Evaluation and Demonstration Boards and Kits
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Function | Embedded | Utilized IC / Part | Primary Attributes | Secondary Attributes | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AC500100 |
6 |
|
Datasheet |
PICtail™ Plus | Bulk | Active | Memory | EERAM | - | 47xxx | mikroBUS™ | - | Board(s) |
|
IL700-01 |
10 |
|
Datasheet |
IsoLoop® | Bulk | Active | Interface | Digital Isolator | - | IL710S-1E, IL712-3E, IL715-3E, IL716E | - | - | Board(s) |
|
IL41050-01 |
5 |
|
Datasheet |
IsoLoop® | Bulk | Active | Interface | Isolated, CAN | - | IL41050TA-3E | - | Thermal Shutdown Circuit | Board(s) |
|
BM1Z102FJ-EVK-001 |
10 |
|
Datasheet |
- | Bulk | Active | Power Management | Power Supply Supervisor/Tracker/Sequencer | - | BM1Z102 | - | - | Board(s) |
|
IL600-01 |
9 |
|
Datasheet |
IsoLoop® | Bulk | Active | Interface | Digital Isolator | - | IL610A-1E, IL611-3E, IL613E, IL614-3E | - | - | Board(s) |
|
|
P3A9606JK-EVB |
8 |
|
Datasheet |
- | Bulk | Active | Interface | Level Shifter | No | P3A9606 | 2-Channel (Dual) | - | Board(s) |
|
|
SI3462-EVB |
6 |
|
Datasheet |
- | Bulk | Active | Power Management | Power Over Ethernet (POE), PSE | No | Si3462 | - | - | Board(s) |
|
MAX5389EVKIT+ |
8 |
|
Datasheet |
- | Box | Active | Data Acquisition | Digital Potentiometer | - | MAX5389 | 2 Channel, 256 Position | - | Board(s) |
|
|
STEVAL-ISB035V1 |
8 |
|
Datasheet |
- | Bulk | Active | Power Management | Battery Charger | No | STBC03 | - | - | Board(s) |
|
TPS22998EVM |
10 |
|
Datasheet |
- | Box | Active | Power Management | Power Distribution Switch (Load Switch) | No | TPS22998 | 0.2V ~ 5.5V Input Voltage | On-Board Test Points | Board(s) |
|
|
EVALSTGAP2SM |
10 |
|
Datasheet |
- | Bulk | Active | Power Management | Gate Driver | No | STGAP2SM | Isolated | On-Board Test Points | Board(s) |
|
EVALSTGAP2DM |
10 |
|
Datasheet |
- | Bulk | Active | Power Management | Gate Driver | No | STGAP2DM | - | - | Board(s) |
|
|
SI82XX-KIT |
7 |
|
Datasheet |
- | Bulk | Active | Interface | ISOdriver | No | Si8220, Si8233, Si8234, Si8235 | 4 Individual Circuits | - | Board(s) |
|
MAX17526AEVKIT# |
9 |
|
Datasheet |
- | Box | Active | Power Management | - | - | MAX17526A | - | - | Board(s) |
|
MAX17610EVKIT# |
10 |
|
Datasheet |
- | Box | Active | Circuit Protection | Overcurrent, Overvoltage, Reverse-Voltage | - | MAX17610 | - | - | Board(s) |
|
MAX17612AEVKIT# |
7 |
|
Datasheet |
- | Box | Active | Circuit Protection | Overcurrent, Overvoltage, Reverse-Voltage, Undervoltage | - | MAX17612A | - | - | Board(s) |
|
MAX17608EVKIT# |
10 |
|
Datasheet |
- | Box | Active | Circuit Protection | Overcurrent, Overvoltage, Reverse-Voltage | - | MAX17608 | - | - | Board(s) |
|
|
EV2667-G-00A |
8 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | - | MP2667 | Li-Ion / Li-Pol (1 Cell) | On-Board Test Points | Board(s) |
|
EV2731-QC-00A |
7 |
|
Datasheet |
- | Box | Active | Power Management | Battery Charger | No | MP2731 | 3.7V ~ 16V Input Voltage | On-Board LEDs, Test Points | Board(s) |
|
DC2548A |
8 |
|
Datasheet |
- | Box | Active | Power Management | Gate Driver | No | LT8672 | - | - | Board(s) |
