Evaluation and Demonstration Boards and Kits
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Function | Embedded | Utilized IC / Part | Primary Attributes | Secondary Attributes | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TMUX7212EVM |
7 |
|
Datasheet |
- | Box | Active | Interface | Switch, SPST, 1:1 | No | TMUX7212 | 4-Channel (Quad) | - | Partially Populated Board(s) - Main IC/Module/Part Not Included |
|
MAX77840EVKIT# |
7 |
|
Datasheet |
- | Box | Active | - | - | - | MAX77840 | - | - | Board(s) |
|
MAX77975EVKIT# |
10 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | No | MAX77975 | 3.8V ~ 19V Input Voltage | - | Board(s), Cable(s), Power Supply, Accessories |
|
MAXREFDES182# |
9 |
|
- |
- | Box | Active | Interface | Power Line Communication Modem (PLC) | No | MAX20355, MAX20357 | Power Line | I2C/USB Interface(s) | Board(s), Cable(s), Accessories |
|
MAX77659EVKIT# |
9 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | Yes, MCU | MAX77659 | USB Powered | On-Board LEDs, Test Points | Board(s) |
|
MAX77642EVKIT# |
10 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | No | MAX77642 | Buck-Boost Regulator, 1 LDO, 2 GPIO, Watchdog Timer | - | Board(s), Cable(s), Power Supply, Accessories |
|
SI3473-KIT |
10 |
|
Datasheet |
- | Box | Active | Power Management | Power over Ethernet (PoE) | - | Si3473 | - | - | Board(s) |
|
MR-T1ETH8 |
8 |
|
- |
- | Bulk | Active | Interface | Ethernet | No | SE050, SJA1110, VR5510 | 40V Operating Voltage | On-Board LEDs | Board(s), Cable(s), Accessories |
|
MAXREFDES9# |
8 |
|
Datasheet |
- | Box | Active | Power Management | Transformer Driver | No | MAX668, MAX1659, MAX13256 | Pmod™-Compatible | - | Board(s) |
|
|
ADM00499 |
8 |
|
Datasheet |
- | Bulk | Active | Interface | Analog Front End (AFE) | Yes, MCU, 16-Bit | MCP3912 | 4-Channel (Quad) | - | Board(s) |
|
|
SI5325/26-EVB |
10 |
|
Datasheet |
- | Box | Active | Timing | Clock Generator | - | SI5325, SI5326 | - | - | Board(s), Cable(s) |
|
EH4205/EH300KIT |
6 |
|
Datasheet |
- | Box | Active | Power Management | Energy Harvesting | - | EH4205, EH300 | - | - | Board(s) |
|
EVAL-ADAQ8088EBZ |
10 |
|
Datasheet |
µModule® | Bulk | Active | Multiple | ADC Driver, Filter | No | ADAQ8088 | 2-Channel (Dual) | - | Board(s) |
|
|
MAX77734EVKIT# |
7 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | - | MAX77734 | - | Graphical User Interface (GUI) | Board(s) |
|
TPS65251EVM |
9 |
|
Datasheet |
- | Box | Active | Power Management | Integrated Power Supply | No | TPS65251 | 3 Step-Down Converters, 3.5A, 2.5A, 2.5A | 4.5 ~ 18V Supply | Board(s) |
|
MAX22192EVSYS# |
8 |
|
Datasheet |
- | Box | Active | Interface | Digital Isolator | - | MAX22192 | - | - | Board(s) |
|
EVALM1IR2214TOBO1 |
10 |
|
Datasheet |
EiceDRIVER™ | Bulk | Active | Power Management | Motor Controller/Driver | Yes, MCU | IR2214SS | Motors (BLDC) | On-Board Test Points | Board(s) |
|
EVALPSIRS200XTOBO1 |
8 |
|
Datasheet |
- | Bulk | Active | Power Management | Motor Controller/Driver, Stepper | - | PSIRS200X | - | - | Board(s) |
|
EA EVALEDIPTFT32 |
9 |
|
Datasheet |
Intelligent Display - eDIP | Bulk | Active | Display | LCD Display | - | EA eDIPTFT32 | 3.2" 320x240 QVGA | On-Board LEDs | Board(s), Cable(s) |
|
FRDM33771BSPIEVB |
5 |
|
Datasheet |
- | Bulk | Active | Power Management | Battery Cell Controller | - | MC33771 | 14-Channel | On-Board LEDs | Board(s) |
