Evaluation and Demonstration Boards and Kits
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Function | Embedded | Utilized IC / Part | Primary Attributes | Secondary Attributes | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
5P49V6968-EVK |
7 |
|
Datasheet |
VersaClock® 6E | Box | Active | Timing | Clock Generator | - | 5P49V6968 | - | - | Board(s) |
|
EVAL1ED3241MC12HTOBO1 |
6 |
|
Datasheet |
EiceDRIVER™ | Bulk | Active | Power Management | Gate Driver | No | 1ED3241MC12H | Isolated | On-Board LEDs | Board(s) |
|
MAX20336EVKIT# |
5 |
|
Datasheet |
- | Box | Active | Interface | Analog Switch | No | MAX20336 | 1 x DPDT Switch | On-Board Test Points | Board(s) |
|
|
DC2476A-A |
10 |
|
Datasheet |
- | Box | Active | Power Management | Power over Ethernet (PoE) | No | LT4295, LT4321 | - | - | Board(s) |
|
DC2518A |
7 |
|
Datasheet |
- | Box | Active | Power Management | Digital Power Controller | No | LTC2975 | 4-Channel (Quad) | Graphical User Interface (GUI) | Board(s) |
|
DC2584A-A |
5 |
|
Datasheet |
- | Box | Active | Power Management | Power over Ethernet (PoE) | No | LT4295, LT4321 | - | On-Board LEDs, Test Points | Board(s) |
|
MAX17320X2EVKIT# |
7 |
|
Datasheet |
- | Box | Active | Power Management | - | - | MAX17320 | - | - | Board(s) |
|
MAX5417LEVCMODU |
10 |
|
Datasheet |
- | Box | Active | Data Acquisition | Digital Potentiometer | - | MAX5417 | - | - | Board(s) |
|
KIT33887EKEVBE |
8 |
|
Datasheet |
- | Box | Active | Power Management | H-Bridge Driver (Internal FET) | No | MC33887 | 5A, 5 ~ 28V, PWM to 20kHz, Active Current Limit | Fault Status, Sleep Mode, Proportional Current Mirror Output | Board(s) |
|
RB-S22Q66XTB32 |
8 |
|
Datasheet |
- | Bulk | Active | Audio | Audio Processing | No | ML22Q663, ML22Q664, ML22Q665, ML22Q666 | - | 2.7V to 5.5V Supply | Board(s) |
|
RB-S22Q62XTB32 |
7 |
|
Datasheet |
- | Bulk | Active | Audio | Audio Processing | No | ML22Q623, ML22Q624, ML22Q625, ML22Q626 | - | 2.7V to 5.5V Supply | Board(s) |
|
55020R-10 |
6 |
|
Datasheet |
- | Box | Active | Interface | LonWorks | - | Neuron 3150 | Twisted Pair | - | Board(s) |
|
MAX22707EVKIT# |
10 |
|
Datasheet |
- | Box | Active | Filter | Low Pass, Switched-Capacitor Filters | No | MAX22707 | Isolated | On-Board Test Points | Board(s) |
|
MAX14912EVKIT# |
9 |
|
Datasheet |
- | Box | Active | Power Management | High Side Driver (Internal FET) | - | MAX14912 | 8-Channel (Octal) | On-Board LEDs | Board(s) |
|
ADTJA1101-RMII |
9 |
|
Datasheet |
- | Bulk | Active | Interface | Ethernet | - | TJA1101 | - | - | Board(s), Cable(s) |
|
|
DC1814A-B |
7 |
|
Datasheet |
- | Box | Active | Power Management | Power over Ethernet (PoE) | No | LTC4274A-2 | - | - | Board(s) |
|
HIP4086DEMO1Z |
6 |
|
Datasheet |
- | Bulk | Active | Power Management | Motor Controller/Driver | Yes, MCU, 8-Bit | HIP4086 | Motors (BLDC) | On-Board LEDs | Board(s) |
|
NCP-NCV51561TO2474LGEVB |
10 |
|
Datasheet |
- | Bulk | Active | Power Management | Gate Driver | No | NCV51561 | Isolated | - | Board(s) |
|
|
SN65LVDS101EVM |
7 |
|
Datasheet |
- | Bulk | Active | Interface | LVDS, Serdes | - | SN65LVDS101 | - | - | Board(s) |
|
|
BQ24115EVM |
7 |
|
Datasheet |
bqSWITCHER™ | Bulk | Active | Power Management | Battery Charger | No | BQ24115 | 1, 2, 3, Cell Li-Ion/ Li-Pol, Up to 2A, 5 ~ 16V Input | Charge Conditioning, Charge Status, and Charge Termination | Board(s) |
