Analog to Digital Converters (ADC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Number of Bits | Sampling Rate (Per Second) | Number of Inputs | Input Type | Data Interface | Configuration | Ratio - S/H:ADC | Number of A/D Converters | Architecture | Reference Type | Voltage - Supply, Analog | Voltage - Supply, Digital | Features | Operating Temperature | Supplier Device Package | Mounting Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ADS1283BIRHFRIC ADC 31BIT SIGMA-DELTA 24VQFN |
1,006 |
|
Datasheet |
- | 24-VFQFN Exposed Pad | Tape & Reel (TR) | Active | 31 | 128k | 2 | Differential | SPI | MUX-PGA-ADC | 0:1 | 1 | Sigma-Delta | External | 2.15V ~ 5.25V | 1.65V ~ 3.6V | PGA | -40°C ~ 85°C | 24-VQFN (5x4) | Surface Mount | - | - |
|
ADS1283AIRHFRIC ADC 31BIT SIGMA-DELTA 24VQFN |
4,768 |
|
Datasheet |
- | 24-VFQFN Exposed Pad | Tape & Reel (TR) | Active | 31 | 128k | 2 | Differential | SPI | MUX-PGA-ADC | 0:1 | 1 | Sigma-Delta | External | 2.15V ~ 5.25V | 1.65V ~ 3.6V | PGA | -40°C ~ 85°C | 24-VQFN (5x4) | Surface Mount | - | - |
|
LTC2220CUP-1#PBFIC ADC 12BIT PIPELINED 64QFN |
3,821 |
|
Datasheet |
- | 64-WFQFN Exposed Pad | Tube | Active | 12 | 185M | 1 | Differential, Single Ended | LVDS - Parallel, Parallel | S/H-ADC | 1:1 | 1 | Pipelined | External, Internal | 3.1V ~ 3.5V | 3.1V ~ 3.5V | - | 0°C ~ 70°C | 64-QFN (9x9) | Surface Mount | - | - |
|
LTC2220CUP-1#TRPBFIC ADC 12BIT PIPELINED 64QFN |
3,802 |
|
Datasheet |
- | 64-WFQFN Exposed Pad | Tape & Reel (TR) | Active | 12 | 185M | 1 | Differential, Single Ended | LVDS - Parallel, Parallel | S/H-ADC | 1:1 | 1 | Pipelined | External, Internal | 3.1V ~ 3.5V | 3.1V ~ 3.5V | - | 0°C ~ 70°C | 64-QFN (9x9) | Surface Mount | - | - |
|
ADS6128IRGZRIC ADC 12BIT PIPELINED 48VQFN |
2,547 |
|
Datasheet |
- | 48-VFQFN Exposed Pad | Tape & Reel (TR) | Active | 12 | 210M | 1 | Differential | LVDS - Parallel, Parallel | S/H-ADC | 1:1 | 1 | Pipelined | External, Internal | 3V ~ 3.6V | 1.7V ~ 1.9V | - | -40°C ~ 85°C | 48-VQFN (7x7) | Surface Mount | - | - |
|
LTC2299IUP#TRPBFIC ADC 14BIT PIPELINED 64QFN |
4,329 |
|
Datasheet |
- | 64-WFQFN Exposed Pad | Tape & Reel (TR) | Active | 14 | 80M | 2 | Differential, Single Ended | Parallel | S/H-ADC | 1:1 | 2 | Pipelined | External, Internal | 2.7V ~ 3.4V | 2.7V ~ 3.4V | Simultaneous Sampling | -40°C ~ 85°C | 64-QFN (9x9) | Surface Mount | - | - |
|
LTC2207CUK-14#TRPBFIC ADC 14BIT PIPELINED 48QFN |
1,005 |
|
Datasheet |
- | 48-WFQFN Exposed Pad | Tape & Reel (TR) | Active | 14 | 105M | 1 | Differential | Parallel | S/H-ADC | 1:1 | 1 | Pipelined | External, Internal | 3.135V ~ 3.465V | 3.135V ~ 3.465V | PGA | 0°C ~ 70°C | 48-QFN (7x7) | Surface Mount | - | - |
|
AD9635BCPZRL7-125IC ADC 12BIT PIPELINED 32LFCSP |
1,806 |
|
Datasheet |
- | 32-WFQFN Exposed Pad, CSP | Tape & Reel (TR) | Active | 12 | 125M | 2 | Differential | LVDS - Serial | S/H-ADC | 1:1 | 2 | Pipelined | Internal | 1.7V ~ 1.9V | 1.7V ~ 1.9V | Simultaneous Sampling | -40°C ~ 85°C | 32-LFCSP (5x5) | Surface Mount | - | - |
|
KAD5514P-12Q72IC ADC 14BIT SAR 72QFN |
2,476 |
|
Datasheet |
- | 72-VFQFN Exposed Pad | Tray | Active | 14 | 125M | 1 | Differential | LVDS - Parallel, Parallel | S/H-ADC | 1:1 | 1 | SAR | Internal | 1.7V ~ 1.9V | 1.7V ~ 1.9V | - | -40°C ~ 85°C | 72-QFN (10x10) | Surface Mount | - | - |
|
|
ADC09QJ1300AAVTQ1IC ANALOG TO DIGITAL CONVERTER |
1,388 |
|
Datasheet |
