Evaluation and Demonstration Boards and Kits
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Function | Embedded | Utilized IC / Part | Primary Attributes | Secondary Attributes | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DS3232MEVKIT# |
5 |
|
Datasheet |
- | Box | Active | Timing | Real Time Clock (RTC) | - | DS3232M | - | - | Board(s) |
|
NCP-NCV51561TO2473LGEVB |
7 |
|
Datasheet |
- | Bulk | Active | Power Management | Gate Driver | No | NCV51561 | Isolated | - | Board(s) |
|
EVAL-CN0388-FMCZ |
6 |
|
- |
Circuits from the Lab™ | Box | Active | Reference Design | Isolated Data Acquisition System | - | AD7960, ADN4651, ADuM2251, ADuM4400 | Isolated | - | Board(s) |
|
|
FRDM-34931S-EVB |
8 |
|
Datasheet |
- | Bulk | Active | Power Management | Motor Controller/Driver | - | MC34931 | - | Graphical User Interface (GUI) | Board(s) |
|
MAX33015ESHLD# |
9 |
|
- |
- | Box | Active | Interface | CAN Transceiver | Yes, MCU | MAX33015E | 5V Power Supply | SPI Interface(s) | Board(s) |
|
MAX22501EEVKIT# |
6 |
|
Datasheet |
- | Box | Active | Interface | Transceiver, RS-422, RS-485 | No | MAX22501E | - | Half-Duplex | Board(s) |
|
MAX22500EEVKIT# |
10 |
|
Datasheet |
- | Box | Active | Interface | Transceiver, RS-422, RS-485 | No | MAX22500E | - | Half-Duplex | Board(s) |
|
LITEDCDCSBCBOARDTOBO1 |
5 |
|
Datasheet |
- | Box | Active | Interface | System Basis Chip (SBC) | - | TLE9471-3ES | - | - | Board(s) |
|
EVALISO1I813TTOBO1 |
6 |
|
Datasheet |
ISOFACE™ | Bulk | Active | Interface | Digital Isolator | No | ISO1I813T | 8-Channel (Octal) | Parallel/Serial Interface(s) | Board(s) |
|
ADL5303-EVALZ |
5 |
|
Datasheet |
- | Box | Active | Interface | Logarithmic Converter | - | ADL5303 | - | - | Board(s) |
|
2RB020BB |
10 |
|
Datasheet |
- | Box | Active | - | - | - | - | - | - | Board(s) |
|
SI8941ISO-KIT |
10 |
|
Datasheet |
- | Bulk | Active | Data Acquisition | Delta-Sigma Modulator (DSM) | Yes, MCU | Si8941 | Isolated | On-Board LEDs, Test Points | Board(s) |
|
EVAL-CN0364-SDPZ |
6 |
|
- |
Circuits from the Lab™ | Bulk | Active | Interface | Analog Input | - | AD7173-8 | 4-Channel (Quad) | - | Board(s) |
|
ISL28023EVKIT1Z |
10 |
|
Datasheet |
- | Bulk | Active | Data Acquisition | ADC, DAC | - | ISL28023 | Monitors Current, Voltage | Graphical User Interface (GUI) | Board(s) |
|
|
MAX31850EVKIT# |
6 |
|
Datasheet |
- | Box | Active | Power Management | Thermal Management | - | MAX31850K | - | USB Interface(s), Graphical User Interface (GUI) | Board(s), Cable(s), Accessories |
|
MAX31856EVSYS# |
9 |
|
Datasheet |
- | Box | Active | Interface | Sensor Signal Conditioner | - | MAX31856 | Pmod™-Compatible | Graphical User Interface (GUI) | Board(s), Cable(s) |
|
|
MAX31856PMB1# |
5 |
|
- |
- | Box | Active | Interface | Sensor Signal Conditioner | - | MAX31856 | Pmod™-Compatible | On-Board LEDs | Board(s) |
|
EVKT-MP2672A |
10 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | No | MP2672A | Li-Ion (2 Cells), 4.5 ~ 6V Input Voltage | I2C Interface(s), Graphical User Interface (GUI) | Board(s), Cable(s) |
|
EVKT-MP2733 |
9 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | No | MP2733 | 3.7V ~ 16V Operating Range | - | Board(s), Cable(s) |
|
|
FRDM-GD3000EVB |
5 |
|
Datasheet |
- | Bulk | Active | Power Management | Motor Controller/Driver | - | GD3000 | - | Graphical User Interface (GUI) | Board(s) |
