1 |
7 |
|
Datasheet |
- | Bulk | Active | Interface | Receiver | No | MXL83434 | 4-Channel (Quad) | - | Board(s) |
|
MXL83433E-ADA-EVK-1 |
8 |
|
Datasheet |
- | Bulk | Active | Interface | Receiver | No | MXL83433 | 4-Channel (Quad) | - | Board(s) |
|
MXL83212E-ADA-EVK-1 |
5 |
|
Datasheet |
- | Bulk | Active | Interface | Transceiver, RS-422, RS-485 | No | MxL83212 | - | On-Board LEDs, Test Points | Board(s) |
|
MXL83214E-ADA-EVK-1 |
9 |
|
Datasheet |
- | Bulk | Active | Interface | Transceiver, RS-422, RS-485 | No | MxL83214 | - | On-Board LEDs, Test Points | Board(s) |
|
EVAL-ADUM34XEEBZ |
7 |
|
Datasheet |
iCoupler® | Box | Active | Interface | Digital Isolator | No | ADuM340E, ADuM341E, ADuM342E | 4-Channel (Quad) | On-Board Test Points | Board(s) |
|
CT001-S |
10 |
|
Datasheet |
- | Box | Active | - | - | - | - | - | - | Board(s) |
|
TPS22950LEVM |
9 |
|
Datasheet |
- | Bulk | Active | Power Management | Power Distribution Switch (Load Switch) | No | TPS22950 | 1.8V ~ 5.5V Input Voltage | - | Board(s) |