- | 144-FBGA, FCBGA | Tape & Reel (TR) | Active | 9 | 1.3G | 4 | Differential | JESD204C, Serial | ADC | 0:1 | 4 | Pipelined, SAR | Supply | 1.05V ~ 1.15V, 1.8V ~ 2V | 1.05V ~ 1.15V | Internal Oscillator | -40°C ~ 125°C | 144-FCBGA (10x10) | Surface Mount | Automotive | AEC-Q100 |
|
ADS5242IPAPIC ADC 12BIT PIPELINED 64HTQFP |
3,092 |
|
Datasheet |
- | 64-PowerTQFP | Tray | Active | 12 | 65M | 4 | Differential | LVDS - Serial | S/H-ADC | 1:1 | 4 | Pipelined | External, Internal | 3V ~ 3.6V | 3V ~ 3.6V | Simultaneous Sampling | -40°C ~ 85°C | 64-HTQFP (10x10) | Surface Mount | - | - |
|
AD9648BCPZRL7-105IC ADC 14BIT PIPELINED 64LFCSP |
1,255 |
|
Datasheet |
- | 64-VFQFN Exposed Pad, CSP | Tape & Reel (TR) | Active | 14 | 105M | 2 | Differential | LVDS - Parallel, Parallel | S/H-ADC | 1:1 | 2 | Pipelined | External, Internal | 1.7V ~ 1.9V | 1.7V ~ 1.9V | Simultaneous Sampling | -40°C ~ 85°C | 64-LFCSP-VQ (9x9) | Surface Mount | - | - |
|
|
ADC09QJ1300AAVQ1AUTOMOTIVE QUAD-CHANNEL, 9-BIT, |
4,144 |
|
Datasheet |
- | 144-FBGA, FCBGA | Tray | Active | 9 | 1.3G | 4 | Differential | JESD204C, Serial | ADC | 1:1 | 4 | Pipelined, SAR | Supply | 1.05V ~ 1.15V, 1.8V ~ 2V | 1.05V ~ 1.15V | Internal Oscillator | -40°C ~ 125°C (TA) | 144-FCBGA (10x10) | Surface Mount | - | - |
|
ADS62P44IRGCRIC ADC 14BIT PIPELINED 64VQFN |
3,905 |
|
Datasheet |
- | 64-VFQFN Exposed Pad | Tape & Reel (TR) | Active | 14 | 105M | 2 | Differential | LVDS - Parallel, Parallel | S/H-ADC | 1:1 | 2 | Pipelined | External, Internal | 3V ~ 3.6V | 1.65V ~ 3.6V | Simultaneous Sampling | -40°C ~ 85°C | 64-VQFN (9x9) | Surface Mount | - | - |
|
LTC2162IUK#TRPBFIC ADC 16BIT PIPELINED 48QFN |
2,093 |
|
Datasheet |
- | 48-WFQFN Exposed Pad | Tape & Reel (TR) | Active | 16 | 65M | 1 | Differential | LVDS - Parallel, Parallel | S/H-ADC | 1:1 | 1 | Pipelined | External, Internal | 1.7V ~ 1.9V | 1.7V ~ 1.9V | - | -40°C ~ 85°C | 48-QFN (7x7) | Surface Mount | - | - |
|
ADS5421Y/TIC ADC 14BIT PIPELINED 64LQFP |
3,922 |
|
Datasheet |
- | 64-LQFP | Tape & Reel (TR) | Active | 14 | 40M | 1 | Differential | Parallel | S/H-ADC | 1:1 | 1 | Pipelined | External, Internal | 5V | 5V | - | -40°C ~ 85°C | 64-LQFP (10x10) | Surface Mount | - | - |
|
|
LTC2267IUJ-14#TRPBFIC ADC 14BIT PIPELINED 40QFN |
2,500 |
|
Datasheet |
- | 40-WFQFN Exposed Pad | Tape & Reel (TR) | Active | 14 | 105M | 2 | Differential | LVDS - Serial | S/H-ADC | 1:1 | 2 | Pipelined | External, Internal | 1.7V ~ 1.9V | 1.7V ~ 1.9V | Simultaneous Sampling | -40°C ~ 85°C | 40-QFN (6x6) | Surface Mount | - | - |
|
LTC2144IUP-14#TRPBFIC ADC 14BIT PIPELINED 64QFN |
3,735 |
|
Datasheet |
- | 64-WFQFN Exposed Pad | Tape & Reel (TR) | Active | 14 | 105M | 2 | Differential | LVDS - Parallel, Parallel | S/H-ADC | 1:1 | 2 | Pipelined | External, Internal | 1.7V ~ 1.9V | 1.7V ~ 1.9V | Simultaneous Sampling | -40°C ~ 85°C | 64-QFN (9x9) | Surface Mount | - | - |
|
LTC2298IUP#TRPBFIC ADC 14BIT PIPELINED 64QFN |
2,176 |
|
Datasheet |
- | 64-WFQFN Exposed Pad | Tape & Reel (TR) | Active | 14 | 65M | 2 | Differential, Single Ended | Parallel | S/H-ADC | 1:1 | 2 | Pipelined | External, Internal | 2.7V ~ 3.4V | 2.7V ~ 3.4V | Simultaneous Sampling | -40°C ~ 85°C | 64-QFN (9x9) | Surface Mount | - | - |
|
MAX174ACPI+IC ADC 12BIT W/REF 28-DIP |
3,554 |
|
Datasheet |
- | 28-DIP (0.600", 15.24mm) | Tube | Active | 12 | 125k | 1 | Single Ended | Parallel | S/H-ADC | 1:1 | 1 | SAR | Internal | 5V, -12V, -15V | 5V, -12V, -15V | - | 0°C ~ 70°C | 28-PDIP | Through Hole | - | - |
